1105A - 1355A - 1505A
Mixer Operation and Parts Manual
ROTO-MIX
P.O. BOX 1724
2205 E. Wyatt Earp Blvd.
Dodge City, Kansas 67801
(620) 225-1142
441926 01/2020
SERIAL NUMBER_________________
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 1105A and is the answer not in the manual?

Questions and answers

Related Manuals for Roto-Mix 1105A

Summary of Contents for Roto-Mix 1105A

  • Page 1 1105A - 1355A - 1505A Mixer Operation and Parts Manual ROTO-MIX P.O. BOX 1724 2205 E. Wyatt Earp Blvd. Dodge City, Kansas 67801 (620) 225-1142 441926 01/2020 SERIAL NUMBER_________________...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS PAGE NO. WARRANTY ......................5 SCALES WARRANTY & SERVICE POLICY ...............6 OPERATOR QUALIFICATIONS ................7 SAFETY ........................ 8-18 OPERATION ....................... 19-20 TRANSMISSION INFORMATION ................21 LUBRICATION..................... 22-24 TROUBLE SHOOTING ....................25 DIMENSIONS...................... 26-31 FEATURES & SPECIFICATIONS ................32 REPAIR PARTS CONTENTS PAGE ................33 REPAIR PARTS ....................
  • Page 4 INTRODUCTION Congratulations on the purchase of your new Vertical Mixer from ROTO-MIX. With proper operation and preventative maintenance it will last for years. This SAFETY ALERT SYMBOL indicates important safety messages in the manual. When you see this symbol, be alert to the possibility of PERSONAL INJURY and carefully read the message that follows.

  • Page 5: Warranty

    ROTO-MIX and that it be returned to ROTO-MIX within 10 days of purchase and be re- corded in ROTO-MIX’s owner file for this warranty to be valid. In the event an owner’s card is not on file at the ROTO-MIX office, the warranty period will extend only from date equipment was picked up or shipped from the ROTO-MIX plant.

  • Page 6: Scales Warranty & Service Policy

    - ROTO-MIX is not responsible and will not be liable for damage caused to persons or property, commercial loss, loss of time or production, loss of use by reason of the installation or use of ROTO-MIX products or their mechanical failure.

  • Page 7: Operator Qualifications

    OPERATOR QUALIFICATIONS Operation of this mixer/feeder shall be limited to competent and experienced persons. In addition, anyone who will operate or work around a mixer/feeder must use good common sense. In order to be qualified, he or she must also know and meet all other qualifications, such as: 1.

  • Page 8: Safety

    It may also be used to alert against unsafe practices. If you have questions not answered in this manual or require additional copies or the manual is damaged, please contact your dealer or ROTO-MIX, 2205 E. Wyatt Earp, Dodge City, Kansas, 67801. (Telephone) 620-225-1142 (Fax) 620-225-6370...
  • Page 9 SAFETY FIRST The careful operator is the best operator. Most accidents are caused REMEMBER: by human error. Certain precautions must be observed to prevent the possibility of injury or death. DO NOT ALLOW PERSONNEL OTHER THAN THE QUALIFIED OPERATOR NEAR THE MACHINE.
  • Page 10 SAFETY READ BEFORE YOU FEED EQUIPMENT SAFETY GUIDELINES Safety of the operator is one of the main concerns in designing and developing a new piece of equipment. Designers and manufactures build in as many safety features as possible. However, every year many accidents occur which could have been avoided by a few seconds of thought and a more careful approach to handling equipment.
  • Page 11 SAFETY READ BEFORE YOU FEED KEEP ALL SHIELDS IN PLACE Do not operate mixer/feeder without safety shields in place. Rotating parts can crush or dismember causing personal injury or death. Disconnect PTO driveline before removing shields for adjustment or service. OPERATE MIXER/FEEDER SAFELY Rotating parts can entangle or strike people, resulting in personal injury or death.
  • Page 12 SAFETY READ BEFORE YOU FEED STAY CLEAR OF ROTATING DRIVELINES Entanglement in rotating driveline can cause serious injury or death. Keep tractor master shield and driveline shields in place at all times. Make sure rotating shields turn freely. Wear close fitting clothing. Stop the engine and be sure PTO driveline is stopped before making adjustments, connections, or cleaning out PTO driven equipment .
  • Page 13 Replace safety decals and signs that are missing or have become illegible. Replaced parts that displayed a safety sign should also display the current sign. Safety decals or signs are available from your dealer or the ROTO-MIX manufacturing plant. How to Install Safety Decals: Be sure that the installation area is clean and dry.
  • Page 14 Your best assurance against accidents is a careful and responsible operator. If there is any portion of this manual or function you do not understand, contact your dealer or the ROTO-MIX plant. BEFORE OPERATION: Carefully study and understand this manual.

