DESCRIPTION
Steel Structure
Powder coated
CONFORM
The assembly time for tennis umpire chair is estimated at 30 minutes with 1 people.
The equipement has to be regularly maintained by the owner. It is adviced to:
- Check every week that all the screws are correctly tightened.
- Fix paint defects if the module has been damaged, using the adapted paint, specified by the
manufacturer.
- Replace all damaged or missing parts with a spare part recommended by the manufacturer.
- Clean the product by using dishwasher soap, clean water, and soft cloth.
One full year parts and labor guarantee. Every claim regarding condition of the delivered equipment has
to be done within the legal period of the reception of the material. The warranty will not apply to:
-
All degradation during the transport.
-
All degradation due to use differing from which was intended.
-
All degradation due to poor maintenance.
-
Any defect claimed after the end of the legal period.
-
Any damaged due to a faulty installation and assembly of the module.
Assembly INSTRUCTIONS
TABLE TENNIS UMPIRE CHAIR
PRODUCT REF
ASSEMBLY TIME
MAINTENANCE
WARRANTY
S29350
UNIT
1 1
Advertisement
Table of Contents
Related Manuals for Sodex Sport S29350
Summary of Contents for Sodex Sport S29350
- Page 1 ASSEMBLY INSTRUCTIONS TABLE TENNIS UMPIRE CHAIR S29350 UNIT PRODUCT REF DESCRIPTION Steel Structure Powder coated CONFORM ASSEMBLY TIME The assembly time for tennis umpire chair is estimated at 30 minutes with 1 people. MAINTENANCE The equipement has to be regularly maintained by the owner. It is adviced to: - Check every week that all the screws are correctly tightened.
- Page 2 ASSEMBLY NECESSARY TOOLS (NOT INCLUDED) Wrench 13mm Wrench 17mm Screwer INCLUDED ITEMS 1– ASSEMBLY OF THE MAIN FRAME Screws BC M8x20 + Screws BC M8x40 + Washers BC 8 + Washers BC 8 + Locknuts BC M8 Locknuts BC M8 Screws BC M8x20 + Washers BC 8 + Locknuts BC M8...
- Page 3 ASSEMBLY 2 – ASSEMBLY OF THE DESK It’s possible to choose the orientation of the desk, so we can place either the red side upwards or the white side. If you want to place the red side upwards, fix the PVC hook on the other side (white)n using the self-tapping screws, respecting the dimensions above.
- Page 4 ASSEMBLY 3– ASSEMBLY OF THE FIXING LUG, THE SEAT AND THE FEET Screws 5x15 Screws BC M10x50 + Washers BC 10+ Locknuts BC M10 PVC swivel feet M10+ Rubber protection NECESSARY ITEMS...
- Page 5 PACKING LIST TABLE TENNIS UMPIRE CHAIR PRODUCT REF S29350 Index C UNIT NOMENCLATURE Package Weight Dim. Index Designation Description Quantity Packing method N° (kg) (mm) S29350-01 Right Frame + left frame S29350-02 Desk Plastic bubbles + cardboard 5 1000x650x300 layers...
