Summary of Contents for Major POST DRIVER
- Page 1 Operator Manual & Parts List MAJOR POST DRIVER Rev3_200411 v3_2 _200...
- Page 2 Major reserves the right to modify the machinery and the technical data contained within the manual without prior notice. Further to this, Major assumes no liability for any damages which may result from the use of the information contained within this manual.
-
Page 3: Table Of Contents
Driving Safely on Public Roads Safe Storage of the Machine Operating the Machine Inspections before Use Key to Main Parts Pre-Use Assembly Spool Controls Hitching to the Tractor Operating the Machine Finishing and Moving Away Spare Parts Post Driver Overview Post Driver Hydraulic Hoses... - Page 4 EN ISO 13857 - Safety of machinery: Safety distances to prevent hazard zones being reached by upper and lower limbs. I certify on behalf of Major Equipment Int. Ltd., that this machine when properly installed and operated correctly, complies with all the essential Health & Safety requirements of all legislation referred to above.
-
Page 5: Introduction
Product Identifi cation Machine Serial Numbers If you need to contact MAJOR or your MAJOR dealer for information on servicing or spare parts, always provide the product model and serial numbers. We suggest that you record your machine details below:... -
Page 6: Register Your Product And Warranty Online
The operator’s manual also explains any potential safety hazards whenever necessary in special safety messages that are identifi ed with the word, CAUTION, and the safety-alert symbol. The Major Post Driver comes equipped with all safety labels in place. They are intended to help you operate your machine safely. -
Page 7: Operating Safely
• Never put hands or fi ngers between hammer plate or post • Never stand directly in front of Post Driver while operating. Stand at 45° to machine in case post is pushed outwards during hammer action. • The operator should be wearing long sleeve shirt, long legged pants, hearing and eye protection, hard hat, steel- toe capped boots and gloves •... -
Page 8: Safe Storage Of The Machine
Grease every 20 hours of operation and pre/post season • Ensure tractor is of suffi cient weight to be stable with Post Driver • Ensure that the Post Driver is properly attached to the tractors three point linkage • Check that all hydraulic fi ttings are tight •... -
Page 9: Pre-Use Assembly
NOTE: This machine is not fi tted with an hydraulic top link. If fi tting a hydraulic top link ensure it is fi tted with fl ow restrictors as to reduce the speed of the machine tipping forward. Consult your dealer or manufacturer for more information. www.major-equipment.com... -
Page 10: Hitching To The Tractor
1. Hook anchors onto hammer and lift strike plate off driver (weight box) using hydraulic control. 2. Lift the Post Driver off ground with tractor link arms and move away from post such that the hammer can be lowered before moving to the next location. -
Page 11: Spare Parts
Spare Parts Post Driver Overview www.major-equipment.com... - Page 12 Post Driver Parts List Item Part No Description Item Part No Description PD-0001 Main Welded Asm PD 23 M10 M10 NYLOC NUT PD-0017 Sliding Lower Linkage 24 M10x25SZP M10x25 SET BOLT PD-0024 STAND LEGS 25 M12 M12 NYLOC NUT PD-0026...
-
Page 13: Post Driver Hydraulic Hoses
Post Driver Hydraulic Hoses www.major-equipment.com... - Page 14 Post Driver Hydraulic Hoses Parts List Item Part No Description Item Part No Description ML-3-A1 3 bank mono-bloc da/da/sa 6.3 EMM3438 3/4”-3/8 M/M CONNECTOR PD-0082 3/8” Breather Pipe Asm 6.4 EDOW34 3/4” DOWTY WASHER 3.1 CRP3890 3/8” CRIMP (90 Deg) 6.5 CRP3800...
- Page 15 Warranty: This machine is guaranteed for 12 months. No warranty is given where the machine is being used as a hire machine. Warranty is against faulty workmanship or parts, with the exception of components not of MAJOR’S manufacture or design, i.e.
- Page 16 HEAD OFFICE UK OFFICE Netherlands & Germany OFFICE Major Equipment Intl Ltd Major Equipment Ltd Major Equipment Intl Ltd Ballyhaunis, Co Mayo Major Ind. Estate, Heysham, Postbus 29, NL-7700 AA Ireland Lancs, LA3 3JJ, UK Dedemsvaart, Nederland Tel: +353 (0) 9496 30572...
