- Page 1 BPS 348i Bar code Positioning System Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com...
-
Page 2: Table Of Contents
6.2.6 BPS mounting with M4 fastening screws..........39 Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... - Page 3 8.6.23Module 24 – Read quality ............72 Leuze electronic webConfig tool – Extended configuration ..... 73 Installing the required software .
- Page 4 14.1 BPS 348i type overview........
-
Page 5: About This Document
Generic Station Description Markup Language Graphical User Interface IO or I/O Input/Output Internet Protocol Light Emitting Diode Media Access Control Type of control bar code Type of control bar code Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... - Page 6 Protective Extra-Low Voltage Real Time SNMP Simple Network Management Protocol Programmable logic control Transmission Control Protocol User Datagram Protocol Universal Serial Bus Underwriters Laboratories Ultraviolet Extensible Markup Language Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com...
-
Page 7: Safety
• They are familiar with the technical description of the BPS. • They have been instructed by the responsible person on the mounting and operation of the BPS. Electrical work must be carried out by a certified electrician. Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 8: Device-Specific Safety Notices
There are no user-serviceable parts inside the device. The device must not be opened. If the device is opened, there is a risk of injury to the retina. Repairs must only be performed by Leuze electronic GmbH + Co. KG. NOTICE Must be observed! ... - Page 9 Safety Laser aperture warning Name plate with laser notice sign Figure 2.1: Attachment of the sticky labels with warning notices at the BPS Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com...
-
Page 10: Disclaimer
Figure 2.2: Laser warning notices, supplied stick-on labels Disclaimer Leuze electronic GmbH + Co. KG is not liable in the following cases: • The BPS is not being used properly. • Safety notices are not adhered to. • Reasonably foreseeable misuse is not taken into account. -
Page 11: Device Description
• Configuration via webConfig tool or PROFINET fieldbus • Diagnostics via webConfig tool or optional display • Optional model with display • Optional model with optics heating for use to -35 °C Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 12: Accessories
The MS 348 BPS connector hood features three M12 connector plugs and a Mini-B type USB socket as a service interface for configuration and diagnostics of the BPS. Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 13: Mk 348 Connection Hood With Spring-Cage Terminals
Upon device exchange, they are automatically transmitted to the new device. 3x cable bushing, M16 x 1,5 SERVICE: Mini-B USB socket (behind protective cap) Figure 3.3: MK 348 terminal hood, connections Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 14: Display Elements
The device housing features the following multicolor LED indicators as primary display element: • PWR • BUS LED PWR LED BUS Display Control buttons Figure 3.5: Indicators on the device housing Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... - Page 15 PROFINET wave function activated LED indicators on the connection hood (MS 348 or MK 348) LED 0, ACT0/LINK0 LED 1, ACT1/LINK1 Figure 3.6: MS 348, LED indicators Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com...
-
Page 16: Display Indicators
• The upper display line shows the selected function as an English term. • The lower display line shows the data of the selected function. Display Control buttons Figure 3.8: Display on the device housing Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... - Page 17 During device start-up, a start-up display first appears which is briefly followed by the display with the version information. Position Value The standard display after starting up the BPS is Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com...
-
Page 18: Bar Code Tape
200 m. Bar code tapes with special requirements with respect to height, length and value range can be ordered from Leuze electronic (see chapter 14.5 „Bar code tapes“). NOTICE Value range for BCB with special requirements! ... - Page 19 BCB8 For bar code tapes with 30 mm grid, the designation is printed in plain text in addition to the position value. Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com...
-
Page 20: Control Bar Codes
• 30 mm with BCB8 bar code tapes • 40 mm with BCB bar code tapes Keep the gap between the BCBs that are switched between as small as possible. Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... - Page 21 BCB, provided the next position label is in the BPS's scanning beam (see figure 3.13). The output position value is thereby always uniquely assigned to one BCB. Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com...
