Page 1 FOLLOW Safety internet Operation Instructions contained www.algqr.com/sve in this manual before operating the equipment. C01-Cover_S Schulte Industries Ltd. PO Box 70 Englefeld Saskatchewan Canada S0K 1N0 Tel. (306) 287-3715 Fax. (306) 287-3355 Parts Fax. (306) 287-4066 Web: www.schulte.ca $0.00...
Page 3 In order to reduce accidents and enhance the safe operation of mowers, Schulte, in cooperation with other industry manufacturers has developed the AEM/FEMA Industrial and Agricultural Mower Safety Practices video and guide book. The video will familiarize and instruct mower-tractor operators in safe practices when using industrial and agricultural mowing equipment.
Page 4 Schulte Industries LTD. is willing to provide one (1) AEM Mower Safety Practices Video Please Send Me: VHS Format – AEM/FEMA Mower Operator Safety Video DVD Format – AEM/FEMA Mower Operator Safety Video Mower Operator’s Manual AEM Mower Operator’s Safety Manual...
Page 5 A Manual canister is provided on the implement where this manual can be properly stored. If you lose or damage this manual a free replacement manual can be obtained from an authorized Schulte dealer or www.schulte.ca...
Page 6 DEALER to CUSTOMER Pre-Delivery/ Operation Instructions Dealer should inform the Purchaser of this product of Warranty terms, provisions, and procedures that are applicable. Dealer should inform Purchaser to review the contents of the Operator’s Manual including safety equipment, safe operation and maintenance, to review the Safety Signs on the implement (and tractor if possible) and of Purchaser’s responsibility to train his/her operators’s of safe operation procedures.
Page 7: Table Of Contents
Table of Contents SAFETY SECTION ..................1-1 GENERAL SAFETY INSTRUCTIONS AND PRACTICES ................1-2 OPERATOR SAFETY ............................1-3 CRUSHING HAZARDS ............................. 1-4 CONNECTING OR DISCONNECTING IMPLEMENT SAFETY ................ 1-5 THROWN OBJECTS HAZARDS ........................1-6 RUN OVER HAZARDS ............................1-8 PTO ENTANGLEMENT HAZARDS ........................1-9 MOWER BLADE CONTACT HAZARDS ......................
Page 8 Boarding the Tractor ............................4-7 Dismounting the Tractor ............................4-8 STARTING THE TRACTOR ..........................4-8 CONNECTING THE MOWER TO THE TRACTOR ...................4-9 SETTING THE MOWER ..........................4-11 Setting Mowing Height-Lift Type ........................4-11 Setting Deck Pitch-Lift Type ..........................4-12 DRIVELINE ATTACHMENT ..........................4-12 PRE-OPERATION INSPECTION AND SERVICE ...................4-13 Tractor Pre-Operation Inspection/Service ......................4-14 Mower Pre-Operation Inspection/Service ......................4-14 Cutting Component Inspection .........................4-17...
Page 9 STORAGE ...............................5-22 PROPER TORQUE FOR FASTENERS ......................5-22 NUTS & BOLTS ............................... 5-23...
Page 12: General Safety Instructions And Practices
NOTE: If you want a translation of this safety section in one of the following Languages, please contact: Translations at 1502 E. Walnut Street Seguin, TX 78155; Fax: (830) 372-9529; Safety Section Translations are available in Spanish, Portuguese, French, German, Russian. PN GS-01 TPX-318 02/21 Safety Section 1-2 © 2021 Alamo Group Inc.
Page 13: Operator Safety
DO NOT EXCEED IMPLEMENT RATED PTO SPEED • AVOID exceeding rated PTO speeds that may result in broken drivelines or blade failures. SAFETY SIGNS: • REPLACE missing, damaged or unreadable safety signs immediately. PN OS01 TPX-318 02/21 Safety Section 1-3 © 2021 Alamo Group Inc.
