Major 1150 Slurry Vac Operator's Manual & Parts List

Hide thumbs
Table of Contents

Advertisement

Quick Links

Operator's Manual & Parts List
MAJOR
Standard, LGP,
Alpine, Challenger
and Tandem
Tankers

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1150 Slurry Vac and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Major 1150 Slurry Vac

Summary of Contents for Major 1150 Slurry Vac

  • Page 1 Operator’s Manual & Parts List MAJOR Standard, LGP, Alpine, Challenger and Tandem Tankers...
  • Page 2 Major reserves the right to modify the machinery and the technical data contained within the manual without prior notice. Further to this, Major assumes no liability for any damages which may result from the use of the information contained within this manual.

  • Page 3: Table Of Contents

    Contents Introduction Thank you Safety Aspects Intended Use Product Identification Machine Serial Numbers Register Your Product and Warranty Online Product Specification Safety Machine Safety Labels General Precautions Hazards associated with operating Slurry Tankers Operating Safely Workstation Regulations for use of the transmission PTO Shaft Safety Driving Safely on Public Roads Operating conditions...
  • Page 4 ISO 3767-1: 1998 + A1-2008. Tractor and machinery for agriculture and forestry. Symbols for operator controls and other displays. I hereby certify on behalf of Major Equipment Int. Ltd., that this machine when properly installed and operated correctly, complies with all the essential Health & Safety requirements of all legislation referred to above.

  • Page 5: Thank You

    A centrifugal pump can also spread the material though a medium pressure outlet. Product Identification Machine Serial Numbers If you need to contact MAJOR or your MAJOR dealer for information on servicing or spare parts, always provide the product model and serial numbers. We suggest that you record your machine details below:...

  • Page 6: Product Specification

    15 x 22.5 1150 5228 4.95m 2.31m 2.9m 2120 7347 16.5 x 22.5 1150 5228 4.95m 2.31m 2.9m 2120 7347 1150 Slurry Vac 550/45/22.5 1150 5228 4.95m 2.31m 2.9m 2120 7347 550/60/22.5 1150 5228 4.95m 2.31m 2.9m 2120 7347 21.3 R24...
  • Page 7 3.44 750/45-22.5 (Steering axle) 18386 9.35 2.87 3.44 Model 3500C 3500 Gallons Capacity 15911 Litres OA Length (Hitch to coupling ball) 8.06m OA Width (Tyre dependant) 2.64m OA Height (Add tractor hitch) 3.6m Weight (Empty) 7600Kg Weight (Full) 22300Kg www.major-equipment.com...

  • Page 8: Safety

    To avoid injury, read the manual Max tractor input PTO speed Max speed 30 km/h General warning of slurry gases. Hydraulic oil warning and vacuum PTO Shaft Warning pump operations label Check wheel nuts daily Pump safety device Noise hazard www.major-equipment.com...

  • Page 9: General Precautions

    The acoustic pressure was measured at a distance of 2.6m from the centre of the machine and at a height of 2.0m, with the implement operating in a no load condition - 90 dBA. In a loaded condition & a PTO rate of 540 rpm the obtained value was 97dBA. www.major-equipment.com...

  • Page 10: Operating Safely

    The operator must remain seated while working the machine. Always ensure the PTO has been turned off and the parking brake applied before leaving the tractor cab. The operator must always apply the parking brake, and turn off the engine before leaving machine or carrying out maintenance. NEVER OPERATE THE HYDRAULICS WITH THE TRACTOR SWITCHED OFF www.major-equipment.com...

  • Page 11: Regulations For Use Of The Transmission

    Disengage the PTO and disconnect the driveline when transporting the implement. MAXIMUM TRANSPORT SPEED MUST NOT EXCEED 30 km/hr (18 MPH). www.major-equipment.com...

  • Page 12: Operating Conditions

    It is advisable to drive up and down the slope as oppose to across the slope. Alpine tankers models have a centre of gravity lowered by at least 100mm (depending on the model) compared to a standard LGP tanker. Therefore the Alpine tankers are more suitable to operation on hilly ground. 226 LOWER 1250 COG ALPINE 1379 COG LGP www.major-equipment.com...

