- Page 1 ® posirot PRAS2EX, PRAS3EX, PRAS5EX Magnetic angle sensors, dust-ex proof Installation and operation manual Please read carefully before installation and operation!
- Page 2 © ASM Automation Sensorik Messtechnik GmbH, 2019 All rights reserved. Am Bleichbach 18 - 24 85452 Moosinning Germany...
-
Page 3: Table Of Contents
3.4 Characteristics for magnetic angle sensors ................. 13 4 Maintenance and disposal ..................18 4.1 Maintenance and service ......................18 4.2 Deinstallation (dust-ex proof standard-compliant) ............... 18 4.3 Disposal ............................18 5 Output specification ....................19 6 EU Declaration of Conformity ..................21 Version 4.2.0 www.asm-sensor.com... -
Page 4: Safety Instructions
The sensor must be operated only within values specified in the datasheet. • The danger of personal injury and danger of property damage due to a malfunction of the sensor in machines or systems must be excluded by additional safety measures. Version 4.2.0 www.asm-sensor.com... -
Page 5: Dust-Ex Proof Marking
Max. revolutions of 1000 1/min resp. max. 1000rpm are admissible. A higher number of 1000rpm revolutions can cause the surface temperature to exceed 80°C. Pos : 12 /########### Sei tenumbruch ################################### @ 0\mod_1353584168894_0.doc x @ 336 @ @ 1 Version 4.2.0 www.asm-sensor.com... -
Page 6: Intended Use
• corrosive and aggressive media e.g. atmospheres containing chloride. Pos : 15 /########### Sei tenumbruch ################################### @ 0\mod_1353584168894_0.doc x @ 336 @ @ 1 Version 4.2.0 www.asm-sensor.com... -
Page 7: Transport And Storage
Mount sensor on a flat metallic surface. • Provide protection devices to avoid damage or blocking of sensor and magnet by foreign objects falling into the working area. Mechanical information for PRAS2EX and PRAS5EX-K • Contact between sensor and magnet is not allowed. Version 4.2.0 www.asm-sensor.com... - Page 8 0 ... 5 PRMAG2Z-VA 0 ... 9 PRMAG5Z-VA 0 ... 8 PRAS5EX PRMAG2-VA 0 ... 4.5 PRMAG2Z-VA 0 ... 5.5 PRMAG5Z-VA 0 ... 7.5 Pos : 21 /########### Sei tenumbruch ################################### @ 0\mod_1353584168894_0.doc x @ 336 @ @ 1 Version 4.2.0 www.asm-sensor.com...
-
Page 9: Electrical Installation
Follow the signal wiring table! Supply voltage See specification in the data sheet of the sensor. The maximum operating voltage must not be exceeded. Pos : 23 /########### Sei tenumbruch ####### ############################ @ 0\mod_1353584168894_0.doc x @ 336 @ @ 1 Version 4.2.0 www.asm-sensor.com... - Page 10 Potential equalization The local potential equalization has to be realized with a wire cross section of 4 mm² minimum. PRAS2EX PRAS3EX PRAS5EX-K PRAS5EX-V Pos : 25 /########### Sei tenumbruch ################################### @ 0\mod_1353584168894_0.doc x @ 336 @ @ 1 Version 4.2.0 www.asm-sensor.com...
- Page 11 A separate cord grip for cable strain relief is recommended Observe cable routing in case of splashing water, water condensation and humidity Pos : 27 /########### Sei tenumbruch ################################### @ 0\mod_1353584168894_0.doc x @ 336 @ @ 1 Version 4.2.0 www.asm-sensor.com...
-
Page 12: Operating Temperature
Pos : 29 /Bedienungs anl eitungen/Posirot/EX/Arbeitstemper atur _Ü bersic ht_PR AS_EX @ 7\mod_1535968307046_78.doc x @ 58505 @ 2 @ 1 3.3 Operating temperature -20 … +40°C ® posirot PRAS2EX -20 … +40°C ® posirot PRAS3EX -20 … +40°C ® posirot PRAS5EX Pos : 30 /########### Sei tenumbruch ################################### @ 0\mod_1353584168894_0.doc x @ 336 @ @ 1 Version 4.2.0 www.asm-sensor.com... -
Page 13: Characteristics For Magnetic Angle Sensors
For ease of mounting there are reference markings at housing, position magnet and near the shaft. If both markings match output will be on the 50% of full scale. Output signal (CW increasing*) Output signal (CCW increasing*) Example angular range 90° Example angular range 360° A – Marking B – Measurement range [°] Version 4.2.0 www.asm-sensor.com... - Page 14 50% value of output signal 0.5 ... 10 V 5.25 V 0.5 ... 4.5 V 2.5 V 4 ... 20 mA 12 mA Pos : 33 /########### Sei tenumbruch ################################### @ 0\mod_1353584168894_0.doc x @ 336 @ @ 1 Version 4.2.0 www.asm-sensor.com...
