Sodex Sport S25345 Assembly Instructions

Right and left lateral chair aluminium

Table of Contents

Download this manual

DESCRIPTION

Aluminium Structure

Powder coated

CONFORM

The assembly time for additionnal seating for aluminium umpire chair is estimated at 05 minutes with 1 people.

The equipement has to be regularly maintained by the owner. It is adviced to:

- Check every week that all the screws are correctly tightened.

- Fix paint defects if the module has been damaged, using the adapted paint, specified by the

manufacturer.

- Replace all damaged or missing parts with a spare part recommended by the manufacturer.

One full year parts and labor guarantee. Every claim regarding condition of the delivered equipment has

to be done within the legal period of the reception of the material. The warranty will not apply to:

All degradation during the transport.

All degradation due to use differing from which was intended.

All degradation due to poor maintenance.

Any defect claimed after the end of the legal period.

Any damaged due to a faulty installation and assembly of the module.

ASSEMBLY INSTRUCTIONS

RIGHT AND LEFT LATERAL CHAIR

PRODUCT REF

ALUMINIUM

S25345

UNIT

Table of Contents

Do you have a question about the S25345 and is the answer not in the manual?

Page 1 ASSEMBLY INSTRUCTIONS RIGHT AND LEFT LATERAL CHAIR ALUMINIUM S25345 UNIT PRODUCT REF DESCRIPTION Aluminium Structure Powder coated CONFORM ASSEMBLY TIME The assembly time for additionnal seating for aluminium umpire chair is estimated at 05 minutes with 1 people. MAINTENANCE The equipement has to be regularly maintained by the owner. It is adviced to: - Check every week that all the screws are correctly tightened.
Page 2 ASSEMBLY NECESSARY TOOLS (NOT INCLUDED) Wrench 17mm INCLUDED ITEMS 1- ASSEMBLY OF THE SEAT SS Screws M10x50 + SS Washers 10 + SS Lock nuts M10 NECESSARY ITEMS...
Page 3 PACKING LIST RIGHT AND LEFT LATERAL CHAIR ALUMINIUM PRODUCT REF S25345 Index C UNIT NOMENCLATURE Package Weight Dim. Index Designation Description Quantity Packing method N° (kg) (mm) S25345-01 Additional frame Plastic bubble 930x400x840 S35402 Seat Plastic bubble 500x510x350 ACCESSORIES PUT IN CLEAR PVC BAG...
