Summary of Contents for Hoggi SHARKY

  • Page 1 Partnerschaft für mobile Kinder SHARKY User manual...
  • Page 2: Table Of Contents

    User manual for SHARKY Model identification and basic configuration 1.1 Model identification ___________________________________________________________________3 1.2 Basic configuration ___________________________________________________________________3 Common information 2.1 Preface ____________________________________________________________________________4 2.2 Application __________________________________________________________________________4 2.3 Declaration of conformity ______________________________________________________________4 2.4 Terms of warranty ____________________________________________________________________4 2.5 Service and repairs ___________________________________________________________________4 Safety instructions 3.1 Meaning of symbols __________________________________________________________________5 3.2 Common safety instructions ____________________________________________________________5 Delivery and preparing for use 4.1 Delivery and preparing for use _______________________________________________________ 9-11 Accessories 5.1...
  • Page 3: Model Identification

    Model identification The mobility base label is mounted on the inside of the left side strutt. Colour code Material number Size / Variant Serial number CE label Classification / Product name Maximum load / load capacity Manufacturer Place of manufacture Year of manufacture The SHARKY basic configuration contains: Base: - compactly foldable - height adjustable, traversable toilet height 43-52 cm - tilt (seat angle) -10° up to 45° Seat unit: - removable from the base (quick release) - PU pads on the back, seat and hip supports - closable hygiene opening - back angle adjustable, foldable and removable - seat width 24, 27, 30 cm - seat depth 27-36 cm - back height 42 cm - back angle 72-120° - maximum load: 60 kg - size 1 and size 2 in progress...
  • Page 4: Common Information

    2.2 Application The SHARKY toilet wheelchair for children is used for indoor and daily use in wet areas. It is used by children and young people with a deficit in the area of s itting down and standing up for individual use in daily care / hygiene or in toilet training. Various bases guarantee numerous possible uses such as use as a toilet chair, toilet seat, bathtub insert or mobile positioning options for daily personal hygiene. Assistance may be required due to: - Paralysis (paraplegia / tetraplegia or paresis) - Loss of limbs (dysmelia/lower limb amputation) - Infantile/spastic cerebral palsy - Spina Bifida - Muscle and nerve disorders - Imperfect osteogenesis - Poliomyelitis SHARKY is able to be used for further service. For further service the product has to be cleaned and sanitised efficiently. Afterwards the product has to be checked concerning condition, wearout and damage by an authorised technician. All damaged and inapropptiate parts need to be changed. Please see also the service manual for detailled information. 2.3 Declaration of Conformity The HOGGI GmbH as manufacturer with sole responsibility declares that the toilet wheelchair SHARKY conforms to the requirements of the 93/42/EEC Guidelines (considering also the modifications of MDD 2007/47/EG). Applicable harmonized standards have been applied. 2.4 Terms of warranty Warranty applies only when the product is used according to the specified conditions and for the intended purposes, following all manufacturer’s recommendations. The manufacturer is not responsible f or damages caused by components and spare parts not approved by the manufacturer. See also § 8 of terms and conditions on: www.hoggi.de 2.5 Service and repairs Service and repairs at SHARKY may only be carried out by specialized dealers. If you...
  • Page 5: Safety Instructions