  • Page 13: Key To Main Parts

    Gate Valve Hitching to the Tractor 1. The MAJOR tank chassis hitch point is designed for both pick up hold and drawbar. 2. Attach the tanker hydraulic hose to tractor hydraulic circuit. 3. Attach the hoses (Labelled) to the appropriate circuit.

  • Page 14: Operating The Machine

    Do not use the Rotary blades vacuum pump at pressures, temperatures, times higher than those indicated in Table 6. During use do not exceed the speed and power limits set in this manual. Do not overload the machine or suddenly engage the P.T.O. www.major-equipment.com...
  • Page 15 (Blow off) Handle Neutral position allows tank to vent. Should be Pump Front Gearbox Handle Filler in this position if using Extension Garda Pump PTO Guard Oil Filler and Level PTO Input Front Gearbox Vacuum tank for filling Level www.major-equipment.com...

  • Page 16: Hydraulic Powered Vacuum Pump

    ‘B’ until a steady ‘B’ until a steady 0.7 bar 0.7 bar is achieved on is achieved on the clock the clock while pump is pump is pressurising pressurising tanker tanker. • Tighten Locking • Tighten Locking screw Collar. www.major-equipment.com...

  • Page 17: Automatic Emergency Brake

    Before disconnecting the tanker, ensure that R-clip is positioned as shown on the diagram. When reconnected, depress the brake pedal fully for approximately 20 seconds to recharge the accumulator. Tanker Tractor Tanker Tractor R-Clip Accumulator Brake Hose Esure that the wire rope from the R-Clip is connected to the brakes hydraulic hose www.major-equipment.com...

  • Page 18: 6" Autocoupler

    5. Open the gate valve on the boom using separate spool. 6. When the tank is full, close the gate valve, stop the PTO and raise the boom into the transport position & change vacuum pump to pressure position. www.major-equipment.com...

  • Page 19: 8" Autocoupler

    Do not select gear lever from the vacuum pump to the centrifugal pump while the tractor PTO is rotating or gears could be damaged. P = Pressurise Tank for spreading N = Neutral position allows tank to vent. Should be in this position if using Garda Pump V = Vacuum tank for filling www.major-equipment.com...

  • Page 20: Centrifugal Pump

    LADES (G90) LADES (G90) bolts and remove housing nut (G37). The chopper countersunk bolts to re- GAP OF 2.5-3MM WHEN ASSEMBLED. WHEN ASSEMBLED. (G88) first blade (G89) pulls of the move couter blades (G90) keyed shaft (G92) ASSEMBLED. ASSEMBLED. www.major-equipment.com...

  • Page 21: Operation Of The Rain Gun

    5. Periodically check stone trap filter. Stone trap filter is held in place by a 4” BSP thread. Cyclone Trap Do not attempt to open cyclone trap when pressurised Check for sediment periodically by opening the drainage cock located underneath the Cyclone www.major-equipment.com...

  • Page 22: Top Fill

    IMPORTANT Hydraulic hoses must be correctly connected. The ¼” hose is the feed hose and the ½” hose is the return line. The Return line must return. Damage to the hydraulic motor can occur if hoses are connected incorrectly. www.major-equipment.com...

  • Page 23: Over Hedge Boom

    15°. This will prevent excessive wear of tyres. When reversing or driving forward at speeds above 15km/h, rear axle will align with the front one. Two shock-absorbers stand for the stability of the free steering axle by preventing too significant vibrations. www.major-equipment.com...

  • Page 24: 6" Rear Filler

    Don’t stand near tank openings or stoop to floor level when mixing is in progress • Never enter a below ground level tank unless there is no alternative. If you have to go in wear a lifeline held by two men. www.major-equipment.com...