  • Page 15: Operation

    SAFETY READ BEFORE YOU FEED DURING OPERATION: Beware of bystanders, particularly children! Always look around to make sure that it is safe to start the engine of the towing vehicle or move the unit. This is particularly important with higher noise levels and quiet cabs, as you may not hear people shouting. NO PASSENGERS ALLOWED - Do not carry passengers anywhere on, or in, the tractor or equipment, except as required for operation.
  • Page 16 SAFETY READ BEFORE YOU FEED DURING OPERATION (CONT.) Never leave running mixer/feeder unattended. As a precaution, always recheck the hardware on mixer/feeder following every 100 hours of operation. Correct all problems. Follow the maintenance safety procedures. FOLLOWING OPERATION: Following operation, or when unhitching, stop the tractor or towing vehicle, set the brakes, disengage the PTO and all power drives, shut off the engine and remove the ignition keys.
  • Page 17 SAFETY READ BEFORE YOU FEED HIGHWAY AND TRANSPORT OPERATIONS (CONT.): Comply with state and local laws governing highway safety and movement of farm machinery on public roads. Use approved accessory lighting, flags and necessary warning devices to protect operators of other vehicles on the highway during daylight and nighttime transport.
  • Page 18 If equipment has been altered in any way from original design, ROTO-MIX does not accept any liability for injury or warranty. A fire extinguisher and first aid kit should be kept readily accessible while performing maintenance on this mixer/feeder.
  • Page 19 SAFETY READ BEFORE YOU FEED PREPARING TRACTOR FOR TRAILER MIXER POSITIONING DRAWBAR IMPORTANT: Drive components can be damaged from excessive speed. Do not operate tractor at speeds in excess of recommended PT0 rpm . This feed mixer is equipped with a 1000 RPM driveline. Match tractor PTO with the feed mixer driveline.
  • Page 20 LOADING INSTRUCTIONS & PRECAUTIONS A. Visually inspect mixer before each load. B. Do not overload the mixer. Mixer capacity is determined by weight. See specification page for maximum weight. An overloaded mixer will not mix correctly, and will pull harder, which could damage your tractor. C.
  • Page 21 1105A-1305A-1505A TRANSMISSION SERVICE & OPERATION ALLISON 643 & 644 AUTOMATIC TRANSMISSION: Oil and internal filter should be changed every 1000 hours or 12 months of operation, whichever comes first. External spin on filter should be changed every 500 hours. Fill transmission with approximately 7 gal. of Transmission Fluid.
  • Page 22 LUBRICATION CHART DISENGAGE PTO & SHUT OFF POWER BEFORE LUBRICATING THE MACHINE. LOOSE OR FLOPPY CLOTHING SHOULD NOT BE WORN BY THE OPERATOR. PTO SHAFTS & U-JOINTS: Grease every 10 to 20 hours. AUGER GEARBOXS: After the first 100 hours of operation, drain initial oil, preferably when box is warm.
  • Page 23 1105A - 1355A OIL CHANGE DIAGRAM BREATHER CAP COMER T-GEARBOX RESERVOIR RESERVOIR OIL FILTER PRESSURE SIDE OF CIRCULATION PUMP TRANSMISSION EXTERNAL FILTER TRANSMISSION INTERNAL FILTER INSIDE OIL PAN 1:2 INCREASER GEAR BOX SIGHT PLUG...

