- Page 1 Magro-J – Series Swing Gate Opener User Manual www.autoglideglobal.com 2018...
-
Page 2: Safety Instruction
Dear users, Thank you for choosing this product. Please read the manual carefully before assembling and using it. Please do not leave out the manual if you send this product to a third party. 1. Safety Instruction Please ensure that the using power voltage matches with the supply voltage of gate opener (AC110V or AC220V);... - Page 3 2. Packing List (standard) Picture Name Quantity Main engine Manual release bar Remote control Control box Wall bracket Front mounting bracket Connecting bracket Mounting screw (short) Mounting screw (length) Screw M8×25 Nut M8 Safety stopper (Optional)
-
Page 4: Technical Parameters
2. Packing list (optional) Picture Name Quantity Infrared sensor Wireless keypad Alarm lamp Electronic lock Storage battery 3. Technical parameters Magro - 500 J Model Magro - 650 J 220V/50Hz;110V/60Hz Power supply 220V/50Hz;110V/60Hz Motor power 18~22 second per 90 (approx) Gate moving speed 18~22 second per 90 (approx) 250 Kg... -
Page 5: Installation
4. Installation Magro J Series swing gate opener is applicable to single leaf gate weight less than 225/300 kg, and length of the single leaf swing gate should be less than 2.5m/3m. The drive mode adopts the worm and worm gear to combine the screw rod transmission. This gate opener must be installed inside the enclosure or yard for protection. - Page 6 Magro – 650 J Figure 2 4.2.2 Size of mounting plate Wall bracket Front mounting bracket Figure 3 4.3 Installation steps 4.3.1 Preparation before main engine installation a) Before installing the door opener, please confirm the correct installation of the door to ensure that the door can be easily manually operated, and the door safety stopper can effectively prevent the door to continue moving.
- Page 7 Mounting brackets In order to install the Magro - 500 J / Magro - 650 J main engines firmly, recommend to use the expansion screws to fix the mounting brackets. 4.3.2 Accessory a) Before installing the main engine, install the wall bracket on the wall, then fix the connecting bracket, and install the front mounting bracket on the door.
- Page 8 Note: The pipe outlet should be facing down to avoid rain water entering the pipe along the cable. d) Before the installation, please unlock the main engine. Method: Remove the cover, insert the manual release bar, rotate the bar until the release, as shown in Figure 6, then turn the telescopic arm to make it easily stretch.
- Page 9 Mounting screw (length) Mounting screw (short) Figure 7 Installation direction: door open facing inward (Magro - 500 J) Note: Note: Safety Safety stopper stopper must must be be installed installed L=620+5 L=620+5 K ＜ 620+340 620+340 Figure 8...
- Page 10 100 110 120 130 140 150 160 170 180 190 200 Max 120° Max 110° Max 100° Max 90° Figure 9 Note: Value B must be close to or equal to the value A to obtain the best mechanical advantage. Installation direction: door open facing outward (Magro - 650 J) Note: Note: Satety...
- Page 11 100 110 120 130 140 150 160 170 180 190 200 Max 90° Max 100° Max 110° Max 120° Figure 11 Note: Value B must be close to or equal to the value A to obtain the best mechanical advantage. Installation direction: door open facing inward (Magro - 500 J) Note: Note: Safety...
- Page 12 100 120 140 160 180 200 220 240 260 280 300 Max 120° Max 110° Max 100° Max 90° Figure 13 Note: Value B must be close to or equal to the value A to obtain the best mechanical advantage. Installation direction: door open facing outward (Magro - 650 J) Note: Note: Satety...
- Page 13 100 120 140 160 180 200 220 240 260 280 300 Max 90° Max 100° Max 110° Max 120° Figure 15 Note: Value B must be close to or equal to the value A to obtain the best mechanical advantage. 4.3.4 Size of control box 127.5 Figure 16...
-
Page 14: Control Board Wiring
Warnings ·To ensure safety, when door open facing outward, the safety block must be installed at the OPEN limit position to prevent the door opening angle from exceeding the machine range; the safety stopper must be installed at the CLOSE limit position, to make two doors stopping at the CLOSE limit position accurately (as shown in figure 10, 14). -
Page 15: Transformer Wiring
Wiring instruction: POWER AC terminal 24VAC alternating current power. ＋ BATTARY － terminal Storage battery. 8P terminal: LIGHT Alarm lamp (24VDC); MOTOR 1 Main engine 1; MOTOR 2 Main engine 2; LOCK Electronic lock (24VDC). CN2 terminal ： ＋ PWR Power supply for fittings +24VDC;... -
Page 16: Dip Switch
DIP switch Dial Function Door closing delay function: ON: Enabled - Motor 2 is 5 seconds delay to close the door than Motor 1; OFF: Disabled. Door opening status: ON: Enabled - Motor 1 and motor 2 conduct 0.5-second close action before open the door;... - Page 17 Infrared Infrared receiver receiver connecting connecting Infrared Infrared emitter emitter connecting connecting SET NC － ＋ － ＋ Com Out IN5408 IN5408 Figure 19 Adjustment and operation Remote control operation Remote control is single button mode, one same button on the remote control to circularly control the main engine OPEN/STOP/CLOSE/STOP.
- Page 18 Add extra remote control (remote control learning): Remove the upper cover of main engine; press the learning button S1 on the control board, and indicator light LEARN will flash once and then go out; press the same button on the remote control twice, the LEARN flashes repeatedly and then goes out;...
- Page 19 Solar panel connection: Solar Solar panel panel Solar Solar charger charger － ＋ － Storage Storage battery battery ＋ Figure 22 5. Others 5.1 Maintenance Check whether the gate operates normally every month. For the sake of safety, each gate is suggested to be equipped with infrared protector, and regular inspection is required.
-
Page 20: Troubleshooting
5.2 Troubleshooting Problems Possible Reasons Solutions 1.Switch power 1.The power is off. supply. The gate cannot open 2.Fuse is burned. 2.Check the fuse, change the or close normally, and 3.Control board power wiring fuse if burnt. LED does not light. with problem.