  • Page 25: Maintenance Schedule

    ● ● Drain air brake tank (if fitted) ● ● NOTE: Change oil in vacuum pump gearbox & Garda pump gearbox after first 50 hours (running in period) and every 300 working hours following that. ISO VG 460 oil. www.major-equipment.com...
  • Page 26 Your tanker will have excessive stability problems on undulating ground if one tyre is under nflated on one side. 3. Over Inflation: Results in a reduced area of contact with the road and greater wear on the tread centre which makes your tyres more susceptible to impact damage. www.major-equipment.com...
  • Page 27 24 hours. Before ventilating, fill the tanker up with clean water and then discharge the tanker. it under pressure (repeat at least twice), this will wash off any loose sediments and get rid of most of the slurry fumes inside the tanker. www.major-equipment.com...

  • Page 28: Changing A Wheel On A Tanker

    Never try lifting a tanker when it is full. Empty the tanker to minimise weight shift. MAJOR recommends that all wheel changing works are carried out by the dealer, whose workshop is fitted with special equipment (crane/jack, trolley, etc.) for lifting the tanker and removing wheels.
  • Page 29 Re-set bearing adjustment nuts to give bearing end-float. Bearings The bearings used in MAJOR axles are of the finest materials, and produced to exacting standards. They are selected to give the user considerable service life. To protect this longevity, the following procedure is recommended when servicing is required:- Immerse cups and cones in a suitable cleaning solution.
  • Page 30 End Float All MAJOR Drum Braked axles are fitted with two rows of tapered roller bearings. To protect normal bearing life, these bearings must not be subjected to preload during assembly and service. End float of between 0.05 and 0.15 mm is therefore recommended.
  • Page 31 How to disassemble the pump - Front Assembly PTO: 1. Unscrew the screws of the gearbox cover; 2. Use two screws for screwing into the threaded extraction holes until the cover is removed; 3. Remove the gear with splined shaft using an extractor if necessary; www.major-equipment.com...
  • Page 32 4. Insert the 6 clamping screws in the holes and tighten them; 5. Fit the bearing on the flange using a drift; 6. Insert the spacer; 7. Re-fit the back cover or the lubrication pump (together with the connector joint) on the flange. www.major-equipment.com...
  • Page 33 8. Position the manifold cover on the manifold; 9. Tighten the mounting screws on the manifold cover; 10. Install the oil seal into its seat on the manifold cover; 11. Install the handle and tighten it using the screw provided; Refitting the pump - front www.major-equipment.com...

  • Page 34: Garda Pump Maintenance

    Before starting the pump, make sure the rotor has not dropped down accidentally. This can be accomplished by making sure the cut machined into flange lines up with the cut machined into pump body. Cut for aligning flange with Flange slot pump body Garda Pump www.major-equipment.com...
  • Page 35 - Excellent resistance to oxidation - Strong anti-rust property - Excellent anti foam power - Working temperature from -5 °C to 160 °C IF “VACUUM PUMP OIL” IS NOT AVAILABLE, USE ONLY NEW MINERAL OIL MEETING ISO VG 100 (SAE 30) www.major-equipment.com...
  • Page 36 (see Figure 7), placed on the side of the gearbox to allow the level to be checked To ensure correct lubrication, the oil should always be visible in the oil level. www.major-equipment.com...
  • Page 37 Figure 9), loosen lock nut “C” and then turn regulator pin “A”. By rotating clockwise lower oil delivery is obtained (-), and by rotating anticlockwise higher oil delivery is obtained (+). When adjustment has been completed tighten lock nut “C” and screw cover. Figure 8 Figure 9 www.major-equipment.com...
  • Page 38 Check that the position of the handle is correct and test that the Rotary blades vacuum pump exhausts or compresses. The running in period foreseen for a rotary blades pump is of 30 of effective working. During that period the working parameters must be reduced of 20%. www.major-equipment.com...
  • Page 39 The same type of breakage can be caused by entrance of sewage or by a too high working pressure. A too high vacuum causes the blades to beat against the cylinder with consequent damage to the outside of the blades. Moreover, the lining becomes wavy. www.major-equipment.com...
  • Page 40 2. Remove the back 3. Extract the blades from the rotor; 4. Replace the blades; 5. Clean the Rotary blades vacuum pump. 6. Re-fit the back of the Rotary blades vacuum pump 7. Use original spare parts only Blade Sizes www.major-equipment.com...
  • Page 41 2. Insert item (B) with the wider part facing inwards, so that the two wider parts come into contact. 3. When you fit the impeller be careful to avoid cutting the rubber of item (B) when the spring is being compressed. www.major-equipment.com...
  • Page 42 4. Unscrew the screws fixing the volute to the support. 5. Remove the volute, together with the external flange, by slipping it off its support. 6. Unscrew the self-locking nut. 7. Remove the impeller from the centrifugal pump shaft. 8. Remove the key. www.major-equipment.com...