  • Page 24: Lubrication

    LUBRICATION CHART ALWAYS DISCONNECT OR DISENGAGE POWER TAKE OFF AND REMOVE KEYS FROM TRACTOR BEFORE ADJUSTING, LUBRICATION OR SERVICING THIS MACHINE. FAILURE TO HEED MAY RESULT IN SERIOUS PERSONAL INJURY OR DEATH. ITEM LUBRICATION INTERVAL Conveyor Chain Light Weight Oil Brush or spray on lightly every 40 hours of operation.

  • Page 25: Trouble Shooting

    TROUBLE SHOOTING ALWAYS DISCONNECT OR DISENGAGE POWER TAKE OFF AND REMOVE KEYS FROM TRACTOR BEFORE CLEANING, ADJUSTING, LUBRICATING OR SERVICING THIS MACHINE. FAILURE TO FOLLOW THIS RECOMMENDATION MAY RESULT IN SERIOUS PERSONAL INJURY OR DEATH. NOTE: THIS CHART DOES NOT COVER ALL PROBLEMS. CONTACT YOUR DEALERSHIP FOR FURTHER ASSISTANCE.
  • Page 26 1105A TRAILER DIMENSIONS FRONT CENTER DISCHARGE - 42" WIDE CONVEYOR HEIGHT DIMENSIONS BASED ON A 42" O.D. TIRE 11R x 22.5" 123 1/2" MAX. 115 1/2" 116 1/2" 31 1/2" 31 1/2" 2" 2 1/2" MAX. 9 1/2" 11" 119 1/2"...
  • Page 27 1105A TRAILER DIMENSIONS FRONT CENTER DISCHARGE - 42" WIDE CONVEYOR HEIGHT DIMENSIONS BASED ON A 42" O.D. TIRE 11R x 22.5" 123 1/2" MAX. 115 1/2" 116 1/2" 45" 2 1/2" MAX. 12 1/2" 119 1/2" INCLINE CONVEYOR EXTENDED INCLINE CONVEYOR RETRACTED 126 1/2"...
  • Page 28 1355A-1505A TRAILER DIMENSIONS FRONT CENTER DISCHARGE - 42" WIDE CONVEYOR HEIGHT DIMENSIONS BASED ON A 36.5" O.D. TIRE 255/R70 x 22.5" 123 1/2" MAX. 115 1/2" 34 1/2" 34 1/2" 6" 11 1/2" MAX. 21" 100" 19 1/2" FLAT CONVEYOR FLAT CONVEYOR FLAT CONVEYOR EXTENDED LEFT...
  • Page 29 1355A-1505A TRAILER DIMENSIONS FRONT CENTER DISCHARGE - 42" WIDE CONVEYOR HEIGHT DIMENSIONS BASED ON A 36.5" O.D. TIRE 255/R70 x 22.5" 123 1/2" MAX. 115 1/2" 135" (1355) 145" (1505) 48" 5 1/2" 11 1/2" MAX. 22" 100" INCLINE CONVEYOR INCLINE CONVEYOR EXTENDED RETRACTED...
  • Page 30 1355A - 1505A SIDE DISCHARGE DIMENSIONS 244 1/2" 145" (1505A) 135" (1355A) 187" 307 1/2" 123" 15" 99 1/2"...
  • Page 31 1105A TRAILER DIMENSIONS SIDE DISCHARGE 244 1/2" 114 1/2" 18"±2 1/4" 188 1/2" 309" 125 1/2" 116" 26 1/2" 4 1/2" 120 1/2"...
  • Page 32 1105A-1355A-1505A VERTICAL MIXER FEATURES & SPECIFICATIONS MODEL 1105A Trailer 1355A-1505A Trailer DESCRIPTION Maximum Load 19,800 LB. 24,300 LB. with Hay Ration Maximum Load 27,500 LB. 33,750 LB. with Heavy Ration Empty Weight, Approximate 17,100 LB. 20,600 LB. (1355) 1,150 CU. FT.