Page 14: Crushing Hazards
ATTACH hoses to tractor. FILL Wing Cylinders with oil. (Refer to Instructions in Operation Section) • • KEEP bystanders away before operating wings. LOWER WINGS slowly and carefully. • PN CH01 TPX-318 02/21 Safety Section 1-4 © 2021 Alamo Group Inc.
Page 15: Connecting Or Disconnecting Implement Safety
KEEP bystanders clear of area before operating wings. • LOWER WINGS slowly and carefully. DO NOT connect the Mower to a tractor with the PTO directly connected to the Tractor transmission. PN CD01 TPX-318 02/21 Safety Section 1-5 © 2021 Alamo Group Inc.
Page 16: Thrown Objects Hazards
3. INSPECT AREA thoroughly before mowing to REMOVE potential THROWN OBJECT HAZARDS, 4. NEVER ALLOW BLADES to CONTACT SOLID OBJECTS like wire, rocks, post, curbs, guardrails, or ground while mowing. PN TO01 TPX-318 02/21 Safety Section 1-6 © 2021 Alamo Group Inc.
Page 17 STOP mowing when EXCESSIVE VIBRATION occurs: 1. STOP PTO and tractor ENGINE. 2. INSPECT mower for vibration source. 3. REPLACE any damage parts and bent or damaged BLADES. PN TO01-X TPX-318 02/21 Safety Section 1-7 © 2021 Alamo Group Inc.
Page 18: Run Over Hazards
ONLY mount or dismount when tractor and moving parts are stopped. • • STOP ENGINE AND PTO, engage parking brake, lower implement, allow all moving parts to stop and remove key before dismounting from tractor. PN RO01 TPX-318 02/21 Safety Section 1-8 © 2021 Alamo Group Inc.
Page 19: Pto Entanglement Hazards
DO NOT USE PTO ADAPTER. • Using a PTO adapter can cause excessive vibration, thrown objects, blade and implement failures by doubling operating speed. Increased working length exposes unshielded driveline areas. PN PE01 TPX-318 02/21 Safety Section 1-9 © 2021 Alamo Group Inc.
Page 20: Mower Blade Contact Hazards
Be sure to keep feet and hands clear of the mower blades. If you raise the mower or mower wing to access the blockage, engage the wing lock up latch and securely block up the mower before placing any parts of the body beneath the mower. PN MB01 TPX-318 02/21 Safety Section 1-10 © 2021 Alamo Group Inc.
Page 21: High Pressure Oil Leak Hazard
KEEP AWAY • Injected Hydraulic fluid may cause gangrene if not surgically removed immediately by a doctor familiar with this form of injury. PN HP01 TPX-318 02/21 Safety Section 1-11 © 2021 Alamo Group Inc.
Page 22: Electrical & Fire Hazards
ADJUST SLIP CLUTCHES to avoid excessive slippage and clutch plate heating. • CLEAR any grass clippings or debris buildup around mower drivelines, slip clutches, and gearboxes. SHUT OFF ENGINE while refueling. • PN EF01 TPX-318 02/21 Safety Section 1-12 © 2021 Alamo Group Inc.
Page 23: Transporting Hazards
TURN ON tractor FLASHING WARNING LIGHTS. • ALLOW clearance for implement swing while turning. KEEP all raised wings at 10 feet or greater distance from all power lines and overhead obstructions. PN TH01 TPX-318 02/21 Safety Section 1-13 © 2021 Alamo Group Inc.
Page 24: Hazards With Maintenance Of Implement
DO NOT modify or alter implement, functions or components. • DO NOT WELD or repair rotating mower components. These may cause vibrations and component failures being thrown from mower. PN HM02 TPX-318 02/21 Safety Section 1-14 © 2021 Alamo Group Inc.
