MADE IN CHINA
02/16
INSTALLATION INSTRUCTIONS
PALISADE
QUESTIONS OR CONCERNS CONTACT CANARM AT:
1-800-265-1833 (ENGLISH)
1-800-567-2513 (FRENCH)
Monday through Friday 8:00 a.m. to 5:00 p.m. EST
IMPORTANT
FOR YOUR RECORDS, RECORD AND KEEP
THE FOLLOWING INFORMATION
Date of purchase:
Place of purchase:
Model on carton:
I.D.#:
UPC:
NOTE: FOR OPTIMUM QUIETNESS, FULLY ASSEMBLE FAN AND RUN FOR 24 HOURS.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PALISADE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Canarm PALISADE

Summary of Contents for Canarm PALISADE

  • Page 1 MADE IN CHINA 02/16 INSTALLATION INSTRUCTIONS PALISADE QUESTIONS OR CONCERNS CONTACT CANARM AT: 1-800-265-1833 (ENGLISH) 1-800-567-2513 (FRENCH) Monday through Friday 8:00 a.m. to 5:00 p.m. EST IMPORTANT FOR YOUR RECORDS, RECORD AND KEEP THE FOLLOWING INFORMATION Date of purchase: Place of purchase: Model on carton: I.D.#:...

  • Page 2: Tools And Materials Required

    1. TOOLS AND MATERIALS REQUIRED Philips screw driver Blade screw driver 11 mm wrench Step ladder Wire cutters 2. PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items: Blade set (5) Hanger bracket assembly Downrod Coupling cover Fan motor assembly...

  • Page 3: Safety Rules

    3. SAFETY RULES 1. To reduce the risk of electric shock, 8. Avoid placing objects in the path of the insure electricity has been turned off at blades. the circuit breaker or fuse box before beginning. To avoid personal injury or damage to the fan and other items, be cautious 2.

  • Page 4: Mounting Options

    4. MOUNTING OPTIONS If there isn't an existing CUL listed mounting box, then read the following instructions. Disconnect the power by removing fuses or turning off circuit breakers. Outlet box Secure the outlet box directly to the building structure. appropriate fasteners and building materials.

  • Page 5: Hanging The Fan

    5. HANGING THE FAN REMEMBER to turn off the power. Follow Hanger the steps below to hang your fan properly: bracket Step 1. Remove the decorative canopy Ceiling bottom cover from the canopy by turning canopy the cover counter clockwise. (Fig. 5) Canopy Step 2.

  • Page 6: Installation Of Safety Support

    6. INSTALLATION OF SAFETY SUPPORT An additional safety support is provided to prevent the fan from falling. Secure the safety cable to the ceiling joist with screw and washer (not included), as illustrated in Figure 9. Hanger bracket Safety cable Figure 9 7.

  • Page 7: Finishing The Installation

    WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR OTHER PERSONAL POWER LINES 120V INJURY. MOUNT FAN ONLY ON AN OUTLET GREEN BOX OR SUPPORTING SYSTEM MARKED GROUND ACCEPTABLE FOR FAN SUPPORT. WIRING LIGHT GROUND TO MOUNTING BRACKET OR DOWNROD LIGHT Figure 12 8.

  • Page 8: Attaching The Fan Blades

    9. ATTACHING THE FAN BLADES Insert the blades through the blade slot in the decorative housing. Align the holes in blade and blade bracket, secure with the screws and fiber washers provided. (Fig. 14) Slot Blade Screws with fiber washers Figure 14 10.

  • Page 9: Installing The Led Light Kit

    11. INSTALLING THE LED LIGHT KIT NOTE: Before starting installation, disconnect the power by turning off the circuit breaker or removing the fuse at fuse box. Turning power off using the fan switch is not sufficient to prevent electric shock. Step 1.

  • Page 10: Operating Your Fan

    13. OPERATING YOUR FAN Turn on the power and check the operation of your fan. The pull chain controls the fan speed as follows: 1 pull - High, 2 pulls - Medium, 3 pulls - Low, and 4 pulls - Off. The pull chain controls the light as follows: 1 pull - Lightest, 2 pulls - Medium ligh, 3 pulls - Darker, and 4 pulls - Off.

  • Page 11: Care Of Your Fan

    14. CARE OF YOUR FAN Here are some suggestions to help you maintain your fan 1. Because of the fan's natural movement, some connections may become loose. Check the support connections, brackets, and blade attachments twice a year. Make sure they are secure.

  • Page 12: Troubleshooting

    15. TROUBLESHOOTING Problem Solution Fan will not start. Check circuit fuses or breakers. Check line wire connections to the fan and switch wire connections in the switch housing. CAUTION: Make sure main power is off. Fan sounds Make sure all motor housing screws are snug. noisy.