-
Page 22: Marker Labels
The marker label must be attached to the bar code tape aligned with the grid of the actual coding. A posi- tion code should be visible before and after the marker label. Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 23: Twin Tapes
Figure 3.15: Twin tape with double numbering Twin tapes are always delivered in pairs on two rolls. If twin tapes are replaced, both tapes are to be replaced. Twin tapes can be ordered from Leuze electronic (see chapter 14.5 „Bar code tapes“). Leuze electronic BPS 348i... -
Page 24: Functions
If the preset is activated, this has priority over the offset. Velocity measurement The current velocity is ascertained and output on the basis of the respective position values. The most important individual parameters for the velocity measurement are: Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 25: Timing
4.4.1 Leuze webConfig tool The webConfig configuration tool offers a graphical user interface for the display of process data, config- uration and diagnostics of the BPS via a PC (see chapter 9 „Leuze electronic webConfig tool – Extended configuration“). 4.4.2 Evaluation of the read quality The BPS can signal the read quality of the BPS. -
Page 26: Distance Measurement To The Bar Code Tape
• Status information for position measurement: Input data 0.0 … 1.7; see chapter 8.6.8 „Module 6 – Status and control“ • Status information for velocity measurement: Input data 0.0 … 1.5; see chapter 8.6.18 „Module 16 – Velocity status“ Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 27: Applications
• The Leuze electronic bar code tape is very robust, highly flexible and, thanks to the self-adhesive back, can be easily integrated into your overall mechanical system. It can be fit optimally to both ver- tical as well as horizontal curved paths and thereby reliably facilitates trouble-free and reproducible measurement at any point in your system with sub-millimeter accuracy. -
Page 28: High-Bay Storage Device
Simultaneous position and velocity measurement for regulation tasks Precise positioning with a reproducibility of 0.15 mm Control at high traverse rates of up to 10 m/s Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 29: Telpher Line
The working range from 50 - 170 mm allows for flexible mounting positions and reliable position detec- tion at varying distances Control codes for changing to different position values at switches Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 30: Gantry Cranes
Positioning from 0 to 10,000 meters Scratch- and smudge-proof, UV-resistant bar code tapes Synchronous positioning with twin tapes on both rails Mounting device for fast, precise mounting with one screw Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 31: Mounting And Installation
Avoid position bar code labels with the value 00000 Measurements to the left of the center of a label produce negative position values that may not be displayed correctly. Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... - Page 32 If there is a gap without tape after the preceding tape, it must be at least 300 mm wide before the subse- quent tape is affixed. The subsequent bar code value must differ from the preceding tape by at least 0.2 m. Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com...
- Page 33 Ensure that there are matt, bright surfaces behind the fanning in the BCB curves. Polished, reflective, and high-gloss surfaces in the scanning beam may impair the measurement qual- ity of the BPS. Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com...
- Page 34 Mounting two bar code tapes with the same value range For crane systems or elevators, two bar code tapes with the same value range are used for positioning. Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com...
-
Page 35: Mounting The Bcb
• BT 300 W: Mounting on a mounting bracket • BT 300-1: Mounting on a rod • Mounting using four M4 mounting threads on the rear of the device Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 36: Mounting Instructions
Mounting with the BTU 0300M-W mounting device Mounting the BPS with a BTU 0300M-W mounting device is intended for wall mounting. For ordering infor- mation see chapter 14; for dimensioned drawing see figure 13.7. Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 37: Mounting With The Bt 300 W Mounting Bracket
Mount the BPS with its fastening grooves on the clamping jaws of the BT 56 with limit stop at end. Secure the BPS with the M6 screw terminal. Maximum tightening torque for the M6 screw terminal: 8 Nm Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 38: Mounting With Bt 300-1 Mounting Device
Mount the BPS on the system with M4 fastening screws (included in delivery contents). Maximum tightening torque of the fastening screws on BT 0300 W and BT 300-1: 2 Nm Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 39: Electrical Connection
• The control can immediately access the exchanged BPS. MS 348 connection hood with connectors The MS 348 connection hood features three M12 connector plugs and a Mini-B type USB socket as a service interface. Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 40: Mk 348 Connection Hood With Spring-Cage Terminals