Page 25: Hazards With Maintenance Of Implement - (Continued)
Side Skirts and Skid Shoes in place and in good condition. REPLACE any missing, broken or worn safety shields, guards and safety devices. • Cancer and Reproductive Harm www.P65Warnings.ca.gov PN HM02-A TPX-318 02/21 Safety Section 1-15 © 2021 Alamo Group Inc.
Page 26 These parts are made and tested to Schulte Industry specifications. Non-genuine "will fit" parts do not consistently meet these specifications. The use of “will fit” parts may reduce the performance, void Schulte warranties, and present a safety hazard. Use genuine Schulte parts for economy and safety.
Page 27: Decal Location
SAFETY Decal Location NOTE: Schulte supplies safety decals on this product to promote safe operation. Damage to the decals may occur while in shipping, use, or reconditioning. Schulte cares about the safety of its customers, operators, and bystanders, and will replace the safety decals on this product in the field, free of charge (Some shipping and handling charges may apply).
Page 28 FEMA Member 226-081 IMPORTANT Check Oil Level 226-088 INFORMATION 1000 RPM 226-100 SERIAL PLATE Serial Plate 226-117 LOGO Schulte, Medium Profile 226-153 REFLECT Red Reflector 2”x9” 226-1541 REFLECT Amber Reflector 2”x 4-1/2” 226-160 WARNING Timed Blades 226-164 WARNING Blade Rotation, CW...
Page 37: Federal Laws And Regulations
Some regulations specify that no one under the age of 16 may operate power machinery. It is your responsibility to know what these regulations are in your own area or situation. (Refer to U.S. Dept. of Labor, Employment Standard Administration, Wage & Home Division, Child Labor Bulletin #102.) TPX-318 02/21 Safety Section 1-27 © 2021 Alamo Group Inc.
Page 40 INTRODUCTION We are pleased to have you as a Schulte customer. Your Rotary Cutter has been carefully designed with care and built with quality materials by skilled workers to give maximum service with minimum down time. This manual is provided to give you the necessary operating and maintenance instructions for keeping your rotary cutter in top operating condition.
Page 41 INTRODUCTION The TPX-318 Rotary Cutter is an 18’ Three Point Hitch Rigid/Flex Wing Mower. • Fixed knives and shrouding for optimum shredding performance and distribution when doing residue management in row crops like corn. cotton, and sugar cane. • Adjustable wheel standards for shredding in virtually all row crop spacing.
Page 42: Equipment Specifications
OEM of the Agricultural tractor used to power and transport this machine would be valid when this machine is attached to and operated by that Agricultural tractor in all OEM recommended applications. TPX-318 02-21 Introduction Section 2-4 © 2021 Alamo Group Inc.
Page 43 GENERAL STATEMENT AFFECTING ALL SCHULTE WARRANTY Schulte Industries Ltd. warrants to the original purchaser only, that in the event of any defect in material or workmanship in the product sold by Schulte Industries, the subject of this warranty (“the goods”) during the warranty period mentioned below the manufacturer will provide the coverage specified below.
Page 44 • The Dealer must keep the failed part until the claim is processed, to allow Schulte Industries the option of further examination of the part. Further examination may mean that pictures are sent, or that the part be returned to Schulte.
Page 46: General Assembly
To change timing disconnect the driveline between the center and wing gearboxes and rotate the pan to the proper location. Blade rotation shown below is depicted from the top of the unit. Category Configurations TPX-318 02/21 Assembly Section 3-2 © 2021 Alamo Group Inc.
Page 47: Wheel Arm Installation
Space the wheel arms as wide as possible to meet your specifications and secure the top clap plate. Adjust arm position as needed before tightening bolts. Torque all bolts and re-torque to confirm both sides of the clamps are secure. See row crop spacing or more details. TPX-318 02/21 Assembly Section 3-3 © 2021 Alamo Group Inc.
Page 48: Row Crop Spacing
Row Crop Spacing TPX-318 has adjustable wheel standards so it can be use in Row Crop. Adjust the wheel standards to the following dimensions according to your row width. All dimensions are from the end of beam to the outer edge of the wheel standard clamp plate as shown.
