SEPLOS PUSUNG 2 User Manual page 11

SEPLOS PUSUNG 2 ND GENERATION 51.2V 100AH LIFEPO4 BATTERY PACK USER MANUAL
CAPACITY
SOC light: 4 green LED lights to show the capacity status of battery pack. Each LED represents 25%
the capacity.
Status
Capacity
●L4
indicator
0-25% OFF
25%-50% OFF
50%-75% OFF
>75% Blink
Operating
indicator
P+/P-
Power terminals: two pairs of power terminals with the same function, one connect to equipment,
and the other one parallel to other battery pack for capacity expanding. For a single pack, both
terminals can achieve charging and discharging functions.
Power cable uses 6.0mm power plug with lock button. And can be full rotation.
Charge
●L3 ●L2
OFF OFF
OFF Blink
Blink Solid Green Solid Green
Solid Green Solid Green Solid Green Solid Green Solid Green Solid Green Solid Green
Solid Green
●L1 ●L4
Blink OFF
Solid Green OFF
OFF
