Panacea

Soft touch SiderailS

for Panacea 3000, 3250 and 3500 beds

Owner's Manual

Please keep and refer to this Owner's Manual.

Thank you for purchasing Panacea

Soft Touch Siderails from Direct Supply Equipment & Furnishings

. Please read this

entire guide carefully and keep it for future reference. This guide will provide you with instructions, warnings, warranty

information and other important information about your Soft Touch Siderails. Share this information with your housekeeping,

nursing and maintenance staff to help ensure the soft touch siderails are cared for properly.

1-800-634-7328 DirectSupply.com

Table of Contents

Need help?

Do you have a question about the Panacea 3000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Direct Supply Panacea 3000

Page 1 Panacea 3000, 3250 and 3500 beds Owner’s Manual Please keep and refer to this Owner’s Manual. Thank you for purchasing Panacea Soft Touch Siderails from Direct Supply Equipment & Furnishings . Please read this ® ® entire guide carefully and keep it for future reference. This guide will provide you with instructions, warnings, warranty information and other important information about your Soft Touch Siderails.
Page 2: Table Of Contents
Table of Contents Table of Contents Description and Intended Use .................... 3 Capacity ..........................3 Important Warnings ......................4 Installation ........................5 - 7 Operation ..........................8 Maintenance ........................9 Limited Warranty ......................10 Customer Service ......................11...
Page 3: Description And Intended Use
Description and Intended Use & Capacity Description & Intended Use Assist devices are intended to be used with the following Direct Supply beds: • Panacea 3000 beds with a safe working load of 450 pounds. • Panacea 3250 beds with a safe working load of 500 pounds. • Panacea 3500 beds with a safe working load of 600 pounds. The assist device is intended for use as an aid in entering or exiting the bed, as well as a stable handhold during self-positioning within the bed.
Page 4: Important Warnings
• resulting in serious injury or death. For questions WarNINg: Risk of serious injury or death. Do not regarding compatibility, contact your Direct Supply use this assist rail until you have verified it is locked in account manager. place. Injury to resident or caregiver may result if this procedure is not followed.
Page 5: Installation
Installation required Tools Plastic hammer Included Parts NoTe: Directional descriptions refer to the resident in a supine position. 1. 7540137BEI: A. (1) Siderail Assembly – Head, Right (NOT SHOWN) B. (1) Siderail Assembly – Head, Left (SHOWN) - OR - 7540028BEI: A.
Page 6 Installation (cont.) rail Location Position the rail in the locked (raised) position. NoTe: Siderails are provided with a label on the face of the mount plate that indicates appropriate bed position locations. Head Foot NoTe: For the foot siderails, follow the arrow for siderail placement and ignore the picture of the person.
Page 7 Bed attachment 1. Insert snap-in nylon bearings into sleep deck mount holes on bed frame. 2. Insert siderail attachment pins into outer and inner sleep deck mount holes, ensuring the rail is properly located on the bed (grooves should be on the inside of the inner mount holes). 3.
Page 8: Operation
Operation To raise: Rotate the siderail upward and toward the head of the bed. Ensure the lock is engaged and functioning properly. To Lower: Press the red button to disengage the lock, then rotate the siderail down. Button...
Page 9: Maintenance
Maintenance routine Inspection 1. Review “REDUCING THE RISK OF ENTRAPMENT” listed in this manual. 2. Review and inspect for compliance the “WARNINGS” listed in this manual. 3. Inspect all components for damage or excessive wear. 4. Visually examine all welds for cracks. 5. Inspect all bolts and fasteners (Do not over tighten bolts at pivot points). Cleaning Clean with a mild solution of antiseptic cleaner and warm water. Read and follow all label instructions on the cleaning products.
Page 10: Limited Warranty
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE; THESE AND ALL OTHER IMPLIED WARRANTIES ARE SPECIFICALLY DISCLAIMED. TO THE FULLEST EXTENT ALLOWED BY LAW, DIRECT SUPPLY MANUFACTURING, INC. WILL NOT BE LIABLE FOR ANY INCIDENTAL, SPECIAL, CONSEQUENTIAL OR PUNITIVE DAMAGES, OR LOST PROFITS THAT MAY RESULT FROM THE DEVICE OR YOUR USE OF OR INABILITY TO USE THE DEVICE EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
Page 11: Customer Service
Panacea Soft Touch Siderails and enjoy outrageous customer service. If you have any questions about the rails you have purchased or would like to request warranty service, please contact: Direct Supply equipment & Furnishings at 1-800-634-7328, 6767 N. Industrial Road, Milwaukee, WI 53223, SalesSupport@DirectSupply.com. 1-800-634-7328...
Page 12 Distributed by Direct Supply Manufacturing, Inc. 6699 N Industrial Road, Milwaukee, WI 53223. © 2015 Direct Supply Manufacturing, Inc. All Rights Reserved. Direct Supply , Panacea , and all associated logos are the registered ® ® trademarks of Direct Supply, Inc., used under license.