Page 50: Chain Guards
Parts Manual for a complete list of fittings and hydraulic hoses. Never force the Wing Lift Lock Pins out of their lock position as the wings may suddenly drop causing injury or even death. TPX-318 02/21 Assembly Section 3-6 © 2021 Alamo Group Inc.
Page 51: Connection To Tractor, 3-Point Unit
Connection to Tractor, 3-Point Unit The TPX-318 is equipped with a Cat 2 Quick Hitch, Cat 3, Cat 3 QH, Cat 4, Cat 4 QH When first connecting the universal joint shaft to the tractor slowly raise and lower the unit to ensure that there is adequate slip range for the power shaft.
Page 52: Transport Light Kit
If the turning lamps are opposite to the tractor, reverse the output to extension harness connections. If the lights do not work at all, check all connections are snug. TPX-318 02/21 Assembly Section 3-8 © 2021 Alamo Group Inc.
Page 54 Pictures contained in this section are intended to be used as a visual aid to assist in explaining the operation of rotary cutter and are not necessarily of a TPX-318 cutter. Some pictures may show shields removed for picture clarity. NEVER OPERATE this implement without all shields in place and in good operational condition.
Page 55: Standard Equipment And Specifications
Front tractor weight kits may be required to ensure a minimum of 20% of total tractor weight is on front tires to maintain steering control ant to prevent the front of the tractor for rearing up during operation. OPTIONS: 1-3/8 Z21 or 1-3/4 Z20 Tractor Shaft Belting on Front or Rear TPX-318 02/21 Operation Section 4-3 © 2021 Alamo Group Inc.
Page 56: Operator Requirements
Serious injury or death to the operator or others could result if the operator is under the influence of drugs or alcohol. (SG-27) TPX-318 02/21 Operation Section 4-4 © 2021 Alamo Group Inc.
Page 57: Tractor Requirements
Never operate the tractor PTO with the PTO master shield missing or in the raised position. OPS-U- 0004 TPX-318 02/21 Operation Section 4-5 © 2021 Alamo Group Inc.
Page 58: 3-Point Hitch-Lift Type Mower
3.6 Power Take Off (PTO) The TPX-318 mower is designed to operate at a PTO speed of 1000 RPM. Most tractors operate at either 540, or a combination of 540 and 1000 RPM PTO speeds. The tractor PTO operating speed can be determined by the number of splines on the PTO output shaft.
Page 59: Getting On And Off The Tractor
(SG-11) Never allow children or other persons to ride on the Tractor or Implement. Falling off can result in serious injury or death. (SG-10) TPX-318 02/21 Operation Section 4-7 © 2021 Alamo Group Inc.
Page 60: Dismounting The Tractor
Never bypass the ignition switch by short circuiting the starter solenoid. After the tractor engine is running, avoid accidental contact with the tractor transmission to prevent sudden and unexpected tractor movement. OPS-U-0028 TPX-318 02/21 Operation Section 4-8 © 2021 Alamo Group Inc.
Page 61: Connecting The Mower To The Tractor
Always shut the Tractor completely down, place the transmission in park, and set the parking brake before you or anyone else attempts to connect or disconnect the Implement and Tractor hitches. (S3PT-15) TPX-318 02/21 Operation Section 4-9 © 2021 Alamo Group Inc.
Page 62 8. Adjust any lower link check chains, guide blocks, or sway blocks to prevent the mower from swaying side to side and possible contact with tractor rear tires. TPX-318 02/21 Operation Section 4-10 © 2021 Alamo Group Inc.
Page 63: Setting The Mower
7. Adjust the wheel arm heights by using the adjusting plates. Remove red lock up pin. Set to desired height. Replace red lock up pin and secure with quick pin. Repeat in all 4 locations. TPX-318 02/21 Operation Section 4-11 © 2021 Alamo Group Inc.
