1.8.2 Example: RX15xx Services and WAN Networking
user or automatically by a pre-configured DHCP server, to allow it to communicate on
VLAN1. It has also been assigned a unique subnet to its ETH1 port.
The RUGGEDCOM APE1808 can also access services and network management of the
RUGGEDCOM RX1500 control module at its 192.168.0.2 address. These services in-
clude SSH, HTTP and HTTPS services for network management, DHCP, NTP and TCP
connections to chassis serial ports.
The RUGGEDCOM APE1808 can also communicate with any hosts on interfaces
lm-2-1 through lm-2-4.
Should you wish to configure the RUGGEDCOM APE1808 to forward traffic
through to the 192.168.1.0/24 network via fe-cm-1, you would need to configure
192.168.0.2 as a default gateway.
For much the same reason, should you wish to forward traffic arriving on fe-cm-1
through to the 172.16.0.0/16 network via the RUGGEDCOM APE1808, you would
need to configure a route for it on the RUGGEDCOM RX15xx device and enable IP for-
warding from the Windows or Linux operating system.
Note
When operating the RUGGEDCOM APE1808 in either switch or router mode, the
RUGGEDCOM RX15xx will issue RSTP BPDUs to the RUGGEDCOM APE1808.
If you do not wish the RUGGEDCOM APE1808 to receive these BPDUs, they may be
disabled in RUGGEDCOM RUGGEDCOM APE1808 in the interface switch menu for the
RUGGEDCOM APE1808 interface.
1.8.2
Example: RX15xx Services and WAN Networking
The following illustration shows how the RUGGEDCOM APE1808 might be used in a
more complex situation in which it is routed as opposed to bridged. The use of inter-
nal serial ports, firewalls, and port forwarding is discussed.
8
RUGGEDCOM APE1808
Configuration Manual, 11/2019, C79000-G8976-1415-03