    Safety instructions 3.1 Meaning of symbols Caution! Warning of possible danger of accident and injury. Warning of possible technical damage. Information! About use of product. Information! For service-personnel.. Attention! Read manual before use! 3.2 Common safety instructions Read manual completely before use! Familiarize yourself with handling and functions of the wheelchair before use and practice the handling. You are responsible for the safety of your child. The safety of your child could be affected if you do not follow the instructions of this manual. Nevertheless not all possible circumstances and unpredictable situations can be covered by this manual. Reason, care and circumspection are not features of the product, they are required of persons, who use the wheelchair or attend it. The person, who is using the wheelchair and its accessories should understand all instructions. It must explained to every other person using the wheelchair and its accessories.If instructions are not clear and further explanations become necessary, or if you have further questions please contact your HOGGI dealer. Practise with the new wheelchair on even, straightforward terrain first, together with the child. Together with the child, learn how the wheelchair reacts when the centre of gravity shifts; for example on slopes or inclines or when clearing obstacles such as steps and curbs. This should be done only with assistance from another person. Using an anti-tip is strongly recommended for inexperienced wheelchair users. Strap in your child at all times, when it is in the toilet wheelchair. HOGGI points out, that any use beside the typical use can be dangerous. The toilet wheelchair is not suitable for jogging, running, skating or similar activities. Swivelling front wheels tend to wobble at higher speed, which can cause a sudden stop and tip over of the wheelchair. Use the toilet wheelchair only at regular walking speed. Under no circumstances leave the handle bar while pushing and never push the toilet wheelchair away.
  • Page 6 The product should only be used on solid level ground. Use your toilet wheelchair as intended by the manufacturer. For instance, do not drive into obstacles (including steps, curbs) without braking. Do not „jump” the chair down from higher surfaces.fe). Pay increased attention to driving up and down gradients. Special attention should be paid to the child falling out, the toilet wheelchair tipping over or rolling away. The toilet wheelchair should be lifted only by touching tighten parts of the frame. The toilet wheelchair should only be parked on horizontal, level surfaces. If you have to park on a slope, face the wheelchair uphill with the brakes engaged and ensure that the seat is in the upright position. There is a risk that the wheelchair might tip over backwards if the seat is the reclined position. Before leaving the wheelchair and before getting into and out of it, always lock the wheel locks. Make sure that your child does not lean too far out of the toilet wheelchair when grabbing objects (which are in front of, to the side or behind the toilet wheelchair), as the shift in the center of gravity causes a tilting or there is a risk of rollover. Please keep packaging material away from children. Plastic packaging presents the danger of suffocation. Never leave your child unattended in the wheelchair even when they are strapped in and the brakes engaged.. Both folding locks must be engaged before use. Static stability is >10,5° inclination. Attaching heavy bags or other weight to the push handles can adversely affect stability. When adjusting the back incline, the seat and knee angle with the child in the seat unit, pay particular attention to the danger of clamping for the child by stretching arms or legs out into moving parts.
  • Page 7 Don´t use the footrest to get into and out of the wheelchair. The toilet wheelchair is only approved for use by one child. Disposal of waste: The packaging material as far as metal, aluminium and plastic parts can be recycled. The recycling must be operated according to the national and legal terms. Load the ventral upper body support with a maximum of 5 kg. All upholstery parts are flame retardant and meet the requirements of EN 1021 Part 1 (cigarette test) and 2 (match test). However, this does not protect the user in the seat unit from burns caused by careless handling of embers or open fire. When stored in the folded state, no load may act on the frame. Maximum load SHARKY: 60 kg. Accessories and add-ons reduce the maximum load proportionately. Protruding strap ends of the accessory parts could jam in the seat angle adjustment mechanism and prevent the locking bolts from engaging. The seat could then adjust the seat angle during use. For this reason, shorten the belt ends of accessories so that they can no longer get into the seat angle adjustment mechanism. After putting the seat unit on, check with a jerk on the seat whether the locking bolts are engaged. Please read to visually handicapped people the manual and info material - or use electric aids. Please download or read all SHARKY documents on our webside www.hoggi.de. In addition, product videos and product photo galleries are available online!
  • Page 8 Whenever you change any settings on the wheelchair, make sure that you firmly tighten any screws that have been loosened. Check the condition of the product if the packaging is damaged. Be careful in case of extreme temperatures. The wheelchair can heat up significantly when in the sun or in the sauna. In extreme cold, there is a risk of hypothermia. Slowing down from high speeds or when descending longer slopes tends to heat up the hands and fingers, especially if using aluminium push rings. When using the wheelchair outdoors, leather gloves should be worn. Gloves provide the wheelchair user with a better grip and protect his or her fingers from dirt and hot metal.
  • Page 9: Delivery And Preparing For Use

    4 Delivery and preparing for use SHARKY will be supplied completely mounted. Delivery in board: ca. 880 mm (L) x 700 mm (W) x 400 - 450 (H) Please check the condition of the product if the packaging shows damages. Please remove the transport packaging carefully. The original package contains the following parts: • folded base (see illustration) • folded seat unit and back • Additional accessories as ordered (These have to be mounted on the wheelchair by an authorized dealer) • Instructions and list of tools required To unfold please proceed as follows: • Move the snapper on the right side of the base frame. • Turn the snapper 90° to lock it. • The illustration shows the locked snapper on the right.
  • Page 10 • Move the snapper on the left side of the base frame. • Secure the base frame with your left hand and at the same time move the base frame up on the back bar with your right hand. • When both sliders have moved a few cm forwards, the lock on the right snapper can be released. • The folding process can now be continued. • Make sure that both snapper audibly snap into place. To insert the seat unit, please proceed as follows: • Pull the release rope (as shown) and move the backrest upwards. • Engage both bolts audibly in the desired back angle position. • Place the seat in the frame from above as shown. • Make sure that you first place the rear guide slots (A) of the seat unit on the two rear locking shafts (B) of the base.
  • Page 11: Accessories

