Maintenance Manual
PIM Master™
MW8208A, MW8209A, MW8219A
Passive InterModulation Analyzer
MW8208A: 869 MHz to 894 MHz
MW8209A: 925 MHz to 960 MHz
MW8219A: 1930 MHz to 1930 MHz and 2110 MHz to 2155 MHz
Anritsu Company
Part Number: 10580-00283
490 Jarvis Drive
Revision: D
Morgan Hill, CA 95037-2809
Published: December 2011
USA
Copyright 2011 Anritsu Company

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PIM Master MW8208A and is the answer not in the manual?

Questions and answers

Related Manuals for Anritsu PIM Master MW8208A

Summary of Contents for Anritsu PIM Master MW8208A

  • Page 1 MW8208A: 869 MHz to 894 MHz MW8209A: 925 MHz to 960 MHz MW8219A: 1930 MHz to 1930 MHz and 2110 MHz to 2155 MHz Anritsu Company Part Number: 10580-00283 490 Jarvis Drive Revision: D Morgan Hill, CA 95037-2809 Published: December 2011 Copyright 2011 Anritsu Company...
  • Page 3 Some or all of the following five symbols may or may not be used on all Anritsu equipment. In addition, there may be other labels attached to products that are not shown in the diagrams in this manual.
  • Page 4 For Safety Warning Always refer to the operation manual when working near locations at which the alert mark, shown on the left, is attached. If the operation, etc., is performed without heeding the advice in the operation manual, there is a risk of personal injury.

  • Page 5: Table Of Contents

    Related Documents ............1-3 Anritsu Customer Service Centers .
  • Page 6 Table of Contents (Continued) PN: 10580-00283 Rev. D MW8208A, MW8209A, MW8219A MM...

  • Page 7: Chapter 1-General Information

    Chapter 1 — General Information The Anritsu PIM Master is capable of producing up to 100 Watts of RF power in the cellular communications bands. Users must take precautions to minimize exposure to these RF fields: Always terminate the output port of the test equipment into a load, a loaded line, or a line that will radiate or absorb the energy before beginning a PIM test.

  • Page 8: Product Description

    (PIM). The PIM Master generates two high-power tones in the transmit band of a base station, and the Anritsu family of PIM Master compatible handheld RF instruments (refer to...

  • Page 9: Optional Accessories

    01-512 1 inch, 25 N·m, Torque wrench 01-513 1.25 inch, 25 N·m, Torque wrench Related Documents Other documents are available for the PIM Master at the Anritsu Web site at: www.anritsu.com: • PIM Master User Guide, part number: 10580-00280 • PIM Master Product Brochure, part number: 11410-00546 •...

  • Page 10: Recommended Test Equipment

    Power Meter Power Range: –70 to +20 dBm Anritsu Model ML2438A Power Sensor Frequency: 100 kHz to 18 GHz Anritsu Model MA2421D or SC7400 Power Range: –67 dB to +20 dB (Quantity 1) Spectrum Analyzer Frequency: 3 GHz Anritsu Model MT8212E or...

  • Page 11: Chapter 2-Pim Analyzer Verification

    Chapter 2 — PIM Analyzer Verification The Anritsu PIM Master is capable of producing up to 100 Watts of RF power in the cellular communications bands. Users must take precautions to minimize exposure to these RF fields: Always terminate the output port of the test equipment into a load, a loaded line, or a line that will radiate or absorb the energy before beginning a PIM test.

  • Page 12: Reference Pim Measurement

    • PIM Master, Model MW8208A or Model MW8209A or Model MW8219A Procedure 1. Confirm that all of the connectors are clean because any debris or contamination may cause incorrect PIM measurement results. Connect the PIM Master to the Anritsu Handheld instrument Controller as shown in Figure 2-1.
  • Page 13 Before continuing, allow a 30-minute warm up for the internal circuitry to stabilize. Caution 7. On the Controller (Anritsu Handheld instrument), press the Freq main menu key and verify that the values for Carrier F1 and Carrier F2 are as indicated in the table below.

  • Page 14: Frequency Accuracy And Output Power

    • Power Sensor, Anritsu Model MA2482D or equivalent • “Test Component” from above consisting of: • Fixed Attenuator, 30 dB, 50 W, Anritsu Model 3-1010-123 • Adapter, 7/16 DIN(f) to N(m), Anritsu Model 1091-386-R • PIM Test Cable, Anritsu Model 2000-1626-R •...
  • Page 15 Chapter 2 — PIM Analyzer Verification 2-3 Frequency Accuracy and Output Power 8. Calculate the Test Component Correction Factor by subtracting the value of Power Reading from Signal Generator from the value of Power Reading with Test Component. Record this calculation Table A-2.