Page 64: Setting Deck Pitch-Lift Type
Always shut the Tractor completely down, place the transmission in park, and set the parking brake before you or anyone else attempts to connect or disconnect the Implement and Tractor hitches. (S3PT-15) TPX-318 02/21 Operation Section 4-12 © 2021 Alamo Group Inc.
Page 65: Pre-Operation Inspection And Service
Make sure all pins have cotter pins and washers. Serious injury may occur from not maintaining this machine in good working order. (SG-21) TPX-318 02/21 Operation Section 4-13 © 2021 Alamo Group Inc.
Page 66: Tractor Pre-Operation Inspection/Service
Ensure the manual canister is secured to the equipment with the operator’s manual inside. • Ensure all safety signs are in place and legible. Replace missing, damaged, and illegible decals. OPS-U- 0011 TPX-318 02/21 Operation Section 4-14 © 2021 Alamo Group Inc.
Page 67 Missing, broken, or worn items must be replaced at once to reduce the possibility of injury or death from thrown objects, entanglement, or blade contact. (SGM-3) TPX-318 02/21 Operation Section 4-15 © 2021 Alamo Group Inc.
Page 68 OPS-R-0039_R • • Inspect the gearbox oil level using the dipstick level indicator and replenish if needed • Ensure the gearbox vent is in place and free from clogs. TPX-318 02/21 Operation Section 4-16 © 2021 Alamo Group Inc.
Page 69: Cutting Component Inspection
OTHERWISE DAMAGE THE BLADE WITH SUBSEQUENT FAILURE AND POSSIBLY CAUSE SERIOUS INJURY FROM THROWN BLADES. (SGM-10) 9.3 Cutting Component Inspection Inspect blade pan and blade assembly for the following: OPS-U-0031 TPX-318 02/21 Operation Section 4-17 © 2021 Alamo Group Inc.
Page 70 Failure to replace abnormally worn blades may lead to catastrophic failure of the blades and ejection of the broken part with tremendous force which may cause serious bodily injury or death. OPS-U-0032 TPX-318 02/21 Operation Section 4-18 © 2021 Alamo Group Inc.
Page 71: Blade Bolt Inspection
Failure to replace abnormally worn blade bolts may lead to catastrophic failure of the blades and ejection of the broken part which may cause serious bodily injury or death. Always replace Blade Bolts with new bolts whenever replacing the Blades. OPS-U-0037 TPX-318 02/21 Operation Section 4-19 © 2021 Alamo Group Inc.
Page 72 Blade bolts are tight Wheel lug nuts are tight Transport locks are in good condition Proper hourly greasing as per Operator’s Manual Operator’s Signature:___________________________________________________________________ DO NOT OPERATE an UNSAFE TRACTOR or MOWER TPX-318 02/21 Operation Section 4-20 © 2021 Alamo Group Inc.
Page 73 The radiator is free of debris The air filter is in good condition Proper hourly greasing is done as per Operator’s Manual Operator’s Signature:__________________________________________________________________ DO NOT OPERATE an UNSAFE TRACTOR or IMPLEMENT TPX-318 02/21 Operation Section 4-21 © 2021 Alamo Group Inc.
Page 74: Driving The Tractor And Implement
When operating in traffic always use the Tractor’s flashing warning lights and reduce your speed. Be aware of traffic around you and watch out for the other guy. (SG-19) TPX-318 02/21 Operation Section 4-22 © 2021 Alamo Group Inc.
Page 75: Starting The Tractor
When operating in traffic, always use the Tractor’s flashing warning lights and reduce your speed. Be aware of traffic around you and watch out for the other guy. TPX-318 02/21 Operation Section 4-23 © 2021 Alamo Group Inc.
Page 76: Driving The Tractor And Mower
When turning with an attached rear implement, the overall length of the working unit is greatly increased. Allow additional clearance for the mower to swing when turning. TPX-318 02/21 Operation Section 4-24 © 2021 Alamo Group Inc.
