ASIC DESCRIPTION AND OPERATION
2
Introduction
Regarding the type of measuring transducer different chapters should be considered since the types
differ in functionality and design. More detailed description of device functions is given in chapter Type
differences. Al types of measuring transducers are available in DIN or ANSI housing. Instruments in DIN
housing are marked as types MT 5xx; instruments in ANSI housing are marked as types UMT 5xx.
Specifications of housing for both types are specified in chapter Dimensions.
1.1.1 Description of symbols
In different chapters or tables different symbols may appear in User's Manual. According to the position
of symbols, they have different meaning.
Chapter
Due to differences among devices, some chapters do not relate to your instrument. Five symbols next
to chapter heading are for faster surveying. Type of symbol indicates to which extent the chapter applies
for each type of measuring transducer. Meaning of each symbol is:

− Function not supported

− Function partially supported (see a note)

− Function completely supported
Each of the three positions, where the symbols are indicates a Measuring transducer type. Positions
follow from left to right:
(U)MT 511/(U)MT 510/(U)MT 516/(U)MT 518
Subchapter
Symbols next to the subchapters indicate accessibility of functions described. Accessibility of functions
is indicated with the following symbols:
− Function accessible via communication (MiQen software)
Tables
Supported functions and measurements are listed in tables for all types. Symbols in tables indicate
support of enabled functions for each type. Additionally a legend is placed below table of used symbols.
Meaning of symbols is:
● − Function is supported
× − Function is not supported
○ − Symbol meaning varies and is described in the legend below the table
USER INFORMATION
For unknown technical terms please refer to Glossary at the end of the document.
