dji Remote Start/Stop User Manual page 10

Protocol from the Serial Protocol drop-
down menu.
Connect the Control Cable to the CTRL
Port of the camera.
6. Sony Alpha 7 Series Camera
Enable the Remote Control function on the
camera and point the infrared light from
the Control Cable to the camera's receiver.
Operation
1. When using with the Ronin series
gimbal on the ground, toggle the
FUNCTION switch quickly from Position
2 to Position 1 and back to Position 2
to take photos. Toggle the FUNCTION
switch quickly from Position 2 to
Position 3 and back to Position 2 to
start/stop video recording.
© 2016 DJI All Rights Reserved.
10
1
2
3
Take Photos Start/Stop
Video Recording