Connect the HOST / BUS IN connection to a switch with the connection cable. PROFINET - linear topology: Connect the HOST / BUS IN connection to the BUS OUT connection of the upstream BPS with the con- nection cable. Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 41: Pin Assignment
If SWIO1 or SWIO2 is to be used as digital input or output, the configuration must be performed in module 4 (see chapter 8.6.6) or module 5 (see chapter 8.6.7). NOTICE Maximum input current The maximum input current must not exceed 8 mA. Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 42: Host / Bus In (Host/Bus Input, Ethernet)
Transmit Data - Receive Data - not connected NOTICE Use ready-made cables! If possible, use the ready-made cables from Leuze electronic (see table 14.4 or see table 14.5). Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 43: Bus Out (Host/Bus Output, Ethernet)
4-pin, M12-socket (D-coded) or terminal block for connection to BUS OUT. Ethernet 0 Ethernet 1 Figure 7.4: BUS OUT connection Table 7.3: BUS OUT pin assignment Pin/terminal Designation Assignment Transmit Data + Receive Data + Transmit Data - Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 44: Service Usb
FE via screw fitting Functional earth (housing) NOTICE Use ready-made cables! If possible, use the ready-made cables from Leuze electronic (see table 14.6). NOTICE Self-configured cables with PROFINET interface! Ensure adequate shielding. The entire connection cable must be shielded and earthed. -
Page 45: Profinet Topologies
The maximum length of a segment (connection from one participant to the next) is limited to 100 m. Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 46: Profinet - Wiring
PROFINET - wiring NOTICE Strictly observe during PROFINET wiring! Use the ready-made cables from Leuze electronic (see chapter 14.3) or the recommended connec- tors/sockets. Always use a CAT 5 Ethernet cable for the wiring. For the conversion of the connection technology from M12 to RJ45, use the KDS ET M12 / RJ 45 W - 4P (see table 14.7) adapter. - Page 47 100 m for 100Base-TX required twisted pair (min. CAT 5) BPS power supply unit 30 m not necessary Switching input 10 m not necessary Switching output 10 m not necessary Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com...
-
Page 48: Profinet Interface - Basic Configuration
• Acyclic data exchange, i.e., transfer of various types of information: Parameters for the module configuration while communication is being established I&M data (Identification & Maintenance functions) Reading diagnostic information Reading I/O data Writing device data Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 49: Conformance Classes
You can find the GSDML file at Leuze website > Products > Measuring Sensors > Sensors for Positioning > BPS 300i > (Name of the BPS) > Tab Downloads > Software/driver > GSDML file. Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... - Page 50 During operation of the BPS on the PROFINET all parameters are set to default values. If these parameters are not changed by the user, the device functions with the default settings delivered by Leuze electronic. The default settings of the BPS can be found in the module descriptions.
-
Page 51: Profinet Modules
Parameters that can be changed via PROFINET (see modules described in the following). • Internal parameters Parameters that are changed only via a service interface. They retain their value even after a PROFINET configuration. Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 52: Overview Of The Profinet Modules
Static velocity limit value 3 Switching type (P), Selection of direction (P), Velocity limit value 3 (P), Velocity see page 67 hysteresis 3 (P), Limit value 3 range start/range end (P) Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 53: Dap Module - Permanently Defined Parameters
Tape selection 1.5 … Bit field 1: 30 mm BCB -------------- Changeover between bar code tape (BCB) with 2: 40 mm BCB 30 mm grid and 40 mm grid. Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 54: Module 1 - Position Value
Example: Offset = 10000 mm – after changing from metric to inch: Offset = 10000 inch/100 Manually convert the numerical values when changing the unit of measurement. Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 55: Module 2 - Static Preset
In the event of a device exchange, the preset value must be reactivated at the intended position (Teach Preset). The module contains output data (with output data length of 5 bytes), but no parameters and no input data. Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 56: Module 4 - Input/Output I/O 1
0: LOW (output), transition 1 → 0 1: HIGH (output), transition 0 → 1 If the I/O is configured as an input, it responds edge- triggered. Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... - Page 57 Inch State 0 … 1 ------------- Signal state of the input or output: 0: Input/output not active at signal level 1: Input/output active at signal level Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com...
