Installation - Omcan Imbera VR08 Instruction Manual

VFS SERIES
Model
Type
Volume
Number of
Doors
Number of
Shelves
Shelf Size
Temperature
Range
Max Ambient
Temp Rating
Energy
Consumption
Electrical
Power
Current
Weight
Item Number
*Energy consumption based on ANSI/ASHRAE Standard 72-2005.
• Install this cooler avoiding direct sunlight.
• Do not install this cooler outdoors.
• This cooler must not be used or stored where ambient temperature
is under 14°F or greater than 140°F and where relative humidity is
greater than 90%.
• Never install equipment close to heat sources; otherwise, cooler may
consume more energy or function incorrectly.
• Do not introduce hot objects or warmer than ambient temperature
inside cooler.
• Never obstruct or place objects along front grill which may obstruct
free air flow; this may cause inefficient cooler operation and will increase the energy consumption.
Technical Specifications
VFS24
Freezer
670.3 L / 23.7 cu. ft.
1
5
25.7" x 21.3" / 653 x 541mm
-28 to -23°C / -18.4 to -9.4°F
32°C - 90°F
10.22 kWh/day*
115V / 60Hz / 1
3/4 HP
7.0A
378 lbs. / 171 kgs.
41221
11

Installation
