Emergency Stop Strap
When the lift is correctly installed in the trolley system, the emergency
stop strap needs to be adjusted. The emergency stop strap is cut at a
height where the strap doesn´t interfere with a normal lifting situation but
at the same time is easily reached by all users.
The strap is cut with scissors and singed at the end as to prevent unravel.
Handicare recommends a height of 1800 mm/70 inches above the floor.
Assembly of charger unit
The following is included in the charger station package:
• Holder
• Charger cup
• Charger
• Plug (4 pce)
Charger cable (EU, UK, US/Japan, AUS connectors included
(fixtures between charger station and wall/freestanding rail not included)
Charger station
a) Secure holder to charger station on wall/freestanding rail system. Recommended
height is 1100-1200 mm/ 43 - 47 inch from floor.
b) Mount the charger cable. If necessary mount the cover for the charger.
c) Connect the accompanying hand control to the charger station and the hand
control cable to the lift unit. Check charger function.