-
Page 58: Module 5 - Input/Output I/O 2
0: LOW (output), transition 1 → 0 1: HIGH (output), transition 0 → 1 If I/O 2 is configured as an input, it responds edge- triggered. Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... - Page 59 Inch State 0 … 1 ------------- Signal state of the input or output: 0: Input/output not active at signal level 1: Input/output active at signal level Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com...
-
Page 60: Module 6 - Status And Control
0: OK 1: Value greater than limit Control or marker bar code 0 … 1 ------------ Signals a detected marker bar code. detected 0: No marker 1: Marker detected Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 61: Module 7 - Position Limit Value Range 1
6 and, if config- ured, an output is set. The module contains parameters (with parameter data length of 8 bytes), but no input data and no output data. Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 62: 10Module 8 - Position Limit Value Range 2
If the problem with the calculation lasts for a longer period of time, it is possible to configure how the BPS is to behave. The module contains parameters (with parameter data length of 8 bytes), but no input data and no output data. Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 63: 12Module 10 - Velocity
The module contains parameters (with parameter data length of 2 bytes) and input data (with consistent input data length of 4 bytes), but no output data. Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 64: 13Module 11 - Static Velocity Limit Value 1
If the range start is identical to the range end, a continuous, direction-independent limit value check is performed. The module contains parameters (with parameter data length of 13 bytes), but no input data and no output data. Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 65: 14Module 12 - Static Velocity Limit Value 2
+10.000.000 /100 position. Limit value 2 range end 9 … sign -10.000.000 … The velocity limit value is monitored up to this posi- 32 bit +10.000.000 /100 tion. Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 66: 15Module 13 - Static Velocity Limit Value 3
0: Direction independent 1: Direction dependent Velocity limit value 4 1 … 2 unsign 0 … +20.000 (in/ Limit value is compared to the current velocity. 16 bit 100) Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 67: 17Module 15 - Dynamic Velocity Limit Value
32 bit +10.000.000 /100 position. Limit value range end 9 … sign -10.000.000 … The velocity limit value is monitored up to this posi- 32 bit +10.000.000 /100 tion. Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 68: 18Module 16 - Velocity Status
Dynamic velocity limit value 0 … 1 ------------- Signals whether the current velocity is compared with active the Dynamic velocity limit value: 0: Comparison not active 1: Comparison active Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 69: 19Module 20 - Free Resolution
Inch Distance unsign 0 … 255 in/10 Current distance between BCB and read head: 8 bit 0: No distance calculated 255: Distance outside of the reading field Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 70: 21Module 22 - Control And Marker Bar Codes
The entire BCB is corrected with the default 10,000,000 value of for the range end. The module contains parameters (with parameter data length of 10 bytes), but no input data and no output data. Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 71: 23Module 24 - Read Quality
Inch Read quality unsign 0 … 100 Read quality in units of [%] as smoothed value, Smoothing of read quality 8 bit dependent on the parame- ter. Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 72: Leuze Electronic Webconfig Tool - Extended Configuration
Leuze electronic webConfig tool – Extended configuration Leuze electronic webConfig tool – Extended configuration With the Leuze electronic webConfig tool, an operating-system independent, web-technology based, graphical user interface is available for configuring the BPS. The webConfig tool can be run on any Internet-ready PC. The webConfig tool uses HTTP as communica- tion protocol and the client-side restriction to standard technologies (HTML, JavaScript and AJAX) that are supported by modern browsers. -
Page 73: Installing The Usb Driver
Contact your network administrator if the installation fails. Starting the webConfig tool Prerequisite: The Leuze electronic USB driver for the webConfig tool is installed on the PC. Connect the operating voltage to the BPS. Connect the SERVICE USB interface of the BPS to the PC. -
Page 74: Short Description Of The Webconfig Tool
Leuze electronic webConfig tool – Extended configuration Process Service Changing the operating mode ( ) (upper left) Figure 9.1: The start page of the webConfig tool The user interface of the webConfig tool is largely self-explanatory. The webConfig tool is completely contained in the firmware of the BPS. -
Page 75: Configuration Function
Leuze electronic webConfig tool – Extended configuration Functions Process In the operating mode, the webConfig tool has the following main menus and functions: HOME • Information on the connected BPS as well as on installation. This information corresponds to the information in the current technical description. - Page 76 Leuze electronic webConfig tool – Extended configuration Overview of the webConfig configuration functions CONFIGURATION Figure 9.2: webConfig function webConfig configuration parameters *: PROFINET parameter, see chapter 8.6 **: Parameter can only be configured via webConfig DEVICE Configuration of the switching inputs/outputs ( tab) •...
