- Page 1 LAU1 ASSEMBLY INSTRUCTIONS OPERATING INSTRUCTIONS WARRANTY CUSTOMER SERVICE: parts@raynorgroup.com CUSTOMER SERVICE: 1-800-637-0005 www.eurotechseating.com...
-
Page 2: Parts List
ASSEMBLY INSTRUCTIONS LAU1 Remove all items from the carton. Verify all pieces before assembly. PARTS LIST Description Part Qity. 5 pcs Caster 1 pcs Star Base 1 pcs Cylinder 1 pcs Mechanism & Seat Cushion 1 pcs Backrest & Lumbar Support... - Page 3 ASSEMBLY INSTRUCTIONS LAU1 Remove all items from the carton. Verify all pieces before assembly. STEP 1 STEP 2 STEP 3 Please be careful to use the correct armrest (G) which are marked Left and Right. For easy assembly, place the Seat Cushion...
- Page 4 OPERATING INSTRUCTIONS LAU1 Remove all items from the carton. Verify all pieces before assembly. SEAT HEIGHT ADJUSTMENT. B BACK TILT ADJUSTMENT. C SEAT DEPTH ADJUSTMENT. LOCK UNLOCK While seated, pull the lever on the right side While seated, turn the knob on the left side...
