Murata Cat-M1/NB-IoT User Manual

Lte evk

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Revision History

Revision

1.0

1.1

1.2

Murata LTE-M EVK User Guide, 5/4/2020

Date

Change Description

01/31/2020

Initial version for new Type1SC/Type1WG EVB with printed antenna

02/26/2020

Minor updates including email contact

4/7/2020

Fixed ToC error

Page 1 of 44

Type1SC/Type1WG

Type1SC-DM

EVK User Guide

LTE CAT-M1 /

NB-IoT EVK

www.murata.com

Table of Contents

Need help?

Do you have a question about the Cat-M1/NB-IoT and is the answer not in the manual?

Questions and answers

Summary of Contents for Murata Cat-M1/NB-IoT

Page 1: Revision History
Initial version for new Type1SC/Type1WG EVB with printed antenna 02/26/2020 Minor updates including email contact 4/7/2020 Fixed ToC error Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 2020 Murata LTE-M EVK User Guide, 5/4/2020 Page 1 of 44 www.murata.com...
Page 2: Table Of Contents
8.4 Making the PPP connection ............................. 28 CURRENT MEASUREMENT ............................32 FIRMWARE UPGRADE ............................... 33 EVK SCHEMATICS ..............................34 Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 2020 Murata LTE-M EVK User Guide, 5/4/2020 Page 2 of 44 www.murata.com...
Page 3 12.1 Disposal of this product in the European Union ....................... 43 12.2 Disposal of this product in other countries outside the European Union ..............43 ACRONYMS ................................. 44 Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 2018 Type 1SC EVK User Guide, v1.3, 5/4/2020 Page 3 of 44...
Page 4 Figure 1 Evaluation Board with Type1SC (top) and Type1WG (bottom) ................5 Figure 2 Murata LTE module development kit contents ......................6 Figure 3 Murata LTE module evaluation board (top view) ...................... 7 Figure 4 Murata LTE module evaluation board (bottom view) ....................8 Figure 5 Power supply block diagram .............................
Page 5: Introduction
Please ensure that the board is the correct version prior to using this document. In the ensuing discussion, Murata LTE module refers to the module mounted on the evaluation board, so it could be either Type1SC or Type1WG.
Page 6: Audience
1.2 Audience This document is intended for software/firmware, hardware and systems engineers to evaluate and develop applications with Murata’s Type1SC and Type1WG LTE Cat M1/NB-IoT modules. 1.3 Contact Info and Support For general contact, technical support services, technical questions and report documentation errors contact Murata Technical Support at: ciotsupport@murata.com.
Page 7: Description
2 DESCRIPTION The EVK is an evaluation and application development kit for the Murata Type1SC and Type1WG LTE modules. It includes an Evaluation Board (EVB) with an Arduino shield interface which allows the EVB to be used across various Arduino based MCU development platforms such as the STM32 Nucleo-64 boards.
Page 8: Figure 4 Murata Lte Module Evaluation Board (Bottom View)
Connect ANT_SEL to GND – select SMA path Table 1 Default CN11 connections The nominal EVB physical dimensions are as shown below. Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 2018 Type 1SC EVK User Guide, v1.3, 5/4/2020 Page 8 of 44...
Page 9: Power Supply
EVB. The mini-USB connector locations are as shown below in Figure 6. Figure 6 USB connectors location Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 2018 Type 1SC EVK User Guide, v1.3, 5/4/2020 Page 9 of 44...
Page 10: External 5V Supply
UART A & C (CN13) are used for CLI and debugging. See Sections 7.4 for more details. Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 2018 Type 1SC EVK User Guide, v1.3, 5/4/2020 Page 10 of 44...
Page 11: Indication And Services
The EVB has four push buttons which can be used to reset the module or place it in recovery mode. Figure 10 Button locations on EVB Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 2018 Type 1SC EVK User Guide, v1.3, 5/4/2020 Page 11 of 44 www.murata.com...
Page 12: Reset Operation
While the module is in sleep mode, press and hold SW2 to wake it up. Pressing SW2 is only necessary if a PC terminal is not connected to the Murata module through the USB via CN14. Otherwise, the CTS signal from that USB-UART connection will keep the module awake.
Page 13: Expansion Headers
Signal with (0Ω) is connected by default, but can be disconnected by removing the 0Ω resister Signal Pin# Level Direction Description IO_REF IOREF I MCU IO voltage reference Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 2018 Type 1SC EVK User Guide, v1.3, 5/4/2020 Page 13 of 44 www.murata.com...
Page 14: Table 5 Expansion Headers Pinout: Cn3 + Cn4
Optional level shifted signal to wakeup module PMU_POWER_BUTTON_IO IOREF Level shifted Modem power button Table 6 Expansion headers pinout: CN10 + CN9 Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 2018 Type 1SC EVK User Guide, v1.3, 5/4/2020 Page 14 of 44 www.murata.com...
Page 15: Startup Procedure
(e.g. COM8, 921600 baud), one for CLI (e.g. COM9, 115200 baud), and one for AT (COM13, 115200 baud). See below an example screenshot of the Device Manager. Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 2018 Type 1SC EVK User Guide, v1.3, 5/4/2020 Page 15 of 44 www.murata.com...
Page 16: At/Ppp Port
(See Section 7.4 for details). Figure 13 PuTTY configuration for AT port Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 2018 Type 1SC EVK User Guide, v1.3, 5/4/2020 Page 16 of 44...
Page 17: At Commands
Open PuTTY to the CLI port. The following screenshot shows how to save the configuration as “COM9” for later use. Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 2018 Type 1SC EVK User Guide, v1.3, 5/4/2020 Page 17 of 44...
