5.3
TQMLX2160A connectors
The TQMLX2160A is connected to the carrier board with 560 pins on three connectors.
The following table shows details of the connector assembled on the TQMLX2160A.
Table 17:
Connector assembled on TQMLX2160A
Manufacturer
EPT
The following table shows suitable carrier board mating connectors.
Table 18:
Carrier board mating connectors
Manufacturer
Part number
401-51401-51
401-51103-51
EPT
401-55401-51
401-55103-51
To avoid damaging the connectors of the TQMLX2160A during extraction, the use of the extraction tool MOZILX2160A is
strongly recommended.
Note: 16 Gbit+ specification
It is strongly recommended to use the 220-pin module connectors with 16 Gbit+ specification
for carrier boards. For the 120-pin module connectors the 10Gbit+ specification is sufficient.
Carrier board mating connectors with 5 mm height can also be used.
Note: Component placement on carrier board
2.5 mm should be kept free on the carrier board, on both long sides of the TQMLX2160A
for the extraction tool MOZILX2160A.
5.4
Protection against external effects
As an embedded module, the TQMLX2160A is not protected against dust, external impact and contact (IP00).
Adequate protection has to be guaranteed by the surrounding system.
Preliminary User's Manual l TQMLX2160A UM 0002 l © 2020, TQ-Systems GmbH
Part number
402-51401-51
402-51101-51
•
120 pin, 0.5 mm pitch
•
Data transfer rate 10+ Gbit/s
•
220 pin, 0.5 mm pitch
•
Data transfer rate 16+ Gbit/s
•
120 pin, 0.5 mm pitch
•
Data transfer rate 10+ Gbit/s
•
220 pin, 0.5 mm pitch
•
Data transfer rate 16+ Gbit/s
Type
Type
120-pin, 0.5 mm pitch
220-pin, 0.5 mm pitch
Remark
5 mm board-to-board distance
8 mm board-to-board distance
Page 26