Page 77: Crossing Ditches And Steep Inclines
Damage resulting from over-collapse of the driveline’s inner profile and its outer housing may allow the driveline to come loose from the Tractor which could cause bodily injury to the operator or bystanders and/or extensive damage to the Tractor or Implement. OPS-R-0020 TPX-318 02/21 Operation Section 4-25 © 2021 Alamo Group Inc.
Page 78: Operating The Tractor And Implement
Special attention should be paid to foreign debris, rough terrain, steep slopes, and passersby and animals in the area. OPS-U- 0015 TPX-318 02/21 Operation Section 4-26 © 2021 Alamo Group Inc.
Page 79 Inspect the cutting area for such objects before mowing. Remove any like object from the site. Never allow the cutting blades to contact such items. (SGM-06) TPX-318 02/21 Operation Section 4-27 © 2021 Alamo Group Inc.
Page 80: Foreign Debris Hazards
In case of an Emergency, Shut down tractor engine, disengage the PTO and wait for all rotating motion to stop. Place the tractor in park position, engage the parking brake and remove the key before leaving the operator’s seat. TPX-318 02/21 Operation Section 4-28 © 2021 Alamo Group Inc.
Page 81: Engaging The Power Take Off (Pto)
Do not put hands or feet under mower decks. Blade Contact can result in serious injury or even death. Stay away until all motion has stopped and the decks are securely blocked up. (SGM-09) TPX-318 02/21 Operation Section 4-29 © 2021 Alamo Group Inc.
Page 82: Pto Rpm And Ground Speed
When mowing in reverse, operate the tractor and mower at a much reduced ground speed to ensure control is maintained of the tractor and cutter. OPS-R-0026_H TPX-318 02/21 Operation Section 4-30 © 2021 Alamo Group Inc.
Page 83 12” from ground level, disengage the tractor PTO and wait for all mower rotation to come to a complete stop before proceeding to raise the mower. TPX-318 02/21 Operation Section 4-31 © 2021 Alamo Group Inc.
Page 84 Stay alert and watch for trees, low hanging limbs, power lines, and other overhead obstacles and solid ground objects while you are operating. Use care to avoid hitting these items. TPX-318 02/21 Operation Section 4-32 © 2021 Alamo Group Inc.
Page 85 Mower sections or wings are adjusted to be close and parallel to ground without exposing blades. MOWING AREA has been inspected and foreign materials and debris have been removed. • • PASSERSBY are inside enclosed vehicle. OPS-U-0040 TPX-318 02/21 Operation Section 4-33 © 2021 Alamo Group Inc.
Page 86: Shutting Down The Implement
Always shut the Tractor completely down, place the transmission in park, and set the parking brake before you or anyone else attempts to connect or disconnect the Implement and Tractor hitches. (S3PT-15) TPX-318 02/21 Operation Section 4-34 © 2021 Alamo Group Inc.
Page 87 Do not let the driveline fall into mud or dirt, which can contaminate the bearing and shorten the life of the driveline. TPX-318 02/21 Operation Section 4-35 © 2021 Alamo Group Inc.
Page 88: Mower Storage
When connecting the cutter to the tractor, ensure the PTO support is swung down, and out of the way. TPX-318 02/21 Operation Section 4-36 © 2021 Alamo Group Inc.
Page 89: Transporting The Tractor And Implement
PTO output shaft. Secure the driveline to the mower deck to prevent driveline damage or loss during transport. OPS-R-0034_C TPX-318 02/21 Operation Section 4-37 © 2021 Alamo Group Inc.
Page 90: Tire And Wheels
Please see chart below for tire speed ratings and recommended inflation pressures. Recommenced inflation pressure for this unit is 60PSI. TPX-318 02/21 Operation Section 4-38 © 2021 Alamo Group Inc.