    A = Guide slots of the seat unit B = Locking shafts of the base • Place the seat unit on the front locking shafts and finally let it snap into place. 5 Accessories 5.1 Push handle unit • Remove the back panel as shown. • Position the push handle on the back frame as shown and insert the four M6x16 cylinder head screws provided. • Secure the screw connection with the supplied washers and the self- locking nuts.
  • Page 12: Footrest System

    5.2 Attaching the footrest system To attach (and also to remove) the footrest the smallest knee angle may not be preset (see marking X). In addition, we recommend to position the seat in a tilt of 45 ° tilt as shown. • Guide the footrest system with both openings into both slots on the bottom of the seat at the same time. • Make sure that the openings are hooked behind the locking shafts of the seat frame. • Swivel the footrest forwards until the snappers audibly click into place.
  • Page 13 Adjusting the knee angle The knee angle can be adjusted between 78 ° and 138 ° using a locking bolt under the front edge of the seat plate. • Pull the release rope with one hand of the locking bolt and move the knee angle lever with the other hand to the desired angular position. •Engage both bolts audibly in the desired back angle position. Removing the footrest system To attach (and also to remove) the footrest the smallest knee angle may not be preset (see marking X). In addition, we recommend to position the seat in a tilt of 45 ° tilt as shown.. • Use your index fingers to pull both heads of the snappers forward. • Make sure to secure the footrest system to the bars.
  • Page 14: Headrest

    • Move the footrest system to the rear so that both openings release from the mounting slots. • Take off the footrest system. 5.3 Headrest • Open the clamping lever and insert the headrest into the headrest holder from above as shown. • Select the desired headrest height and lock the clamping lever. •Open the clamping lever as shown and select the desired angular position of the headrest. • Close the clamping lever. 5.4 Trunk supports The illustration shows the clamp in the back frame for mounting the trunk support.
  • Page 15 • Screw the trunk support holder to the clamp in the back frame as shown. • To adjust the height of the trunk support, loosen the screw connection as shown and move the trunk support holder to the desired height position. • Firmly tighten the screw connection again. • Loosen the screw connection as shown to set the desired width. • Firmly tighten the screw connection again. •Loosen the screw connection as shown to make the desired to adjust the angle. • Firmly tighten the screw connection again. Swiveling the trunk support away: • Pull the pull latch up to release the locking. Move the trunk supports backwards...
  • Page 16: Chest-Shoulder Harness

    5.5 Chest-shoulder harness Illustration shows the chest-shoulder harness. • Guide the strap through the eyelet in the back area from the front as shown. • Guide the strap through the bar buckle as shown. • Guide the strap behind the cross brace of the back frame as shown. • Guide the strap back through the bar buckle as shown.
  • Page 17: Lap Belt

    • Guide the strap back through the bar buckle and back through the eyelet on the back as shown • Then do the same on the other side. • To attach the lower belts, please proceed as described under 5.6 lap belt. Opening the chest-shoulder harness: • Open the fasteners on the shoulders and / or in the pelvic area. 5.6 Lap belt • Guide the end of the strap through the bar buckle as shown. • Guide the end of the strap through the eyelet on the base of the back as shown. • Guide the end of the strap back through the bar buckle as shown.
  • Page 18: Pelvic Retraction Belt

    • Guide the end of the strap back through the bar buckle as shown. • Proceed accordingly on the other side. By moving the buckle the strap length can be set. • The lap belt opens by pressing the black release button. The lap belt can be retightened at the belt buckle by pulling the belt end (fine adjustment). 5.7 Pelvic retraction belt Illustration shows the pelvic retraction belt. • To assemble, screw the pelvic retraction belt as shown into the thread of the back base. • Then do the same on the other side.
  • Page 19: Armrests With Pu-Pads

    • To adjust the depth of the belt, loosen the screw connection as shown and select the desired position. 5.8 Armrests Illustration shows the height-adjustable and removable armrest. • Press the release button as shown and select the desired armrest height. • Make sure that it is securely locked.
  • Page 20: Ventral Upper Body Support

    The armrest can also be removed. 5.9 Ventral upper body support • Illustration shows the ventral upper body support. • Place the ventral upper body support with the frame construction in the holders below the armrest pads. • Make sure that it is securely locked. 5.10 Abduction block Insert: • Position the abduction block as shown. Move it upwards to lock it.
  • Page 21: Calf Support