- Page 77 Leuze electronic webConfig tool – Extended configuration Timing functions The timing functions of the position and velocity measurements (e.g., start-up delay) can only be config- ured with the webConfig tool. The configuration of the timing functions is not overwritten by the PROFINET master on start-up.
-
Page 78: Alignment Function
Leuze electronic webConfig tool – Extended configuration DATA PROCESSING Velocity Detection Configuration of velocity detection ( tab, – • Velocity measurement averaging * • Error handling procedures * DATA PROCESSING Measurement data Velocity Configuration of velocity monitoring ( tab, –... -
Page 79: Process Function
Leuze electronic webConfig tool – Extended configuration ALIGNMENT Figure 9.4: webConfig function PROCESS 9.3.3 function PROCESS Process function serves to control the current measurement data in the operating mode. The measurement results are output in tabular form – strictly as monitor output. -
Page 80: Maintenance Function
Leuze electronic webConfig tool – Extended configuration DIAGNOSTICS The device event log is displayed with the function. DIAGNOSTICS Figure 9.6: webConfig function MAINTENANCE 9.3.5 function MAINTENANCE Service function is only available in the operating mode. Functionalities: • User management • Devices Backup/Restore •... - Page 81 Leuze electronic webConfig tool – Extended configuration MAINTENANCE Figure 9.7: webConfig function Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com...
-
Page 82: Diagnostics And Troubleshooting
NOTICE Contact Leuze electronic subsidiary/customer service. If you are unable to rectify a fault, contact the Leuze electronic branch responsible for you or call the Leuze electronic customer service (see chapter 12 „Service and support“). 10.1.1 PROFINET-specific diagnostics The following diagnostics options are available with PROFINET: •... -
Page 83: 2Diagnostics With Webconfig Tool
DIAGNOSTICS Figure 10.1: webConfig function 10.2 Operating displays of the LEDs You can ascertain general causes of errors via the PWR and BUS status LEDs (see table 10.5). Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 84: Error Messages On The Display
Possible cause Measures • No supply voltage connected • Check supply voltage to the device • Contact Leuze electronic customer ser- • Hardware error vice(see chapter 12 „Service and support“) • No bar code in the scanning • Query BCB diagnostic data and carry out... - Page 85 • Check configuration, in particular with respect to address assignment (device names/IP address/MAC ID) • Incorrect configuration • Check configuration, in particular with respect to address assignment (device names/IP address/MAC ID) Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com...
- Page 86 • Wrong bar code tape • Change BPS configuration to the Faulty measure- BCB grid different from BPS bar code tape that is being used ment value configuration Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com...
-
Page 87: Care, Maintenance And Disposal
Self-printed bar code tape should not remain in the system on a permanent basis. Repair bar code tapes in lengths of 1 m can be ordered from Leuze electronic on request. If a bar code tape was damaged, e.g., by falling parts, you can download a repair kit for the BCB from the Internet. -
Page 88: Disposing
000030 Figure 11.2: Checking the print results of the BCB8 repair kit (30 mm grid 11.3 Disposing For disposal observe the applicable national regulations regarding electronic components. Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 89: Service And Support
Repair service and returns Procedure and Internet form can be found at Leuze website. Return address for repairs: Service center Leuze electronic GmbH + Co. KG In der Braike 1 D-73277 Owen / Germany 12.1 What to do should servicing be required? -
Page 90: Specifications
At a reading distance beyond 100 mm, the reading field width is 160 mm (see figure 13.1, BPS reading field curve). -100 Figure 13.1: BPS reading field curve Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... - Page 91 (H x W x D) 108.7 mm x 100.0 mm x 48.3 mm Dimensions (with MS 348 connection hood) (H x W x D) 108.7 mm x 100.0 mm x 48.3 mm Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com...