Page 91: Transporting On Public Roadways
Consult an authorized tractor dealer for lighting kits and modifications available to upgrade the lighting on older tractor models. OPS-U- 0021 TPX-318 02/21 Operation Section 4-39 © 2021 Alamo Group Inc.
Page 92: Hauling The Tractor And Implement
Ensure that the load will be in compliance with the legal limits set for the areas that will be traveled through. OPS-U- 0024 TPX-318 02/21 Operation Section 4-40 © 2021 Alamo Group Inc.
Page 93 If during transport a hard braking, sharp turning, or swerving action was performed, stop at the next safe location to inspect the security of the load. OPS-U- 0026 TPX-318 02/21 Operation Section 4-41 © 2021 Alamo Group Inc.
Page 94: Troubleshooting Guide
Replace seal or use a sealant on OD of seal. Oil level too high. Drain oil to proper level. Sand hole in casting. Replace castings or gearbox. Gasket damaged. Replace gasket. Bolts loose. Tighten bolts. TPX-318 02/21 Operation Section 4-42 © 2021 Alamo Group Inc.
Page 95 On main lift cylinder use depth stop cylinder vent a small amount of leakage is to carry. If leakage is excessive normal replace piston rings. Cylinder wall scored or pitted Replace cylinder TPX-318 02/21 Operation Section 4-43 © 2021 Alamo Group Inc.
Page 98: Hazards With Maintenance Of Implement
DO NOT modify or alter implement, functions or components. • DO NOT WELD or repair rotating mower components. These may cause vibrations and component failures being thrown from mower. PN HM02 TPX-318 02/21 Maintenance Section 5-2 © 2021 Alamo Group Inc.
Page 99 Side Skirts and Skid Shoes in place and in good condition. • REPLACE any missing, broken or worn safety shields, guards and safety devices. Cancer and Reproductive Harm www.P65Warnings.ca.gov PN HM02-A TPX-318 02/21 Maintenance Section 5-3 © 2021 Alamo Group Inc.
Page 100: Parts Information
These parts are made and tested to Schulte Industry specifications. Non-genuine "will fit" parts do not consistently meet these specifications. The use of “will fit” parts may reduce the performance, void Schulte warranties, and present a safety hazard. Use genuine Schulte parts for economy and safety.
Page 102: Gearboxes
Replace oil in gearboxes after the first 50 hours of operation then yearly. Check gearbox oil level frequently. Steady loss of oil will indicate damaged seals, which should be replaced immediately to prevent ruining the gearbox. TPX-318 02/21 Maintenance Section 5-6 © 2021 Alamo Group Inc.
Page 103: Grease Schedule
-API Service Classifications GL-5 -Military Specification MIL-L-2105C Consult the following chart for the oil viscosity recommendations: NOTE: Use SAE 80-90Gear Oil Grease Schedule Grease should meet the following recommendations: TPX-318 02/21 Maintenance Section 5-7 © 2021 Alamo Group Inc.
Page 104: Drivelines
Check that the driveline shielding is not damaged and rotates freely on the driveline. If sliding members are allowed to dry out to the point where the two halves cannot slip freely, damage to the rotary cutter or tractor may occur. TPX-318 02/21 Maintenance Section 5-8 © 2021 Alamo Group Inc.
Page 105: Tractor Shaft
A fresh coat of grease should be applied to the entire surface of the inner tube. If sliding members are allowed to dry out to the point where the two halves cannot slip freely, damage to the rotary cutter or tractor may occur. TPX-318 02/21 Maintenance Section 5-9 © 2021 Alamo Group Inc.
Page 106 NOTE: Replace Blades in pairs after no more than 1/2” notch wear! TPX-318 02/21 Maintenance Section 5-10 © 2021 Alamo Group Inc.
