Sodex Sport S28240 Assembly Instructions

Two competition shuttlecock posts

Download this manual

DESCRIPTION

Steel structure 40x40

Powder coated

CONFORM

The time to assemble this product is estimated at 5 minutes with 2 people.

The equipment has to be regularly maintained by the owner. It is recommended to:

- Check every week that all the bolts are correctly tightened.

- Fix paint defects if the unit has been damaged, using the adapted paint specified by the manufacturer.

- Replace all damaged or missing parts with a spare part recommended by the manufacturer.

- Clean the product by using dishwasher soap, clean water, and soft cloth.

One full year parts and labour guarantee. Every claim regarding the condition of the delivered equipment

has to be done within the warranty period following receipt of the product.

The warranty will not apply to:

Any degradation during transport.

Any degradation due to poor maintenance.

Any degradation due to use differing from which the product was intended.

Any defect claimed after the end of the warranty period.

Any damage due to a faulty installation or assembly of the product.

ASSEMBLY INSTRUCTIONS

TWO COMPETITION

SHUTTLECOCK POSTS

PRODUCT REF

ASSEMBLY TIME

MAINTENANCE

WARRANTY

S28240

PAIR

Need help?

Do you have a question about the S28240 and is the answer not in the manual?
