Rugged Radios P N PH-MS Installation Manual

RADIO & INTERCOM HARNESS WITH ROCKER SWITCH
Installation Guide
This guide will explain how to connect your Rugged Intercom and Mobile Radio inline with our
Radio/Intercom Harness with Rocker Switch.
Radio & Intercom Harness with Rocker Switch (P.N. PH-MS)
TO INTERCOM
• Blue wire connects to accessory bus bar.
• Connection source should only be hot when
ignition is turned on.
NOTE: Cables and connections are not to scale.
RUGGEDRADIOS.COM
WIRE DIRECTLY
TO BATTERY
TO MOBILE
RADIO
HARNESS
POWER CABLE
(P.N. PH-MS)
(PACKAGED WITH
MOBILE RADIO)
TO POWER
SOURCE
RADIO/INTERCOM HARNESS W/ ROCKER SWITCH V.10
BLUE WIRE
TO 12V IGNITION
(ACTIVATES LED LIGHT)
