CONNECTION
User's Manual
Introduction
Before use: Check voltages, supply voltage and nominal frequency.
Check protective fuse rating (the recommended maximum rating of the external protective fuse for this
equipment is 6 A - Red Spot type or equivalent).
WARNING!
Wrong or incomplete connection of voltage, protective ground or other terminals can cause
malfunction or damage the device.
PLEASE NOTE
After connection, settings have to be performed via communication or remote display
(connection mode, current and voltage transformers ratio ...).
Mounting
(U)MT 51x measuring transducer is designed for panel mounting. It should be mounted on a 35 mm DIN
rail by means of three plastic fasteners. Before installation fasteners should be in open position (pulled).
After device is on place, fasteners are locked (pushed) to close position.
7
