5. Panel Description

Note Fig. 1
1. Display
2. Function keys (meaning see below.)
3. Rotary switch
4. Input terminal
10 A-jack
Joint connector (COM)
Multi-function jack
measurement, Resistance measurement, Capacity measurement, Current
masurement max. 600 mA)
5. NCV-Sensor
6. Point Illumination (Torch light)
The function keys and their meanings
SEL
2.1
V.F.C
2.2 RANGE
Hz
2.3
2.4
HOLD
(Battery test, Single-Pole voltage test, Voltage
Select button
Voltage measurement at variable frequency
Automatic range selection / manual Range
selection
Frequency measurement
Point Illumination (Torch light)
Backlight
Data hold
