AMI Trides

Program List and Explanations

9.

1 Messages

1.1 Pending Errors
1.1.5
1.2 Message List
1.2.1

2 Diagnostics

2.1 Identification
2.1.3
2.1.4
2.2 Sensors
2.2.1
2.2.1.5
2.2.2
2.2.3
2.2.3.1
A-96.250.111 / 161120
Program List and Explanations
Provides the list of active errors with their status (active, acknowl-
edged). If an active error is acknowledged, the alarm relay is active
again. Cleared errors are moved to the Message list.
Shows the error history: Error code, date / time of issue and status
(active, acknowledged, cleared). 65 errors are memorized. Then the
oldest error is cleared to save the newest error (circular buffer).
In diagnostics mode, the values can only be viewed, not modified.
Desig.: Designation of the instrument.
Version: Firmware of instrument (e.g. V6.20-06/16).
Factory Test: Test date of the Instrument and Motherboard.
Operating Time: Years / Days / Hours / Minutes / Seconds.
Trides Sensor:
Current value: Shows the current disinfectant measuring value in
ppm
Raw value 1: Shows the actual sensor current in µA, without
compensation of temperature (and pH).
Raw value 2: Shows the actual sensor current in µA, with
compensation of temperature (and pH).
Ref. voltage: Shows the actual voltage of counter electrode (CE) in
mV. Values for most applications are within 800 - 1300 mV.
Cal. History: Review the diagnostic values of the last calibrations.
Number, Date, Time, Offset [µA], Slope [µA]
Electrode (only available if option pH /Redox is installed):
Current value: Shows the current pH value.
Raw value: Shows the current voltage of the pH electrode in mV.
Miscellaneous:
Case Temp: Shows the current temperature in [°C] inside the trans-
mitter.