  • Page 33: Repair Parts

    REPAIR PARTS TABLE OF CONTENTS PAGE NO. MIXER ASSEMBLY ....................34-35 DRIVELINE ASSEMBLIES ..................36-38 INCREASER GEARBOX .................... 39 TRANSMISSION ...................... 40-43 TRANSMISSION COOLER ASSEMBLY ..............44-45 TRAILER GEARBOX CIRCULATION KIT ..............46-51 TRAILER PLATFORM ASSEMBLY ................52-53 TRAILER ASSEMBLIES .................... 54-55 TRAILER SPINDLE &...
  • Page 34 1105A-1355A-1505A MIXER ASSEMBLY TORQUE TO 600 FT-LBS 27 39 TORQUE TO 400 FT-LBS TORQUE TO 400 FT-LBS 4 28 29 28 29 18 27 17 26 28 29 25 33...
  • Page 35 1105A-1355A-1505A MIXER ASSEMBLY ITEM # PART # DESCRIPTION QTY. 160076 KNIFE BACKUP PLATE - LEFT HAND 160115 DOOR GUIDE BAR 160118 VERTICAL KNIFE 160619 CYLINDER PIN 5 7/8" 160620 CYLINDER PIN 1" x 4 1/4" 161290 AUGER COVER BOLT BAR 3/8 x 1 x 8 161298 AUGER ACCESS COVER - 7"...
  • Page 36 1105A-1355A-1505A GEARBOX DRIVELINES TRANSMISSION TO GEARBOX 11 13 GEARBOX TO GEARBOX 11 13 ITEM # PART # DESCRIPTION QTY. 338011 DRIVE LINE 1350 70" C-C (After Serial #8001857502) 338018 DRIVELINE 1350, 67-1/2" C-C, (Before Serial #800487644) 338015 DRIVELINE 1480 57" C-C, 42" CONVEYOR 338017 DRIVELINE 1480 32-1/2"...
  • Page 37 1105A TRACTOR DRIVE SHAFT ASSEMBLY #338034 ITEM # PART # DESCRIPTION QTY. 338443 CROSS KIT 32mm x 76mm W2400 338469 DOUBLE YOKE CVC - W-2400 365722 338470 CROSS & BEARING CVC KIT- W-2400 342221 338473 ROLL PIN 10mm x 90mm 338483 Yoke 1-3/8"...
  • Page 38 1355A-1505A TRACTOR DRIVE SHAFT ASSEMBLY #338570 23 21 ITEM # PART # DESCRIPTION 338446 CROSS KIT W2500 338454 INBOARD YOKE W2500 338473 ROLL PIN 10mm x 90mm 338489 BEARING RING 338503 SUPPORT BEARING- 355155 338600 YOKE 1-3/4" - 20 SPL QD W2500 ASG 135316 338601 DOUBLE YOKE CVC W-2500 365725 338602...
  • Page 39 GEARBOX, 2:1 INCREASER AP202 #344004 REF # PART # DESCRIPTION 310802 PLUG, 3/8" PIPE, BLACK 342229 BEARING 40mm ID x 90MM OD 31308 344227 SEAL M-10 INPUT 40 x 90 x 8 344236 SHAFT, INPUT AP2 6T 1-3/8" 344271 PINION GEAR Z14 M7 R1/2 344272 CROWN GEAR Z28 M7 R1/2 344273...
  • Page 40 1105A TRANSMISSION ASSEMBLY 34 50 37 49...
  • Page 41 1105A TRANSMISSION ASSEMBLY ITEM # PART # DESCRIPTION QTY. 160261 GEAR BOX BRACKET - 11" 160264 HOUSING COVER - 5 1/2" x 5 1/2" 160278 DIPSTICK BRACE- 1/4" x 3/4" x 8" 160290 SHIFTER CABLE BRACKET 160989 643 CONVERTER SPACER - 3/4"...
