- Page 1 T E R • • E A E A S I S I E E R R P U M P S A U S T R A L I A UNDERSINK PUMP STATION INSTRUCTION MANUAL MODELS: RUP155 | RUP220 Made in Australia Pumps for the Future www.reefe.com.au...
- Page 2 Adjustable “stop” vertical float switch • Compact & easy to install • Preassembled - ready to install • 24 hour auto pump timer (RUP155-T only) • Not suitable for raw sewage CONSTRUCTION • Stainless steel motor housing & shaft •...
- Page 3 CABLE WEIGHT SIZE CODE HANDLING LENGTH (KG) L X W X H (MM) INCH 8416 15MM 1 1/4 220 x 190 x 350 8225 25MM 1 1/2 190 x 205 x 350 ASCENTO GROUP AUSTRALIA www.reefe.com.au P 1800 807 604...
- Page 4 T E R • • E A E A S I S I E E R R P U M P S A U S T R A L I A PUMP DIMENSIONS FRONT VIEW OVERALL DIMENSIONS Length Width Height 450mm 280mm 350mm ASCENTO GROUP AUSTRALIA www.reefe.com.au P 1800 807 604...
- Page 5 P U M P S A U S T R A L I A CROSS SECTION & COMPONENTS LIST COMPONENT REEFE® RVS155VF/RVS200VF Sump Pump with Vertical Float 25mm Brass Barrell Union 25mm Brass Swing Check Non-Return Valve 25mm Poly Discharge Pipework...
- Page 6 The decline of horizontal pipework must be at least one centimetre per metre. RECOMMENDATION: It is recommended for the REEFE® Undersink Pump Station to be vented, either by connecting it to existing pump vent, or alternatively, by installing an air remittance valve connection to the vent connection. Ensure the air remittance valve is installed in the upright position.
- Page 7 5. Warranty is void if any tampering or removal of identification labels or electrical cables has occurred, or any non- genuine parts have been fitted, or repairs have been carried out by unqualified persons. No warranty applies for REEFE COMPACT LIFTING STATIONS sold or used for HIRE or RENT or LEASE or MINE SITES or REMOTE AREAS or INDUSTRIAL APPLICATIONS or SCHOOLS or PUBLIC VENUES, all of which are defined by us, at our discretion.