  • Page 43: Troubleshooting

    Reconnect correctly incorrectly Hydraulic gate valve doesn’t respond Gas-spring cylinder defect Replace cylinder Fastening eye of the cut-off valve is broken Remove dirt in the cut-off valve box. OR (as a result of frost or dirt) Replace the cut-off valve. www.major-equipment.com...
  • Page 44 Handle incorrectly positioned Position handle correctly Reversing gear badly positioned Position reversing gear correctly No exhaust/compression in Disassemble exhauster/compressor, clean exhauster/compressor All blades jammed and wash rotor blades and body. Rubber ball close overflow valve Increase air passage inside valve. www.major-equipment.com...
  • Page 45 When play or looseness even 0.0025 mm exists between the bearing and shaft, there is a very powerful force tending to rotate the inner race on the shaft. Brake lining has worn out. Replace the brake lining. The brakes don’t function or make noise Wheel bearing is adjusted incorrectly Adjust the wheel bearing. www.major-equipment.com...

  • Page 46: Spare Parts - Tankers

    180719 Spare Parts - Tankers 1150, 1500, 1700 and 2000 Standard Slurry Tanker www.major-equipment.com...
  • Page 47 M16 FLAT WASHER 71 EDOW14 1/4” DOWTY WASHER 32 FWM20 M20 Flat Washer 72 EMM14 1/4” M/M CONNECTOR 33 FWM6 M6 FLAT WASHER 73 111070 DIA 50.5-54mm INSERT 34 HA1 6” SPRING RETURN RAM 74 190.000.545 PTO GUARD (EXTENDED OVAL) www.major-equipment.com...

  • Page 48: Lgp Tanker - Assembly

    LGP Tanker - Assembly www.major-equipment.com...
  • Page 49 LGP Tanker - Assembly www.major-equipment.com...
  • Page 50 6" MALE CONNECTION 3722160 6" FLANGE BLANK SEAL M12x120BZP M12x120 BOLT M12x30SZP M12x30 SET BOLT PUMP M12x35BZP M12x35 BOLT S-MAJOR-007 LGP AXLE SV16A 29" DOOR SEAL M12x50BZP M12x50 BOLT TA-ST100-03 100mm PIPE FLANGE SEAL M12x60BZP M12x60 BOLT M14 NYLOC NUT...

  • Page 51: Alpine Tanker - Assembly

    Alpine Tanker - Assembly www.major-equipment.com...
  • Page 52 Alpine Tanker - Assembly www.major-equipment.com...
  • Page 53 6" HOSE BRACKET R1706-6 6" DOME GATE VALVE 112_PLUG 1 1/2" BSP PLUG R1727 SAFETY VALVE1 1/2" BSP 130020A M20 EYE NUT R1765 1/4" PRESS' GAUGE 3 BAR MAX 3772002 1/2"-1/4" REDUCER NIPPLE SO700 RUBBER BUFFER 3772201 1 1/2"-1/2" BSP TEE www.major-equipment.com...