- Page 15 Connector M12 axial Connector M12 radial A – Marking A – Marking Magnets: Magnets: PRMAG2-VA PRMAG2-VA PRMAG2Z-VA PRMAG2Z-VA PRMAG5Z VA PRMAG5Z VA Pos : 35 /########### Sei tenumbruch ################################### @ 0\mod_1353584168894_0.doc x @ 336 @ @ 1 Version 4.2.0 www.asm-sensor.com...
- Page 16 Pos : 37 /Bedienungs anl eitungen/Posirot/EX/R eferenzpositi on_EX/Refpos _PR AS3_EX_M 12_ax_rad_hohl welle @ 5\mod_1499413423263_78.doc x @ 44485 @ @ 1 Reference position PRAS3EX with hollow shaft Connector M12 axial Connector M12 radial A – Marking B – Marking (back side) Pos : 38 /########### Sei tenumbruch ################################### @ 0\mod_1353584168894_0.doc x @ 336 @ @ 1 Version 4.2.0 www.asm-sensor.com...
- Page 17 Pos : 40 /Bedienungs anl eitungen/Posirot/EX/R eferenzpositi on_EX/Refpos _PR AS5_EX_K_M12_ax_rad @ 5\mod_1499417445244_78.doc x @ 44530 @ @ 1 Reference position PRAS5EX-K Connector M12 axial Connector M12 radial A – Marking B – Marking (front side) Pos : 41 /########### Sei tenumbruch ################################### @ 0\mod_1353584168894_0.doc x @ 336 @ @ 1 Version 4.2.0 www.asm-sensor.com...
-
Page 18: Maintenance And Disposal
Screw tight sealing: Remove dust remove sensor mounting parts from service and remove sensor with recommended send it to ASM for from service and torque, if repair send it to ASM for applicable use bolt repair adhesive Pos : 44 /Bedienungs anl eitungen/Posi wire/WS_EX_D emontage @ 6\mod_1519816144724_78.doc x @ 52912 @ 2 @ 1 4.2 Deinstallation (dust-ex proof standard-compliant) -
Page 19: Output Specification
±100 x 10 / °C f.s. (typical for <90°) Protection Reverse polarity, short circuit -40 … +85 °C Operating temperature DIN EN 61326-1:2013 Pos : 52 /########### Sei tenumbruch ################################### @ 0\mod_1353584168894_0.doc x @ 336 @ @ 1 Version 4.2.0 www.asm-sensor.com... - Page 20 Signal Do not connect! Do not connect! View to the sensor connector 3-wire current 4...20 mA interface: GND has to be connected! Pos : 55 /########### Sei tenumbruch ################################### @ 0\mod_1353584168894_0.doc x @ 336 @ @ 1 Version 4.2.0 www.asm-sensor.com...
-
Page 21: Eu Declaration Of Conformity
® posirot Magnetic angle sensors, dust-ex proof Pos : 56 /Bedienungs anl eitungen/Posirot/EX/D OC_PRAS-EX @ 8\mod_1564998694674_78.doc x @ 66631 @ 1 @ 1 6 EU Declaration of Conformity ASM Automation Sensorik Messtechnik GmbH Am Bleichbach 18-24 85452 Moosinning Germany declare under our sole responsibility that the product ®... - Page 22 ® posirot Magnetic angle sensors, dust-ex proof Version 4.2.0 www.asm-sensor.com...
- Page 23 ® posirot Magnetic angle sensors, dust-ex proof Version 4.2.0 www.asm-sensor.com...
- Page 24 Tel. +44 845 1222-123 Tel. +49 8123 986-0 Fax +1 630 832-3204 Fax +44 845 1222-124 Fax +49 8123 986-500 info@asmsensors.com info@asm-sensor.com info@asm-sensor.com © ASM Automation Sensorik Messtechnik GmbH, 2019 All rights reserved. Subject to changes without notice. See protection note DIN34.
