IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR USING
YOUR CHANTELLE DAY BED WITH TRUNDLE FRAME
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE
HEALTH & SAFETY
DO NOT jump on this bed frame
DO NOT use this bed frame if any parts are missing, damaged or worn
DO NOT use this bed frame unless all fixings are secured
Please keep small parts out of reach of children
Always use on a level, even surface
WARNING: If this bed is placed on a non-carpeted floor you must place some protection
under all legs to stop the bed frame from moving. If this is not adhered to there is no
guarantee if the bed frame collapses.
CARE & MAINTENANCE:
Assemble in the room of use.
Periodically check all screws & fixings to ensure they are secure.
DO NOT push the bed frame as this will damage the legs.
Always lift the bed with two people to reposition.
Keep any sharp objects away from the frame.
Birlea
Suppliers of Inspiration
ASSEMBLY INSTRUCTIONS
CHANTELLE DAY BED WITH TRUNDLE
www.birlea.com
Vendor: S000053
Page 1 of 4