  • Page 54: 3500 Challenger - Assembly

    3500 Challenger - Assembly www.major-equipment.com...
  • Page 55 Rubber Mudguard Clamp 31 1/CHEX 1” Fine Plain Nut 74 TA-SP021 Support Arm 32 1x5FBZP 1”X5” FINE BOLT 79 R1765 1/4” Press’ Gauge 33 1x6FBZP 1”X6” FINE BOLT 34 380100 Rubber Backed Lighting 35 3770030 Dia 3” Sight Glass www.major-equipment.com...
  • Page 56 THE INFORMATION CONTAINED IN THIS DRAWING IS THE PROPERTY MAJOR OF MAJOR EQUIPMENT INTL. LTD. Vendor: WELDED ANY REPRODUCTION IN PART OR A WHOLE WITHOUT THE WRITTEN www.major-equipment.com PERMISSION OF MAJOR EQUIPMENT INTL. LTD. IS PROHIBITED. 27 FWM16 M16 FLAT WASHER Route: Quantity Date Stock Code: TA-6HC-GA Rev.
  • Page 57 THE INFORMATION CONTAINED IN THIS DRAWING IS THE PROPERTY MAJOR OF MAJOR EQUIPMENT INTL. LTD. Vendor: ANY REPRODUCTION IN PART OR A WHOLE WITHOUT THE WRITTEN www.major-equipment.com PERMISSION OF MAJOR EQUIPMENT INTL. LTD. IS PROHIBITED. Scale Route: Drawn Title Sheet...
  • Page 58 6” Hose JET20 8” To 6” Pipe Reducer 5101200 Circlip 10 BP1101/H 8” Connector 11 GARDA75 Garda Pump 12 GARDA5 Pump Outlet 13 510100 Circlip 14 TGRE100 100mm HOSE 15 GMP320 Hydraulic Motor 16 BP210/E Hydraulic jetter with flange www.major-equipment.com...
  • Page 59 Top Fill Tie Bar TTF-BAR Top Fill Bar M20X90BZP Bolt Nyloc Nut MG16910A Clamp Nut M20X200BZP Bolt TTFRM Hydraulic Ram SV13A Seal 10 M16 Nyloc Nut 11 MG16910B Clamp Bolt 12 M16X75BZP Bolt 13 M20X110BZP Bolt 14 M20X120BZP Bolt www.major-equipment.com...
  • Page 60 SWEEPER RAM 30 R1362-14 1/4" BALL VALVE 12 BLAST_L-24 RAM LINKAGE 13 4716000 4" 'O' RING 14 EDOW14 1/4" DOWTY WASHER 15 EMF38 3/8" M/F CONNECTOR 16 EMM14RV 1/4" M/M RESTRICTOR (DIA 1mm) 2 17 M10 M10 NYLOC NUT www.major-equipment.com...

  • Page 61: Vacuum Pumps

    AM28 Valve Washer Washer AM29 Gasket Spring Plug AM38 Housing Oil Seal AM39 Housing Gasket Ball Seal AM57 Spacer Bolt Shaft Housing Back Cover Housing External scroll flange Body Bolt Gearbox Housing Vane Stud Rotor Washer AM20 Washer Bolt www.major-equipment.com...
  • Page 62 MEC 9000-11000-13500/M-P www.major-equipment.com...
  • Page 63 CM 7 4070113192 Long life blade MEC 9000/M BALLAST CM 5/Mb 4010220159 Rotor BALLAST MEC 11000 CME 7 4070113193 Long life blade MEC 11000/M BALLAST CME 5/Mb 4010220160 Rotor BALLAST MEC 13500 CMEC 7 4070113194 Long life blade BALLAST www.major-equipment.com...
  • Page 64 4010406015 Support flange CM 64 5030210008 Seal ring CM 65 4010601056 Manifold cover CM 66 5050107054 Screw CM 67 4010501026 Manifold Manifold cover CM 68 4030109025 gasket CM 73/2” 4010606020 Tank Oil cover CM 73/2”1/2 4010606021 Tank Oil cover www.major-equipment.com...