Page 107: Blade Removal
1" to 1-1/2" (25-38 mm)of free up and down motion at the tip of the blade. Mnt-R-0004 TPX-318 02/21 Maintenance Section 5-11 © 2021 Alamo Group Inc.
Page 108: Blade Bolt Inspection
Strike opposite end of bar with sledge hammer. Rotate blade carrier 180 degrees and repeat process. TPX-318 02/21 Maintenance Section 5-12 © 2021 Alamo Group Inc.
Page 109: Blade Carrier Installation
It is important that the retaining nut be checked after a few hours of operation then periodically. Retightened if necessary. AVOID PERSONAL INJURY. DO NOT work under cutter without support blocks to keep the frame from falling. Mnt-R-0019 TPX-318 02/21 Maintenance Section 5-13 © 2021 Alamo Group Inc.
Page 110 It is important that the retaining nut be checked after a few hours of operation then periodically. Retightened if necessary. AVOID PERSONAL INJURY. DO NOT work under cutter without support blocks to keep the frame from falling. Mnt-R-0006 TPX-318 02/21 Maintenance Section 5-14 © 2021 Alamo Group Inc.
Page 111: Slip Clutches
SLIP CLUTCHES Each of the drivelines on the Schulte cutter is equipped with a slip clutch. Everyone of these slip clutches are pre-set and run-in by the Schulte supplier, so they should not be adjusted by the dealer or end user.
Page 112: Reassembly
4. Clean the parts using brake cleaner and a wire brush. 5. Inspect the thickness of the friction linings and replace them if they are less than 2.5 mm in thickness (new friction linings are 3.2 mm thick). Reassembly TPX-318 02/21 Maintenance Section 5-16 © 2021 Alamo Group Inc.
Page 113 The FT clutch utilizes Belleville spring to provide a constant torque setting during the life of the friction lining. The spacer/ indicator ring ensures the accuracy of the spring tension setting. TPX-318 02/21 Maintenance Section 5-17 © 2021 Alamo Group Inc.
Page 114 12. Check dust seal to ensure seal rubber is positioned correctly. 13. Install the small or outer bearing. 14. Install the axle washer and castle nut on the axle. TPX-318 02/21 Maintenance Section 5-18 © 2021 Alamo Group Inc.
Page 115: Tightening Instructions For 517 & 511 Hubs
Securely block the wheel standard so the tire can spin freely before removing the wheel bolts. AVOID PERSONAL INJURY. DO NOT work under cutter without support blocks to keep the frame from falling. TPX-318 02/21 Maintenance Section 5-19 © 2021 Alamo Group Inc.
Page 116: Hydraulic Hoses
Cylinder immediately before the Cylinder is damaged or too much hydraulic fluid is lost. MAXIMUM ALLOWABLE OPERATING OIL TEMPERATURE Do not operate this implement if the tractor hydraulic oil temperature exceeds 200°F TPX-318 02/21 Maintenance Section 5-20 © 2021 Alamo Group Inc.
Page 117: Flex Wing Hydraulic Cylinder Replacement Instructions
19. Check the hydraulic reservoir of the tractor to ensure there is sufficient oil. 20. If the wing is to remain in the raised position attached the wing transport latch. TPX-318 02/21 Maintenance Section 5-21 © 2021 Alamo Group Inc.
Page 118 NOTE: These values apply to fasteners as received from supplier, dry or when lubricated with normal engine oil. They do not apply if special graphited or molydisulphide greases or other extreme pressure lubricants are used. This applies to both UNF fine and UNC coarse threads. TPX-318 02/21 Maintenance Section 5-22 © 2021 Alamo Group Inc.
Page 119 [Refer to the "Parts Manual" ]. Do not replace lock nuts with nuts and lockwashers. Use only original equipment lock nuts. Recommended Torques in foot pounds for SAE Grade 5 bolts, based on dry assembly: Mnt-R-0002 TPX-318 02/21 Maintenance Section 5-23 © 2021 Alamo Group Inc.