    Armrests: • Activate the locking hook and pull the abduction block out towards the front. 5.11 Calf strap Illustration shows the calf strap. • Open the thumbscrews on both sides of the footrest bearings. • Pull the footrest off downwards. • Insert the calf strap as shown and position it at the desired height. • Reinstall the footrest at the desired height and close the thumbscrew on both sides of the footboard bearings. 5.12 Ankle hugger Illustration shows an ankle hugger. To assemble the ankle hugger, please proceed as described under 5.6 lap belt.
  • Page 22: Toilet Bucket

    5.13 Toilet bucket Insert: • Place the toilet bucket in the guide rails from the rear. • Make sure that it is securely locked. Removal: • Pull the toilet bucket out of the guide rails from the rear. Illustration shows the guide rails. Bottom view. 5.14 Splash guard Illustration shows splash guard. • Position the splash guard as shown before use. • Remove the splash guard after use. 5.15 PU seat infill pad for hygiene opening The hygiene opening can be easily removed for hygiene and cleaning.
  • Page 23: Bath Subframe

    • If desired, pull out the infill pad as shown. Illustration shows the hygien opening without the infill pad. 5.16 Bath subframe Illustration shows bath subframe. 5.17 Toilet adapter Illustration shows toilet adapter.
  • Page 24: Pu-Hip Support Pads

    5.18 PU-hip support pads Illustration showas lateral PU-pads. 6 Transport and storage 6.1 Transport and storage SHARKY can be transported or stored with or without a seat, with or without footrest hanger. The smallest packing size can be achieved with removed seat and footrest hanger.
  • Page 25: Maintenance/ Service And Repair

    X Testing the screw connections X Air pressure (indicated on the side wall of the tyre) X Visual inspection of wearing parts such as wheels and bearings X Contamination on bearings X Quick release (rear wheels) X Check firmness of the footrest Function test of the tilt mechanism Testing adjustment of the back angle Should any defects become obvious, please contact your authorized HOGGI dealer to eliminate them. We also recommend that you have your SHARKY serviced by your authorized dealer every twelve months. Instructions for cleaning and maintenance - Clean all frame components and plastic parts using mild detergents only. (e.g. Sagrotan). - Padding parts can be washed at 40 °C. If washed in a washing machine, put them in a linen bag or a pillow case. - In most cases, wiping with a damp cloth is sufficient. - Do not use your SHARKY in salt water. - Keep sand or other particles from damaging the wheel bearings. - If your SHARKY gets wet, towel-dry it as soon as possible. - Hair and dirt particles generally accumulate between the caster wheel and fork. This can restrict the caster wheels from rotating smoothly. Remove the caster and thoroughly clean the fork and caster using a mild detergent. - The rear wheels feature a quick-release system. To keep this system operational, ensure that no dirt adheres to the quick-release axle or axle housing. The quick-release axle should also be lightly lubricated regularly with resin-free sewing machine oil. - Screw connections should be checked frequently, in particular when beginning to use the wheelchair and after any adjustment. If a screw connection becomes loose repeatedly, consult your dealer. 7.2 SHARKY life cycle: The expect life cycle of SHARKY amount to 5 years, dependent on use intensity and maintenance. We recom- mend a yearly check by your authorized dealer. In case of any disorders or defects it‘s intended to hand over the wheelchair the health care supply store or your authorized dealer.
  • Page 26: All Specifications And Notes On Attachments And Accessories

    24/27/30 cm 29/32/35 cm Seat width 27 - 36 cm 27 - 40 cm Seat depth Backrest height 42 cm 50 cm Maximum, traversable toilet height 52 cm 52 cm Seat angle -10° bis +45° -10° bis +45° Back angle 72° - 120° 72° - 120° Footrest angle 80° - 100° 80° - 100° Armrest heigth 14,5 - 20,5 cm 14,5 - 20,5 cm 75 mm, 100 mm 75 mm, 100 mm Wheel diameter Load capacity** 60 kg 60 kg Weight (seat) 9 kg 10 kg ATTENTION! *Accessories and mounting parts reduce the remaining vehicle load capacity. ATTENTION! **Weight refer to a SHARKY with basic configuration.
  • Page 28 HOGGI GmbH Eulerstraße 27 • 56235 Ransbach-Baumbach • Deutschland Telefon: (+49) 2623 / 92 499-0 • Telefax: (+49) 2623 / 92 499-99 E-mail: info@hoggi.de • www.hoggi.de...
