Direct Supply Panacea 6300 Assembly And Operation Manual

Bariatric free-standing trapeze
Hide thumbs Also See for Panacea 6300:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual
Panacea
®
6300 Bariatric
Free-Standing trapeze
Assembly and Operation Manual
Please keep and refer to this Owner's Manual.
Read this Assembly and Operation Manual, along with your Bed Owner's Manual, completely and carefully before
proceeding with assembly procedures. If you require an additional copy of the Panacea 6300 Bariatric Bed Owner's Manual
that accompanied your Panacea
6300 Bariatric Bed, contact Direct Supply Equipment & Furnishings
.
®
®
If you do not feel capable of performing this assembly, STOP – please contact Direct Supply Equipment &
Furnishings or a capable service person to finish the assembly for you. Improper assembly will affect user safety
and may void your warranty.
1-800-634-7328 DirectSupply.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Panacea 6300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Direct Supply Panacea 6300

Summary of Contents for Direct Supply Panacea 6300

  • Page 1 Please keep and refer to this Owner’s Manual. Read this Assembly and Operation Manual, along with your Bed Owner’s Manual, completely and carefully before proceeding with assembly procedures. If you require an additional copy of the Panacea 6300 Bariatric Bed Owner’s Manual that accompanied your Panacea 6300 Bariatric Bed, contact Direct Supply Equipment &...

  • Page 2: Table Of Contents

    WE, US and OUR: Direct Supply Manufacturing, Inc. Device Description The Panacea 6300 series bariatric trapeze is a floor-mounted static device that allows residents to reposition themselves in bed, and is intended for use within an institutional healthcare environment, Application Environment 3 (i.e.

  • Page 3: Warnings

    Warnings • Read and follow all directions and warnings WARNING: Do not use this device without before using this device. Do not operate this proper instruction and supervision from a device without first reading and understanding healthcare professional. this manual. Damage or injury may result from •...

  • Page 4: Trapeze Specifications

    Trapeze Specifications Item # #0-67583 Total Height 69½" (176.5 cm) Total Width 32½" (82.5 cm) Total Depth 58" (147 cm) Width Between Legs 28½" (72 cm) Boom Length 40" (102 cm) Product Weight 106 lbs. (48 kg) Shipping Weight 116 lbs. (52.5 kg) Weight Capacity 350 lbs.

  • Page 5: Assembly & Directions For Use

    " Wrench Prior to installation, verify all package contents have been received in good condition. If components are damaged or missing, contact Direct Supply Equipment & Furnishings immediately. DO NOT use substitute parts or assemble the device while missing parts.

  • Page 6: Assembly & Directions For Use

    Assembly & Directions for Use Step 1 Clear a work space and remove all contents from shipping box. You can use the top of the box to place unwrapped items in. Step 2 Place trapeze legs on floor. Make sure foot pads are on the floor. Next, attach mid-section on the posts coming up from the trapeze legs.

  • Page 7: Directsupply.com

    Assembly & Directions for Use Step 3 Use the (12) ½" long hex bolts and washers to attach the mid-section to the trapeze legs. Step 4 Use the (4) 6" long hex bolts, washers and lock nuts to attach the trapeze boom to the mid-section. 1-800-634-7328 DirectSupply.com...
  • Page 8 Assembly & Directions for Use Step 5 Check to ensure all bolts are tightened and secure. Not doing so may result in injury to the patient/resident or staff. Step 6 Attach the trapeze handle to an appropriate spot for the resident. Step 7 If the bed is not in the center of the room, move it to a location that provides access to both sides.
  • Page 9 Repeat for other side. YOU HAvE NOW COMPLETED THE ASSEMBLY OF YOUR PANACEA 6300 BARIATRIC FREE- STANDING TRAPEZE. Be sure to double-check all bolts and part placements on the trapeze. Also, be sure to remove all packaging materials from the area before allowing residents into the area.

  • Page 10: Cleaning & Maintenance

    Cleaning & Maintenance • T he trapeze frame should be cleaned periodically using a mild detergent and water. Be sure to completely dry the trapeze frame before use. When washing the trapeze straps, use only mild detergent and water. DO NOT USE BLEACH. Allow straps to completely air-dry before use. Do not place straps in a dryer. Prior to First Use Per Patient Maintenance: • Check and tighten all hardware • Inspect the frame and strap for wear or damage...

  • Page 11: Limited Warranty

    MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE; THESE AND ALL OTHER IMPLIED WARRANTIES ARE SPECIFICALLY DISCLAIMED. TO THE FULLEST EXTENT ALLOWED BY LAW, DIRECT SUPPLY MANUFACTURING, INC. WILL NOT BE LIABLE FOR ANY INCIDENTAL, SPECIAL, CONSEQUENTIAL OR PUNITIVE DAMAGES, OR LOST PROFITS THAT MAY RESULT FROM THE DEVICE OR YOUR USE OR INABILITY TO USE THE DEVICE EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

  • Page 12: Customer Service

    , a division of Direct Supply ® ® ™ ® Inc. Distributed by Direct Supply Manufacturing, Inc. 6699 N Industrial Road, Milwaukee, WI 53223. © 2011-2015 Direct Supply Manufacturing, Inc. All Rights Reserved. Direct Supply , Panacea , and all associated logos are the ®...