  • Page 42 1355A-1505A TRANSMISSION ASSEMBLY 34 48 29 39 31 37 47...
  • Page 43 1355A-1505A TRANSMISSION ASSEMBLY ITEM # PART # DESCRIPTION QTY. 160261 GEAR BOX BRACKET - 11" 160264 HOUSING COVER - 5 1/2" x 5 1/2" 160278 DIPSTICK BRACE- 1/4" x 3/4" x 8" 160290 SHIFTER CABLE BRACKET 161009 HOUSING SPACER BAR - 5 3/4" 161053 644 STA CONVERTER SPACER - 1/2"...
  • Page 44 1105A-1355A-1505A TRANSMISSION COOLER ASSEMBLY 15 17 13 16...
  • Page 45 1105A-1355A-1505A TRANSMISSION COOLER ASSEMBLY ITEM # PART # DESCRIPTION QTY. 310818 BUSHING 3/4" MP x 1/2" FP 362403 FILTER HEAD 3/4", ZAF-07-25-0 362440 FILTER ELEMENT - AE-10 362560 OIL TEMERATURE GAUGE 362576 HAYDEN COOLER 1292 368042 HYD SWIVEL 3/4"MP x 3/4"FP 90º...
  • Page 46 1105/1355/1505 VERTICAL CIRCULATION KIT BELT DRIVE #660240 27 32 36 25 30 34...
  • Page 47 1105/1355/1505 VERTICAL CIRCULATION KIT BELT DRIVE #660240 PART # DESCRIPTION QTY. 140689 MOTOR MOUNT TIGHTENER ROD 162710 PULLEY, 1350 3V-2 GROOVE DR FLG 324118 SHEAVE , 3V-2GRV X 4.75 SH 325383 V-BELT POWERBAND, 3VX-355 336008 BUSHING SH 1/2 QD 362010 HYDRAULIC PUMP, CCW ,PARKER 362240 CHECK VALVE, 5 PSI (1/2"...
  • Page 48 1105A-1355A-1505A GEARBOX CIRCULATION PARTS 34 41 DETAIL A...
  • Page 49 1105A-1355A-1505A GEARBOX CIRCULATION PARTS ITEM # PART # DESCRIPTION QTY. 162165 COOLER MOUNT PLATE 310818 BUSHING 3/4" MP x 1/2" FP 362403 FILTER HEAD 3/4", ZAF-07-25-0 362440 FILTER ELEMENT - AE-10 362549 TANK BREATHER 8" DIP STICK 362555 SIGHT GAUGE 5"...
  • Page 50 1105A-1355A-1505A GEARBOX CIRCULATION PARTS DIRECT DRIVE PUMP DETAIL B 39 33 29 24 50 DETAIL C...
  • Page 51 1105A-1355A-1505A GEARBOX CIRCULATION PARTS ITEM # PART # DESCRIPTION QTY. 161708 SHAFT ADAPTER, 1/2" 161709 SHAFT ADAPTER, 45mm 161711 BOLT SPACER, 3/8" 161712 CIRCULATION PUMP BRACKET 362011 HYDRAULIC PUMP C/W PARKER 362231 CHECK VALVE, 25 PSI 368020 HYD ADAPTER 3/8"MP x 3/8"FPX 90º...
  • Page 52 1105A-1355A-1505A PLATFORM ASSEMBLY #760597 10 13 10 12...
  • Page 53 1105A-1355A-1505A PLATFORM ASSEMBLY ITEM # PART # DESCRIPTION QTY. 161908 KICKBOARD RH REAR 161926 SPACER PLATE 162071 KICKBOARD LH REAR 162284 PLATFROM SUPPORT BAR - 865 162285 PLATFORM SUPPORT BAR - 745 310954 CAPLUG-RIBBED-SQ 1-1/4" x 1.175" 400107 HEX NUT, 3/8-16 SERR FLANGE #5 PLTD 400114 HEX NUT, 1/2"-13 SERRATED FLANGE #5 PLTD...
