4.

Preparation and Setup

Consider the weight and dimension of the product for installation.
NOTICE
4.1

Arranging the Workspace

For best results:
1. Choose a stable, level workspace to install and operate the Form Cure.
2. Reserve the following minimum dimensions for the most convenient access:
° Width: 36 cm (14 in)
° Depth: 36 cm (14 in)
° Height: 64 cm (25.2 in)
° The cover opens upward from the front to allow inserting and removing printed parts
from the turntable. To fully open, the Form Cure requires an additional clearance of 30
cm (12 in) above the unit for a total clearance height of 64 cm (25.2 in). The Form Cure
unit weighs 5.6 kg (12.4 lb).
3. Allow additional space for accessories, such as the Formlabs SLA printer, Finish Kit, and
Form Wash.
4. Ensure either the wall outlet or power supply for the Form Cure is easily accessible. To
disconnect the equipment from mains electricity and power off the unit, unplug the power
cable from the wall outlet, or the power supply.
4.2

Unboxing the Form Cure

The Form Cure ships in a cardboard carton, protected by foam inserts above and below the
machine. The upper foam insert also contains the accessories. During unboxing, inspect the
Form Cure for any damage or missing items. In the case of damage or missing items, contact
Formlabs or the certified service provider.
To unbox the Form Cure:
1. Open the box from the top.
2. Lift and remove the foam insert containing the power supply.
3. Lift the Form Cure out of the box.
4. Remove the turntable, located at the bottom of the box.
Remove all packaging material before connecting power. Retain all packaging and
inserts for warranty service.
NOTICE
4.3

Installing the Form Cure

To install the Form Cure:
1. Find a clean, level surface with a nearby power source.
2. Remove the thin plastic wrapper from the Form Cure exterior.
3. Lift the cover.
Insert the turntable on the circular wheel mount at the base of the cure chamber.
4
Connect the power cable and external supply to the Form Cure and a power source.
5
