HANYOUNG NUX TPR-3SL-EP Instruction Manual page 2

(021)33985010-33985020
Part name and function
LED display
POWER
L.L
1 RTX+
Signal and
2 RTX-
alarm terminals 3
+
4 -
5
+
6 -
7 +
8 -
9
10
11
12
TPR-3SL040H-EP
LOAD
Rated voltage : 100 V - 440 V
•
Maximum rated current : 40 A
•
Separate power
input terminal
50
4-6.5
4-8
█ Indicating LED and functions
LED indicator
110
name
POWER POWER indicator is ON when the power is being supplied to the control unit
CH1 Lights up when an alarm related to channel 1 occurs.
CH2 Lights up when an alarm related to channel 2 occurs.
CH3 Lights up when an alarm related to channel 3 occurs.
• When the heater is configured in parallel with the partial heater disconnection function,
at least one of them is disconnectedThis function is to maintain the process while
detecting the heater disconnection.
• Detectable when using less than 3 parallel heaters.
(In case of 4 or more parallel configurations)
• The total load capacity is not detected within the range of less than 6A and 0 to 20%.
• Part heater disconnection detection operation method (scan function)
L.L - Corresponds to phase control, variable cycle control
- After circuit and load power supply is turned on, the LL LED flashes
0 to 100% The heater value is detected while sequentially outputting the output.
- If the initial scan function is used only once after connecting the heater, the value
stored in the internal CPU Therefore, no further operation is required in the future.
- If you do not use the scan function and leave the initial mode 2 ON,
Partial heater disconnection function is activated.
It is not precise in the way that it is detected by calculation formula automatically.
• The LED flashes when the heat sink temperature rises above 60 ° C during
control, Operation is normal, and if the heatsink temperature drops below about
OT 50 °C Will be released.
• If the heat sink temperature rises above 80 ° C during control, the LED will light
up and TPR output will stop.
• When an overcurrent occurs, it will light up if a current above a set value
is generated to protect the product and load, Operation stop
O.C
(can be set by communication)
• FAN failure: Flashing when FAN fails
EMG LED lighting situation is as follows.
1. Power failure: The load power is turned on when the circuit power
(100 - 240 V a.c.) is applied Lights when the heater is disconnected.
EMG 2. SCR short: When SCR is shorted, the power is on without control input and
TPR output Since the heater continues to overheat, the current continues to flow
without the control input.
The EMG LED flashes when it flows. (10 A or more)
█ Internal dip switch operation
Number OFF
No. 1 - RESET (Functioning stops)
No. 2 load volume scan
Partial load disconnection function
No. 3 Not Using
No. 4
cycle control fixed cycle method
No. 5 -
cycle control variable cycle method
No. 4, 5
No. 6 Not Using
No. 7 use all 1, 2, 3 channels
3 channel function fixed
No. 8 -
No. 7, 8 Check 8 LED lights
※ The reset operates after turning off the switch 1 and turning it on again through the CPU reset
www.AltonSegal.com
213.7
50
4-6.5
4-8
CH1 CH2 CH3
OT O.C EMG
Soft start or
O.C
UP/DOWN setting volume
CH1
SOFT
CH2
N.C
CH3 Communication dip switch
1
2
3
4
ALARM1
(Caution) 5
110
6
7
ALARM2 8
(Warning)
OFF ON
Internal dip switch
1
2
3
4
5
POWER
6
100 - 240 V ~
~ 7
50 / 60 Hz 18 W
8
173
ON
OFF
15 13 14
160
213.7
50
4-6.5
194.6
4-8
Load terminal
99.1
110
Description
ON Initial setup mode
Restart mode
Phase control
4 - 20 mA d.c.
1. Input mode : 4 - 20 ㎃ d.c.
-
2. Control Mode: Phase control
Appearance
█ 40A / 55A / 70A
50
173
4-6.5
213.7
160
4-8
50
194.6
4-6.5
194.6
4-8
110
99.1
99.1 110
213.7
173
50
239.1
194.6
4-6.5
160
213.7
220.5
4-8
194.6
110
99.1
125
Communication specifications (communication setting dip switch)
1. Communication method: RS485 2-wire half-duplex
2. Communication speed : 2400, 4800, 9600, 19200 bps
3. Maximum number of connections : 31 pcs
4. Protocol : ModBus RTU, ModBus ASCⅡ
Address(ID) settings
█
•You can set the ID through the DIP S/W from 1 to 5.
•Set from 1 to 31.
•Please reset when you change the communication settings
예)
Communication speed setting
█
•Set the baud rate to 6 or 7 in DIP S / W
2400 bps
Select communication protocol
█
•Set the communication protocol to No. 8 of DIP S / W.
2
telegram.me/altonsegal
█ 90A
213.7
173
239.1
194.6
160
220.5
99.1
125
173 173
160
160
239.1
220.5
99.1
125
ID:1
ID:3
ID:5
2400 bps
4800 bps 9600 bps 19200 bps
RTU
RTU
█ 130A / 160A
239.1
173 173
160
220.5
160
239.1
220.5
125
173
239.1 239.1
160
220.5
220.5
125
125
ID:2
ID:4
ID:6
ASCⅡ