-
Page 92: 2Bps With Heating
Ambient temperature (storage) -35 °C … +70 °C 13.2 Bar code tape Table 13.9: BCB dimensions BCB8 Grid 40 mm 30 mm Standard height 47 mm 47 mm Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... - Page 93 Behavior in fire Self-extinguishing after 15 s, does not drip Mounting surface Grease-free, dry, clean, smooth Mechanical properties Scratch and wipe resistant, UV resistant, moisture resis- tant, partly chemical resistant Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com...
-
Page 94: Dimensioned Drawings
Specifications 13.3 Dimensioned drawings all dimensions in mm Reference point for the bar code position Figure 13.2: Dimensioned drawing BPS without connection hood Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... - Page 95 Figure 13.3: Dimensioned drawing BPS with MS 348 connection hood all dimensions in mm Figure 13.4: Dimensioned drawing BPS with MK 348 connection hood Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com...
-
Page 96: Dimensional Drawings: Accessories
13.4 Dimensional drawings: Accessories all dimensions in mm Figure 13.5: Dimensioned drawing MS 348 connection hood all dimensions in mm Figure 13.6: Dimensioned drawing MK 348 connection hood Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... - Page 97 Specifications all dimensions in mm Figure 13.7: Dimensioned drawing BTU 0300M-W mounting device all dimensions in mm Figure 13.8: Dimensioned drawing BT 300-W mounting bracket Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com...
- Page 98 Clamp profile for fastening to round or oval pipes (Ø 16 … 20 mm) Rod holder, turnable 360 ° Figure 13.9: Dimensioned drawing BT 56 mounting device all dimensions in mm Figure 13.10: Dimensioned drawing BT 300-1 mounting device Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com...
-
Page 99: Dimensioned Drawing Bar Code Tape
Figure 13.11: Dimensioned drawing bar code tape BCB with 40 mm grid 1,28 28,72 BCB8 000018 BCB8 000021 BCB8 000024 all dimensions in mm Figure 13.12: Dimensioned drawing bar code tape BCB8 with 30 mm grid Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 100: Ordering Information And Accessories
Table 14.1: BPS 348i type overview Part No. Part designation Description 50124981 BPS 348i SM 100 D H BPS with PROFINET RT interface, display and heating 50124982 BPS 348i SM 100 D BPS with PROFINET RT interface and display 50124983... -
Page 101: Other Accessories
BPS without adjustment (easy-mount). 50121433 BT 300 W Mounting bracket for wall mounting 50027375 BT 56 Mounting device for rod 50121434 BT 300-1 Mounting device for rod Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 102: Bar Code Tapes
Bar code tape, 60 m length, 47 mm high 50104798 BCB8 070 Bar code tape, 70 m length, 47 mm high 50104799 BCB8 080 Bar code tape, 80 m length, 47 mm high Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... - Page 103 Part designation Description 50120380 BCB twin tape special length, BCB twin tape, 47 mm high; delivery contents: 47 mm high Two bar code tapes with the same value range Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com...
-
Page 104: Ec Declaration Of Conformity
The bar code positioning systems of the BPS 300 series have been developed and manufactured in accor- dance with the applicable European standards and directives. The manufacturer of the product, Leuze electronic GmbH + Co. KG in D-73277 Owen, possesses a certi- fied quality assurance system in accordance with ISO 9001. -
Page 105: Appendix
16.2.1 BCB bar code tape with 40 mm grid 000000 000004 000008 000012 Figure 16.1: Continuous, 40 mm grid Figure 16.2: Single label MVS, 40 mm grid Figure 16.3: Single label MV0, 40 mm grid Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... -
Page 106: 2Bar Code Tape Bcb8 With 30 Mm Grid
BCB8 000006 BCB8 000009 BCB8 000012 Figure 16.5: Continuous, 30 mm grid Figure 16.6: Single label MVS, 30 mm grid Figure 16.7: Single label MV0, 30 mm grid Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com... - Page 107 Appendix Figure 16.8: Single marker label, 30 mm grid Leuze electronic BPS 348i Buy: www.ValinOnline.com | Phone 844-385-3099 | Email: CustomerService@valin.com...