  • Page 65: Chopper Pump Parts

    5050107020 Screw M 10x25 TE G 1/MEC-TS 4010301024 TURBO SYSTEM 5012107010 Ball bearing 6307 Central gear wheel 540 RPM Z G 5/540 4020807001 4010601021 Gearbox cover 97 - M 3 5050107028 Screw M 12x35 TE G 14 4010601020 Front cover (75) www.major-equipment.com...
  • Page 66 JET-GK Z 97 - M 3 Central gear GARDA 1000 RPM Z 86 - M 3 G 61 / 1000 wheel High pressure pump coupling G 115 4010407005 flange GARDA/JET Centrifugal shaft for preshaped G 62 / 1000 4020907003 ring GARDA 1000 RPM www.major-equipment.com...

  • Page 67: Glass Eye Locks

    EYE LOCK FLAT 3770030 3” Sight Glass TA-GE008 GLASS EYE RING 3772030 3” Bsp Socket M8HEX M8 PLAIN NUT FWM8 M8 Flat Washer TA-GE004 GLASS EYE RUBBER M10HEX M10 Hex Nut M8x40SZP M8x40 SET M10x50BZP M10x50 Bolt DIPC450DG018 PRESSURE DISC www.major-equipment.com...

  • Page 68: Wired Controls

    Wired Controls   www.major-equipment.com...
  • Page 69 www.major-equipment.com...
  • Page 70 www.major-equipment.com...

  • Page 71: Axles

    33114 070 120 37 57548B6 CROWN NUT M48X1,50 WR65 H44 7 NOTCH 56112518 CAP 125 BOLT ON ADR WITH GASKET 96308A0101 SOCKET HEAD SCREW 466103078 STIFFENING PLATE FOR AXLE SPECIAL TYPE 58209 SPRING PIN FOR NUT M48 7 NOTCH www.major-equipment.com...
  • Page 72 ROLL ASSEMBLY FOR 412E 4218E 738127 SPRING FOR ROLL BRAKE 412E 96701 RIVET 8X15 FOR LINING 734VC02 LINING 406X120 BRAKE 412E 466103078 STIFFENING PLATE FOR AXLE SPECIAL TYPE 75Q4063006 CAM SHAFT D40 B0600 S LEFT 75P4063006 CAM SHAFT D40 B0600 S RIGHT www.major-equipment.com...

  • Page 73: Tandem Axles - Standard Duty

    TANDEM AXLES - STANDARD DUTY www.major-equipment.com...
  • Page 74 TANDEM - steered - BNR2RW1XC001(GF) TANDEM - steered - BNR2RW1XC001(P) www.major-equipment.com...
  • Page 75 TANDEM - steered and fixed - AR2RW1XCN001(GF) TANDEM - steered and fixed - AR2RW1XCN001(P) www.major-equipment.com...
  • Page 76 Item Part No Description 96760960 PLATE R127 B120 BOX CLAMPING LS120 4352010 4X20 R127 U-BOLT E M22X2.50 H295 42122011 W128 RUBBER PLATE 150X120 45306 TK15 WASHER M22 D023 D039 9812201 SP3.0 ISO 7089 SELF LOCKING NUT 97422F1 M22X2,50 CA10 DIN 982 www.major-equipment.com...
  • Page 77 TANDEM - steered - GEK2250 TANDEM - fixed - GEK2560 www.major-equipment.com...

