Door hanging

Door hanging
The tumble dryer comes with the door hung
on the left. However, it is possible to change
the door so that it is hung on the right.
Follow these instructions:
1. Remove the lower front plate and undo the
three screws holding the hinge attachment.
2. Angle the lower edge of the door out to the
left while turning the hinge attachment as
indicated by the arrows.
Hinge attach-
ment
3. Move the hinge pin. To hang the door on
the right, the hinge attachment must then
be turned upside down.
Hinge pin
4. Then move the hinge pin in the panel's
lower edge.
22
5. Next you must move the plastic plugs on
the upper and lower edges of the door. Use
a flat screwdriver.
6. Unscrew the two screws on the sides of
the door by around five millimetres, to allow
the door magnet and cover washer on the
inside of the door to be removed.
7. Then remove the door magnet (1) and
cover washer (2).
1
2
