Gill 330155 Assembly Instructions Manual

www.gillathletics.com
800-637-3090
STRAIGHT POLE TENSIONED BATTING TUNNEL
SOFTBALL: 55' x 14' Nets
No. 330155
No. 330255
2'-0"
No. 330355
2'-0"
2'-0"
Copyright  2016 by Gill Athletics.
All rights reserved.

POLE LAYOUT

63'-0"
4'-0"
63'-0"
4'-0"
63'-0"
4'-0"
BASEBALL/SOFTBALL BATTING TUNNELS
BASEBALL: 75' x 14' Nets
No. 330175
14'-0"
No. 330275
15'-0"
2'-0"
15'-0"
No. 330375
15'-0"
2'-0"
16'-0"
2'-0"
15'-0"
ASSEMBLY INSTRUCTIONS
83'-0"
4'-0"
83'-0"
4'-0"
83'-0"
4'-0"
14'-0"
15'-0"
15'-0"
15'-0"
16'-0"
15'-0"
6/18/2020
INST330175
Page 1 of 8