  • Page 54 1105A TRAILER ASSEMBLY 6 13 5 1/4" REF 4 1/2" REF ITEM # PART # DESCRIPTION QTY. 372425 WHEEL, 10 BOLT BUD 8-1/4" x 22.5" 372631 TIRE 11R x 22.5 RECAP 374101 CAT 3 CLEVIS INSERT (PPI-208VR) 374109 BASE HITCH ISO-21244 PPI-301VH 400117 FLANGE HEX NUT 1"-8 SERRATED...
  • Page 55 1355A-1505A TRAILER ASSEMBLY 5 1/4" 4 1/2" 2 1/4" ITEM # PART # DESCRIPTION QTY. 372077 AXLE ASSEMBLY 372188 TANDEM SUPENSION KIT, 44,000lb 374101 CAT 3 CLEVIS INSERT (PPI-208VR) 374109 BASE HITCH ISO-21244 PPI-301VH 400112 RH INNER THIMBLE & OUTER LUG NUT 400117 FLANGE HEX NUT 1"-8 SERRATED 400908...
  • Page 56 1105A-1355A-1505A HUB ASSEMBLY 1105A TRAILER SPINDLE ITEM # PART # DESCRIPTION QTY. 184614 20,000# SPINDLE (1105A ONLY) 342213 INNER BEARING 3.543" BORE 342214 OUTSIDE BEARING 2-5/8" OD 342215 INNER BEARING RACE 5.787"OD 342216 OUTSIDE BEARING RACE 4-13/16" OD 372212 10-BOLT HUB ASSEMBLY, (RIGHT HAND) 20,000# 372304 SEAL 4-3/8"...
  • Page 57 1105A-1355A-1505A TRAILER SCALE SYSTEM ASSEMBLY ITEM # PART # DESCRIPTION 160016 SCALE PAD 7-1/8" x 7-7/8" 401112 HEX NUT, 3/4"-10 NYLOC #5 PLTD 402012 SPLIT LOCK WASHER 3/4" PLTD 402112 LOCK WASHER, EXTERNAL STAR 3/4" 405778 HHCS 3/4"-10 x 1-3/4" #5 PLTD 405779 HHCS 3/4"-10 x 2"...
  • Page 58 1105A-1355A-1505A 42" WIDE FLAT CONVEYOR ASSY # 660247...
  • Page 59 1105A-1355A-1505A 42" WIDE FLAT CONVEYOR ASSY ITEM # PART # DESCRIPTION 161810 RAIL BOLT PLATE 161811 CONVEYOR SLIDE ROLLER 161872 CONVEYOR SIDE SHIELD 161934 CONVEYOR SLIDE RAIL FLAT & DOGLEG 161944 PLASTIC SLIDE RAIL 364076 HYDRAULIC CYLINDER 2" x 30", 40-1/4" C-C 368020 HYD SWIVEL 90º...
  • Page 60 1105A-1355A-1505A 42" WIDE FLAT CONVEYOR SLIDE ASSY #760171 33 23 19...
  • Page 61 1105A-1355A-1505A 42" WIDE FLAT CONVEYOR SLIDE ASSY #760171 ITEM # PART # DESCRIPTION 161508 PLASTIC IDLER 161774 DRIVE CHAIN COVER 161777 CONVEYOR BOLT PLATE 161780 PLASTIC LINER FLAT CONV 161783 MOTOR MOUNT TUBE 161830 CONVEYOR CHAIN HOLD DOWN 161940 SLIDE CYLINDER BOLT-ON LUG...
  • Page 62 1105A-1355A-1505A 42" WIDE INCLINE CONVEYOR ASSY #660245...
