Page 2: Hardware List
Code: S000238 Left headboard post (117 x 8.2cm) - Box 2 1 Headboard panel Right headboard post (117 x 8.2cm) - Box 2 (132 x 50.6cm) - Box 1 2 Headboard rail Left footboard post (63 x 8.2cm) - Box 2 (132 x 9.2cm) - Box 1 Right footboard post (63 x 8.2cm) - Box 2... - Page 3 Code: S000238 Step 1: Join the support legs (11) to the centre rail using hardware N and G. Insert hardware part B to the side rails (8) using a small mallet (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 2: Insert hardware part A to the headend panel (1), footboard panel (3) and Headboard rail (2) using a small mallet (not provided).
- Page 4 Code: S000238 Step 3: Attach the left headend post (4) and right headend post (5) to the headend panel (1) using hardware parts N and H. DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 4: Attach the left footend post (6) and right footend post (5) to the footend panel (3) using hardware parts N and H.
- Page 5 Code: S000238 Step 5: Fix hardware part L to the headend panel (1) and footend panel (3) using hardware part C and a screwdriver (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 6: Attach the side rails (8) to the headend posts using hardware parts N, J and K.
- Page 6 Code: S000238 Step 7: Attach the footend using hardware parts N, J and K and fix the centre rail (9) in place using hardware parts E and F with an M11 spanner (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 8: Fix slats (10) to the side rails and centre rail using hardware parts O and D with a screwdriver (not provided).
- Page 7 Code: S000238 Step 9: Insert hardware part M using a small mallet (not provided). DO NOT use any power tools as this may damage the frame and will invalidate any claim. 50mm 160mm 40mm 40mm Page 7 of 7...
-
Page 8: General Care And Maintenance
floor as this will cause damage to the joints and could result in failure to the product that will invalidate the warranty. For more information on cleaning and product care visit: https://www.happybeds.co.uk/help-and-advice Notes We’ve tried to make this product as easy to assemble as possible. In the unlikely event that...