Page 18: Cli Commands
All supported CLI commands can be seen with the “help” command. The “help” command lists categories of CLI commands. Use “help <category>” to see commands under a particular category. Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 2018 Type 1SC EVK User Guide, v1.3, 5/4/2020 Page 18 of 44 www.murata.com...
Page 19: Sending At Commands From Cli Channel
Connect both CLI and AT port from the EVB to PC. Use PuTTY to connect to CLI port to make sure the modem is in application mode (“>” prompt is shown). Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 2018 Type 1SC EVK User Guide, v1.3, 5/4/2020 Page 19 of 44 www.murata.com...
Page 20: Creating A Modem
The “Add Hardware Wizard” displays. Figure 18 ‘Add New Hardware Wizard’ 2. Click ‘Next’ to go to the next screen. Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 2018 Type 1SC EVK User Guide, v1.3, 5/4/2020 Page 20 of 44...
Page 21: Figure 19 Next Screen
Figure 20 Modem Selection 4. Ensure there is no PuTTY session connected to the AT port. Click ‘Next’ to select the AT port. Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 2018 Type 1SC EVK User Guide, v1.3, 5/4/2020 Page 21 of 44 www.murata.com...
Page 22: Figure 21 Click Selected Ports
5. Click “Next”, then the “Finished” button. A screen like the following would be shown. Figure 22 Modems Installed 6. Click “Properties”. The Device Status screen is then shown. Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 2018 Type 1SC EVK User Guide, v1.3, 5/4/2020 Page 22 of 44...
Page 23: Creating Ppp Connection Entry
8. Click ‘OK’ twice on the modem window to complete the setup. 8.2 Creating PPP connection entry 1. Go to ‘Control Panel’ and type in ‘dial-up’ in the search bar. Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 2018 Type 1SC EVK User Guide, v1.3, 5/4/2020 Page 23 of 44...
Page 24: Figure 24 Accessing Dial-Up Connection
‘Skip’ to stop the connection. A dialog similar to the following should be shown: 4. Click ‘Close’ to go to the next step. Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 2018 Type 1SC EVK User Guide, v1.3, 5/4/2020 Page 24 of 44...
Page 25: Figure 26 Connection Is Ready
Figure 27 Set Connection Anyway 6. Open ‘Network and Sharing Center’ under control panel and select ‘Change adapter settings’. Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 2018 Type 1SC EVK User Guide, v1.3, 5/4/2020 Page 25 of 44...
Page 26: Figure 28 Access For Change Adapter Settings
Figure 28 Access for Change Adapter Settings Figure 29 Change Adapter Settings 7. Right click on the ‘PPP’ connection and select ‘Properties’. Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 2018 Type 1SC EVK User Guide, v1.3, 5/4/2020 Page 26 of 44...
Page 27: Establishing The Lte Connection
Insert the SIM card, reset the EVB, wait until LTE connection is established. The CLI console can be used to view the LTE connection process, as shown below. Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 2018 Type 1SC EVK User Guide, v1.3, 5/4/2020 Page 27 of 44 www.murata.com...
Page 28: Making The Ppp Connection
1. Open PuTTY on AT port, enter ‘at&k3’ to enable HW flow control, and then close PuTTY. Figure 32Enabling hardware control Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 2018 Type 1SC EVK User Guide, v1.3, 5/4/2020 Page 28 of 44...
Page 29: Figure 33 Ppp Connection - Network Connections Panel
4. In Windows 10, a popup screen similar to that shown below may appear at the lower right corner. Figure 34 Windows 10 Pop-Up Screen 5. Click on ‘PPP’. Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 2018 Type 1SC EVK User Guide, v1.3, 5/4/2020 Page 29 of 44 www.murata.com...
Page 30: Figure 35: Click "Ppp
Figure 35: Click “PPP” 6. Select the ‘PPP’ connection under ‘Dial-up’ then click on ‘Connect’ Figure 36 Connect “PPP” Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 2018 Type 1SC EVK User Guide, v1.3, 5/4/2020 Page 30 of 44...
Page 31: Figure 37 Options
‘Prompt for name and password…’ and then press OK. Figure 37 Options 8. Click ‘Dial’. The CLI console should show PPP connection. Figure 38 PPP Connection Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 2018 Type 1SC EVK User Guide, v1.3, 5/4/2020 Page 31 of 44 www.murata.com...
Page 32: Current Measurement
• The LTE connection can be either to a tester such as CMW500 or to the live network The supply must be in the range of 3.2V to 4.2V and capable of delivering 1A of current. Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 2018 Type 1SC EVK User Guide, v1.3, 5/4/2020 Page 32 of 44 www.murata.com...
Page 33: Firmware Upgrade
Some PCs might have a hard time running at 3000000 if so try changing the Baud Rate to 921600. Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 2018 Type 1SC EVK User Guide, v1.3, 5/4/2020 Page 33 of 44...
Page 34: Evk Schematics
The firmware will take several minutes to upgrade, but there is no other input required from the user. 11 EVK Schematics Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 2018 Type 1SC EVK User Guide, v1.3, 5/4/2020 Page 34 of 44...
Page 43 This symbol is only valid in the European Union (EU). If you wish to discard this product please contact your local authorities or dealer and ask for the correct method of disposal. Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 2018 Type 1SC EVK User Guide, v1.3, 5/25/2018 Page 43 of 44 www.murata.com...
Page 44 UART Universal Asynchronous Receiver Transmitter VBAT Voltage of the Battery u.FL A type of RF connector Input Voltage Copyright © Murata Manufacturing Co., Ltd. All rights reserved. 2018 Type 1SC EVK User Guide, v1.3, 5/4/2020 Page 44 of 44 www.murata.com...