  • Page 63 1105A-1355A-1505A 42" WIDE INCLINE CONVEYOR ASSY ITEM # PART # DESCRIPTION 161383 MOUNT ANGLE 161775 DOGLEG RUBBER SHIELD 161810 RAIL BOLT PLATE 161811 CONVEYOR SLIDE ROLLER 161817 RUBBER SUPPORT PLATE 161818 DOGLEG EXTENSION SHIELD 161819 DOGLEG CONVEYOR REAR FILLER 161820...
  • Page 64 1105A-1355A-1505A 42" WIDE INCLINE CONVEYOR SLIDE ASSY # 760172 26 30 38 28 24 11 36 27 31...
  • Page 65 1105A-1355A-1505A 42" WIDE INCLINE CONVEYOR SLIDE ASSY # 760172 ITEM # PART # DESCRIPTION 161508 PLASTIC IDLER 161762 DOGLEG EXTENSION BOLT-ON 161774 DRIVE CHAIN COVER 161777 CONVEYOR BOLT PLATE 161783 MOTOR MOUNT TUBE 161784 CLEANOUT DOOR 42"W CONVEYOR 161786 CONVEYOR MOUNT ANGLE 161787 RUBBER HINGE 42"W CONVEYOR...
  • Page 66 1105A-1355A-1505A 42" WIDE ADJ INCLINE CONVEYOR ASSY #660244 27 28 16 22 19 20 19...
  • Page 67 1105A-1355A-1505A 42" WIDE ADJ INCLINE CONVEYOR ASSY #660244 ITEM # PART # DESCRIPTION 161383 MOUNT ANGLE 161532 CONVEYOR EXTENSION 161810 RAIL BOLT PLATE 161811 CONVEYOR SLIDE ROLLER 161866 SIDE SHIELD ADJUSTABLE CONVEYOR 161867 RUBBER SUPPORT PLATE 161868 CONV SLIDE RAIL ADJ CONV...
  • Page 68 1105A-1355A-1505A 42" WIDE ADJ INCLINE SLIDE ASSY # 760173 37 1 1 37 33 5...
  • Page 69 1105A-1355A-1505A 42" WIDE ADJ INCLINE SLIDE ASSY # 760173 ITEM # PART # DESCRIPTION 161508 PLASTIC IDLER 161774 DRIVE CHAIN COVER 161783 MOTOR MOUNT TUBE 161784 CLEANOUT DOOR 42"W CONVEYOR 161786 CONVEYOR MOUNT ANGLE 161787 RUBBER HINGE 42"W CONV 161788 HINGE STRAP 42"W CONVEYOR...
  • Page 70 1105A-1355A-1505A TRAILER SIDE DISCHARGE DOOR ASSY 19 20 17 24 21 32 19 20 12 15...
  • Page 71 1105A-1355A-1505A TRAILER SIDE DISCHARGE DOOR ASSY ITEM # PART # DESCRIPTION 160619 CYLINDER PIN 5 7/8" 160620 CYLINDER PIN 1" x 4 1/4" 160710 SUPPORT BAR 29" 160861 BELT HINGE CLAMP 45 1/2" 160862 BELT SKIRT 28" X 45 1/2"...
  • Page 72 1105A-1355A-1505A OLD STYLE GEARBOX CIRCULATION SYSTEM...
  • Page 73 1105A-1355A-1505A OLD STYLE GEARBOX CIRCULATION SYSTEM REF # PART # DESCRIPTION 362549 TANK BREATHER NBF-2016 8” DIP STICK 362555 5” SIGHT GUAGE 860064 GEAR BOX RESERVOIR WA 368608 ADAPTER TEE, 1/2”MP x (2) 1/2”FP 368028 ADAPTER, 1/2”MP x 3/8”FP, 90° SWIVEL 368031 ADAPTER, 1/2”MP x 1/2”FP, 90°...
  • Page 74 1105A-1355A-1505A 8" EXTENSIONS ITEM # PART # DESCRIPTION QTY. 160974 LEFT EXT. END 160975 RIGHT EXT END 860285 8" END EXT W.A.