  • Page 16: Frequency Accuracy And Output Power Verification

    • BNC Tee Jack-Plug-Jack, Amphenol 31-208 • “Test Component” from above consisting of: • Fixed Attenuator, 30 dB, 50 W, 50 Ω, Anritsu Model 3-1010-123 • Adapter, 7/16 DIN(f) to N(m), Anritsu Model 1091-386-R • PIM Test Cable, Anritsu Model 2000-1626-R •...
  • Page 17 Chapter 2 — PIM Analyzer Verification 2-3 Frequency Accuracy and Output Power 14. On the Ref SPA, press the Amplitude main menu key, then press the Reference Level submenu key. Enter 20 and then press the dBm submenu key. Press the Scale submenu key, enter 7, and then press the dB/Div submenu key.

  • Page 18: Residual Pim Measurement

    • PIM Master, Model MW8208A or Model MW8209A or Model MW8219A Procedure Follow this entire procedure for each instrument that you test. 1. Connect the PIM Master to the Anritsu Handheld (HH) Controller as shown in Figure 2-1 on page 2-2.

  • Page 19: Chapter 3-Troubleshooting

    Chapter 3 — Troubleshooting The Anritsu PIM Master™ is capable of producing up to 100 Watts of RF power in the cellular communications bands. Users must take precautions to minimize exposure to these RF fields: Always terminate the output port of the test equipment into a load, a loaded line, or a line that will radiate or absorb the energy before beginning a PIM test.

  • Page 20: Operating Problems

    11. PIM Reference LO Lock Error - Reference LO unable to lock. Measurement results may be invalid. 12. PIM External Reference Error – The Anritsu handheld instrument can not lock onto the reference signal from the PIM Master and switches to its own internal frequency reference.
  • Page 21 Continuing to document this process with each performance verification session provides a detailed history of the instrument performance. The Anritsu PIM Master™ is capable of producing up to 100 Watts of RF power in the cellular communications bands. Users must take precautions to minimize exposure to these RF fields: Always terminate the output port of the test equipment into a load, a loaded line, or a line that will radiate or absorb the energy before beginning a PIM test.

  • Page 22: Appendix A-Test Records A-1 Introduction

    A-2 Reference PIM Measurement Appendix A — Test Records MW82__A Firmware Rev: ______________ Operator: ____________________ Date: _____________ Serial Number: _______________ Options: ___________________________________________________ Reference PIM Measurement Table A-1. Reference PIM Measurement with –80 dBm PIM Standard PIM Master PIM Frequency Specification Measurement Reading MW8208A 848 MHz...

  • Page 23: Output Tone Frequency Differential

    Appendix A — Test Records A-3 Frequency Accuracy and Output Power MW82__A Firmware Rev: ______________ Operator: ____________________ Date: _____________ Serial Number: _______________ Options: ___________________________________________________ Frequency Accuracy and Output Power (continued) Output Tone Frequency Differential Table A-5. PIM Output Tone Frequency Accuracy Tone PIM Master Frequency...

  • Page 24: Residual Pim Measurement

    A-4 Residual PIM Measurement Appendix A — Test Records MW82__A Firmware Rev: ______________ Operator: ____________________ Date: _____________ Serial Number: _______________ Options: ___________________________________________________ Residual PIM Measurement Table A-7. Residual PIM Measurement Carrier Frequencies PIM Master (F1 and F2) Tolerance Measurement Reading MW8208A 869 MHz and 894 MHz >...
  • Page 25 Appendix A — Test Records A-4 Residual PIM Measurement MW82__A Firmware Rev: ______________ Operator: ____________________ Date: _____________ Serial Number: _______________ Options: ___________________________________________________ MW8208A, MW8209A, MW8219A MM PN: 10580-00283 Rev. D...
  • Page 26 A-4 Residual PIM Measurement Appendix A — Test Records MW82__A Firmware Rev: ______________ Operator: ____________________ Date: _____________ Serial Number: _______________ Options: ___________________________________________________ PN: 10580-00283 Rev. D MW8208A, MW8209A, MW8219A MM...

  • Page 27: Index

    ..... . . 1-3 Anritsu part numbers 10580-00244 SPA MG ....1-3 recommended test equipment .
  • Page 28 Index-2 PN: 10580-00283 Rev. D MW8208A, MW8209A, MW8219A MM...
