OPERATING INSTRUCTIONS
ELV2-BLK-FS/ELV2-WHT-FS
B5 SEAT HEIGHT ADJUSTMENT B5 SEAT HEIGHT ADJUSTMENT
B6 BACKREST TILT ANGLE ADJUSTMENT
B6 BACKREST TILT ANGLE ADJUSTMENT
D2 SEAT DEPTH ADJUSTMENT
B5

SEAT HEIGHT ADJUSTMENT

While seated, pull the single control lever
upward and hold it while raising or lowering
the seat to reach your desired seat height.
When the lever is released to its original
position, the seat height is locked.
The seat height adjustment range is
approximately 3.54".
B6

BACKREST TILT ANGLE ADJUSTMENT

While seated, pull the single control
lever completely backward and lean
against the back. When your desired
angle is achieved, return the lever to the
original middle position to lock your tilt
angle into place. There are 4 positions
that provide 21º of range.
