Iskra MT406 User Manual

Voltage cc current transducer

Advertisement

GB
User's Manual
Voltage Transducer MT406
Current Transducer MT408

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MT406 and is the answer not in the manual?

Questions and answers

Summary of Contents for Iskra MT406

  • Page 1 User’s Manual Voltage Transducer MT406 Current Transducer MT408...
  • Page 3: Table Of Contents

    Table of contents  Table of Contents     SECURITY ADVICE AND WARNINGS ________________________________________ 1   1.1 Welcome --------------------------------------------------------------------------------------------- 2   1.2 Introduction ----------------------------------------------------------------------------------------- 2   1.3 Health and safety ----------------------------------------------------------------------------------- 2   1.4 Safety warnings and instructions for use -------------------------------------------------------- 2   1.5 Warnings, information and notes regarding designation of the product ------------------- 3  ...
  • Page 5: Security Advice And Warnings

    Security advice and warnings SECURITY ADVICE AND WARNINGS   1.1 Welcome --------------------------------------------------------------------------------------------- 2   1.2 Introduction ----------------------------------------------------------------------------------------- 2   1.3 Health and safety ----------------------------------------------------------------------------------- 2   1.4 Safety warnings and instructions for use -------------------------------------------------------- 2   1.5 Warnings, information and notes regarding designation of the product ------------------- 3 User’s Manual ...
  • Page 6: Welcome

    Installation and use of devices also includes handling with dangerous currents and voltages and shall therefore be carried out by qualified persons. The Iskra MIS Company assumes no responsibility in connection with installation and use of the product. If there is any doubt regarding installation and use of the system in which the instrument is used for measuring or supervision, please contact a person who is responsible for installation of such system.
  • Page 7: Warnings, Information And Notes Regarding Designation Of The Product

    Compliance of the product with European CE directives. Contents of consignment The consignment includes: − Measuring transducer MT406/408 − Quick guide. User’s Manual  3 ...
  • Page 8: Basic Description And Operation Of Measuring Transducer

    Basic description and operation of measuring transducer BASIC DESCRIPTION AND OPERATION OF MEASURING TRANSDUCER   2.1 Introduction ----------------------------------------------------------------------------------------- 5   2.2 Glossary --------------------------------------------------------------------------------------------- 5   2.3 Description of the product ------------------------------------------------------------------------ 6   2.4 Purpose and use of measuring transducer ------------------------------------------------------ 6 4  User’s Manual...
  • Page 9: Introduction

    2.1 Introduction MT406 and MT408 are voltage / current transducers with minimal differences in functionality. Where there are some characteristic features that denote MT406 or MT408 symbol next to data. User information For unknown technical terms please refer to Glossary.
  • Page 10: Description Of The Product

    2.4 Purpose and use of measuring transducer Voltage transducer MT406 The MT406 voltage transducer is used for a permanent monitoring of a single-phase voltage value. PLCs, PCs, microprocessor control, indicators, alarms units etc. can be operated by the output signal.
  • Page 11: Connection

    Connection CONNECTION   3.1 Introduction ----------------------------------------------------------------------------------------- 8   3.2 Mounting -------------------------------------------------------------------------------------------- 8   3.3 Electric connection --------------------------------------------------------------------------------- 8 User’s Manual ...
  • Page 12: Introduction

    3.2 Mounting MT406/408 measuring transducer is designed for panel mounting. It should be mounted on a 35 mm DIN rail by means of one plastic fastener. Before installation fastener should be in open position (pulled). After device is on place, fastener is locked (pushed) to close position.
  • Page 13 Connection System/ connection Terminal assignment MT406 Voltage measurement MT408 Current measurement Warning! For safety purposes it is important that both wires are firmly connected. They should be connected only to the designated terminals as shown on the label above as well as on the front foil.
  • Page 14: Technical Data

    Technical data TECHNICAL DATA   4.1 Applied standards --------------------------------------------------------------------------------- 11   4.2 Accuracy -------------------------------------------------------------------------------------------- 11   4.3 Measuring input ----------------------------------------------------------------------------------- 12   4.4 Measuring output ---------------------------------------------------------------------------------- 12   4.5 Connection ----------------------------------------------------------------------------------------- 12   Permitted conductor cross-sections ....................... 12   4.6 Safety features ------------------------------------------------------------------------------------- 13  ...
  • Page 15: Applied Standards

    Frequency influence: 0,5% / ( 10Hz) ∆ Burden influence: 0,1% / ( / 2) ∆ R bmax MT406 Reference value: Output end value Basic accuracy: Class 0.5, Reference conditions: Voltage 20% … 100% x U Ambient temperature range 15 … 30°C Frequency ±...
  • Page 16: Measuring Input

    50, 60 Hz Measuring frequency range ± 10% Consumption < 2 VA MT406 57,7, 63.5, 69.3, 100, 110, 115, 120, 127, 220, 230, Standard nominal input voltage (U 240, 250, 380, 400, 415, 440, 500 V Measuring range limit values 0...50 V to 0...500 V...
  • Page 17: Safety Features

    - 10 … 15 … 30 … 55 °C Acc. to EN 60688 Operating temperature - 20 to + 70 °C Storage temperature - 40 to + 70 °C ≤ 93% r.h. Average annual humidity ≤ 2000 m Altitude 4.9 Dimensions Construction Appearance Measuring transducers MT406/408 User’s Manual  13 ...
  • Page 18 Technical data Iskra MIS, d. d. Ljubljanska cesta 24a SI-4000 Kranj, Slovenia Phone: 04 237 21 12 Fax: 04 237 21 29 E-mail: info@iskra-mis.si www.iskra-mis.si Printed in Slovenia • Subject to change without notice • Version 1.01 / Feb. 2011 • GB K 22.496.503 14  User’s Manual...

This manual is also suitable for:

Mt408