  • Page 78: Steered Tandem Axle - Heavy Duty

    CROWN NUT M52X2.00 WR70 H36 58108 SPLIT PIN 8X36 WITH SAFETY RING D66 56312002 CAP 120 M135X2.00 ADR 74417501 CAMSHAFT SUPP R127 ROUND 40-42 D40 L068 46108306 BRACKET FOR BOOSTER FOR AXLE ROUND 127 742WCR223 SPYDER 42-40 R127 ROUND www.major-equipment.com...
  • Page 79 SEEGER D025 DIN471 FOR SHAFT 76A02 ANCHOR BRACKET 60° FOR AUTOMATIC SLACK ADJUSTER 738201 RETURNING ACTION SPRING D30 AGRICULTURAL BRAKE 75Q4063007 CAM SHAFT D40 B=650 S LEFT SAE 1,5" Z=10 75P4063007 CAM SHAFT D40 B=650 S RIGHT SAE 1,5" Z=10 www.major-equipment.com...
  • Page 80 STEERED TANDEM AXLE - HEAVY DUTY AFTER HR16634 BNRAXL1XCN001_E-A www.major-equipment.com...
  • Page 81 SELF LOCKING NUT M12X1,75 CL8 DIN985 ZINC PLATED 46A187 PLATE SHOCK ABSORBER SUPPORT RIGHT FOR 8214501 96112C0601 SCREW EH M12X1,75 L060 CS08,8 ISO 4014 ZINC PLATED 76A04 ANCHOR BRACKET ALIGNED 74401113 SUPPORT D=38 L=005 FOR CAM SHAFT 462083089 SUPPORT PLATE SPECIAL TYPE FOR CAMSHAFT www.major-equipment.com...
  • Page 82 STUD NUT M22x1,50 CH30 GERMAN TYPE 57B5301 LOCK WASHER FOR M53 57552D1 CROWN NUT M52X2.00 WR70 H36 58108 SPLIT PIN 8X36 WITH SAFETY RING D66 56312002 CAP 120 M135X2.00 ADR 73A65 SUPPORT FOR ABS SENSOR PERIFERIA ZA S150 742WCB223 SPYDER 42-40 R120 ROUND www.major-equipment.com...
  • Page 83 SELF LOCKING NUT M22X2,50 CA10 DIN 982 ZINC PLATED 42122011 U-BOLT E M22X2,50 H295 W128 4352010 BOX CLAMPING LS120 4X20 R127 ARAXL1XCN009 BRAKED AXLE HUB AND DRUM PERIFERIA XL FRENO 4218E BNRAXL1XCN001 SELF STEERING AXLE STA 0° PERIFERIA XL BRAKE 420X180 4218E www.major-equipment.com...
  • Page 84 STEERED TANDEM AXLE - HEAVY DUTY AFTER HR16634 BNRAXL1XCN001_E-C www.major-equipment.com...
  • Page 85 738204 RETURNING ACTION SPRING D30 7632601 SLACK ADJ AUTO SAE Z10 SHIFT30 7632602 SLACK ADJ AUTO SAE Z10 SHIFT30 75P4062003 CAM SHAFT D40 B=225 S RIGHT SAE 1,5" Z=10 75Q4062003 CAM SHAFT D40 B=225 S LEFT SAE 1,5" Z=10 www.major-equipment.com...

  • Page 86: Single Axle - Granning Type

    M22 Din Wheel Nut 10 61371 M22 Din Inner Washer 11 61372 M22 Din Outer Washer Item Part No Description 61061 L=212mm Large Head Left 61071 L=212mm Large Head Right 61065 L=519mm Large Head Left 61075 L=519mm Large Head Right www.major-equipment.com...
  • Page 87 15 20058 Axle Washer 16 20059 Cotter Pin Ø8 x 40 17 20060 Heavy Duty Axle Nut 18 61140 Return Spring 19 61141 Anchor Spring Pin 20 61150 Return Spring Pin 21 61220 Cam Roller Retainer 22 61235 Cam Roller www.major-equipment.com...
  • Page 89 Major Equipment Intl Ltd Ballyhaunis, Co Mayo Ireland Tel: +353 (0) 9496 30572 United Kingdom Major Equipment Ltd Major Ind. Estate, Heysham, Lancs, LA3 3JJ, UK Tel: +44 (0) 1524 850501 Netherlands & Germany Major Equipment Intl Ltd Postbus 29, NL-7700 AA...

This manual is also suitable for:

1500 slurry vac1700 slurry vac2000 slurry vac1500 lgp1700 lgp1900 lgp ... Show all

Table of Contents
