Weltem AmeriCool WPC-18000 Owner's Manual

High capacity air conditioner (for indoor & outdoor)
Hide thumbs
Table of Contents

Advertisement

Quick Links

Owner's Manual
Please read and save these instructions. Read carefully before attempting to assemble, install, oper-
ate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions
could result in personal injury and / or property damage! Retain instructions for future reference.
High Capacity Air Conditioner
(For Indoor & Outdoor)
Descripti on
AmeriCool Portable Air Conditi oners are specialized for
"SPOT COOLING" where central cooling is impracti cal.
AmeriCool air conditi oners can also be used in enclosed areas
just like conventi onal air conditi oners. Simple digital controller
and self-diagnosti c functi ons allow users to easily operate
the unit. Built-in Caster wheels enable users to move the
unit without any hassle. The unit can be installed in 5 minutes
and does not require any extra materials or certi fi ed technician
for installati on.
AmeriCool Portable Air Conditi oner, anywhere, everywhere.
Plug-and-Go!
Unpacking
Aft er unpacking the unit, carefully inspect unit for any damage that may have occurred during transit.
Check for any loose, missing, or damaged parts.
Specifi cati ons
Power Supply
Model No.
WPC-18000
1Phases - 220V - 60Hz
Weight (Net / Gross)
Model No.
WPC-18000
(Phase-V-Hz)
Lbs(kg)
672/728lbs.
(305/330kg)
by
Cooling Capacity
(Btu/h)
60000
Operati ng Ambient
Temperature Range
64~113
(18~45
°F
°C
WPC-18000
Figure 1
Power Consumpti on
(Watt s)
6.5kW
Dimensions
W x D x H - in. (mm)
29.5 x 62.1 x 58.1
)
(750 x 1578 x 1478 )
WPC-18000
Rated Current
(Amps)
30.2A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AmeriCool WPC-18000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Weltem AmeriCool WPC-18000

Summary of Contents for Weltem AmeriCool WPC-18000

  • Page 1 Owner’s Manual WPC-18000 Please read and save these instructions. Read carefully before attempting to assemble, install, oper- ate or maintain the product described. Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and / or property damage! Retain instructions for future reference. High Capacity Air Conditioner (For Indoor &...
  • Page 2 WPC-18000 Owner’s Manual Specifications (Continued) Evaporator(Cool) Air Flow Model No. Refrigerant Type / oz(g) (CFM) For a compressor: WPC-18000 1998 R-410, 56.4oz (1600g) Total: 102.8oz (3200g) Compressor overload protector, Anti-freezing thermister, Automatic restart (Power interruption), Safety Devices Compressor time delay program, High pressure switch Temperature control, Self-diagnostic function, Features...
  • Page 3 WPC-18000 Owner’s Manual DO NOT operate the unit in explosive or flammable environments. 14. DO NOT unplug to turn off the unit. Always use the power switch to start and to stop the unit. 15. Always turn off the unit and unplug it before cleaning, moving or performing maintenance. 16.
  • Page 4 WPC-18000 Owner’s Manual Assembly (WPC-18000) COMPONENT PARTS Controls Hot Air Exhaust Emergency Stop Figure 3 Handle Controls Electrical Panel Top Cover I BOLT Cold Air Exhaust Filter Cold Air Inlet Filter Condensate outlet Cold Air Inlet Air Inlet Figure 2 Caster Front and Right Side View Figure 4...

  • Page 5: Duct Connections

    WPC-18000 Owner’s Manual DUCT CONNECTIONS Cool Air Duct (OUT) connection The Cool Air Ducts (OUT) are labeled "AIR OUT". The diameter of the duct is 400Ø. Connect the flexible air duct as following 1. Attach a flexible duct to the duct collar. Use a clamp or any appropriate apparatus around the collar to prevent any air leakage.

  • Page 6: Installation

    WPC-18000 Owner’s Manual Installation WARNINGS REGARDING PROPER LOCATION FOR INSTALLATION Do not use the unit in explosive environments or in areas where flammable gas leakage may occur. Do not use the unit in areas where it will be exposed to rain or water. Do not use the unit in a corrosive atmosphere.

  • Page 7: Control Panel

    WPC-18000 Owner’s Manual Operation CONTROL PANEL Figure 10 1. POWER BUTTON : Turns on/off the unit when the button is pressed for 1 second. 2. BLOWER BUTTON : Adjusts the fan speed from (Low) to (High) when the button is pressed for 1 second. NOTE: Some models only have one fan speed 3.
  • Page 8 WPC-18000 Owner’s Manual Operation CONTROL PANEL 7. CURRENT TEMP : Displays Current temperature NOTE: Canadian version shows the temperature in Celsius. 8. TARGET TEMP : Displays target temperature OFF-TIMER : Press BLOWER Button and SPOT/COOL Button simultaneously for 2 seconds to set off-timer.

  • Page 9: Maintenance

    WPC-18000 Owner’s Manual Maintenance FILTER CLEANING (See Figures 11 and 12) 1. Unscrew 6 bolts on the front filter guard. 2. Slide filter up and use a vacuum cleaner to remove the dust from the filter. 3. If the filter is heavily covered with dust and dirt, use warm water and mild soap or neutral detergent to wash the filter.

  • Page 10: Self Diagnostic Codes

    WPC-18000 Owner’s Manual Maintenance (Continued) – To ensure your product is covered by warranty, the complete faulty product along with your original purchase receipt must be provided at the place of purchase. Product Portable Air Conditioner Customer: Please read and keep this Model No.
  • Page 11 WPC-18000 Owner’s Manual NOTE: The alarm code will be displayed on CURRENT TEMP display SELF-DIAGNOSTIC ALARM CODES Alarm Display Problem Cause Solutions • Ambient • Do not use the air temperature is conditioner if ambient Abnormal too low temperature is below temperature •...
  • Page 12 WPC-18000 Owner’s Manual Wiring Diagram PS (HP) Figure 14 - Circuit Wiring Diagram (WPC-18000)

  • Page 13: Troubleshooting

    WPC-18000 Owner’s Manual TROUBLESHOOTING Symptom Possible Cause(s) Solutions 1. Check the power supply 1. Reset the circuit breaker and restart the unit Unit does not start. 2. Check whether the 2. Connect power cord power cord is connected 1. The filter is dirty and air 1.

  • Page 14: Shipping List

    SHIPPING LIST • (1) High Capacity Air Conditioner • (1) Owner’s Manual OBTAINING SERVICE Weltem High Capacity Air Conditioner by AmeriCool If the requires Service: 1. Use the TROUBLESHOOTING section in this manual to eliminate obvious causes. 2. Verify there are no circuit breakers tripped.

  • Page 15: Limited Warranty

    TO THE EXTENT PERMITTED BY LAW, THIS WARRANTY, AS LIMITED HEREIN, SHALL BE IN LIEU OF AND EXCLUSIVE OF ALL OTHER WARRANTIES, EITHER EXPRESSED OR IMPLIED, ON THE PART OF AMERICOOL INC., OR WELTEM CO.,LTD. WHETHER ARISING FROM LAW, COURSE OF DEALING, US- AGE OF TRADE, OR OTHERWISE, INCLUDING WITHOUT LIMITATION ANY IMPLIED WARRANTY OF MERCHANT-ABILITY OR FITNESS OF A PARTICULAR PURP OSE OR ANY LIABILITY FOR COMMERCIAL LOSSES BASED UPON NEGLIGENCE OR MANUFACTURER’S STRICT LIABILITY.
