- Page 1 SOJI® Task Chair Installation Manual – June 2017 Revision: 1.0 E.C.O. No: 00000013511 Part Number: 6100-0077...
-
Page 2: Table Of Contents
Table of Contents Part Number: 6100-0076 Task Chair • Insert Cylinder • Attach Base Part Number: 6100-0077 Arm Replacement • Fixed Arm • Adjustable Arm Arm Cap Replacement • Fixed Arm Cap • Adjustable Arm Cap Back Replacement • Back •... -
Page 3: Task Chair
SOJI® Task Chair Installation Instructions No Tools Required Chair Cylinder Base NOTE: Carefully sit for 10 seconds to ensure solid connection (75lbs minimum). CUSTOMER SERVICE PHONE: 1-800-426-8562 E.C.O. No: 00000013511 1 OF 1 6100-0076 Rev: Page: Part No:... -
Page 4: Arm Replacement
SOJI® Arm Replacement Installation Instructions Scale 1 : 1 Tools Required Remove defective arm (E1) FIXED ARM ADJUSTABLE ARM Install new arm (E) S125 REMOVE SCREWS (S125) INSTALL ARM (C) RECYCLE ARM (C1) (S125) 1/4-20 x 2-11/32” Screw CUSTOMER SERVICE PHONE: 1-800-426-8562 E.C.O. -
Page 5: Fixed Arm
SOJI® Arm Cap Replacement Installation Instructions Scale 1 : 1 Tools Required ADJUSTABLE ARM (S130) M5 X 10 mm Washer Head Screw S130 FIXED ARM (S130) M5 X 10 mm Washer Head Screw S130 S130 CUSTOMER SERVICE PHONE: 1-800-426-8562 E.C.O. No: 00000013511 2 OF 2 6100-0077... -
Page 6: Back Replacement
SOJI® Back Replacement Installation Instructions Scale 1 : 1 Tools Required (S126) 5/16-18 x 1” Pan Head Screw REMOVE SCREWS (S126) S126 REMOVE BACK (A) RECYCLE BACK (A) CUSTOMER SERVICE PHONE: 1-800-426-8562 E.C.O. No: 00000013511 1 OF 4 6100-0077 Rev: Page: Part No:... - Page 7 NOTE: DO NOT use power (S126) tools to install screws. 5/16-18 x 1” Pan Head Screw Torque 120-130 in-lbs INSTALL SCREWS (S126) (Torque 120-130 in-lbs) S126 INSERT NEW BACK (A) CUSTOMER SERVICE PHONE: 1-800-426-8562 E.C.O. No: 00000013511 2 OF 4 6100-0077 Rev: Page:...
-
Page 8: Trim Cover
TRIM COVER NO GAP CUSTOMER SERVICE PHONE: 1-800-426-8562 E.C.O. No: 00000013511 3 OF 4 6100-0077 Rev: Page: Part No:... -
Page 9: Lumbar Replacement
SOJI® Lumbar Replacement Installation Instructions Scale 1 : 1 Tools Required PARTS S129 (S129) M5 X 12.5 mm Washer Head Screw S129 CUSTOMER SERVICE PHONE: 1-800-426-8562 E.C.O. No: 00000013511 4 OF 4 6100-0077 Rev: Page: Part No:... -
Page 10: Mechanism Replacement
SOJI® Mechanism Replacement Installation Instructions Scale 1 : 1 Tools Required (S127) (S128) 1/4-20 x 1-17/32” Button Head Screw 1/4-20 x 15/16” Button Head Screw Remove Mechanism Disconnect Forward Tilt (Optional) Remove arms (E) Remove Back (A) REMOVE SCREWS (S127 & 128) S127 Remove Base (C) S128... -
Page 11: Trim With Tilt
Trim Options Trim with Tilt Trim without Tilt Install Mechanism IMPORTANT! CABLE MUST HAVE LOOP AS SHOWN CUSTOMER SERVICE PHONE: 1-800-426-8562 E.C.O. No: 00000013511 2 OF 3 6100-0077 Rev: Page: Part No:... - Page 12 Connect Forward Tilt (Optional) PINCH PINCH NOTE: DO NOT use power tools to install screws (S127 & 128). S127 S128 Torque 120-130 in-lbs (S127) 1/4-20 x 1-17/32” Button Head Screw (S128) 1/4-20 x 15/16” Button Head Screw CUSTOMER SERVICE PHONE: 1-800-426-8562 E.C.O.
-
Page 13: Tension Crank
SOJI® Tension Crank Installation Instructions Scale 1 : 1 Tools Required PARTS TENSION CRANK REPLACEMENT CUSTOMER SERVICE PHONE: 1-800-426-8562 E.C.O. No: 00000013511 1 OF 1 6100-0077 Rev: Page: Part No:... -
Page 14: Disassembly & Recycling
SOJI® Task Chair Disassembly & Recycling Instructions Tools Required RECYCLE BINS STEEL NYLON/PLASTIC Fixed Arm Height Adjustable Arm 4D Arms CUSTOMER SERVICE PHONE: 1-800-426-8562 E.C.O. No: 00000013511 1 OF 4 6100-0077 Rev: Page: Part No:... - Page 15 RECYCLE BINS NYLON/PLASTIC FOAM/RUBBER RECYCLE BINS STEEL NYLON/PLASTIC FABRIC CUSTOMER SERVICE PHONE: 1-800-426-8562 E.C.O. No: 00000013511 2 OF 4 6100-0077 Rev: Page: Part No:...
- Page 16 RECYCLE BINS STEEL ALUMINUM RUBBER RECYCLE BINS STEEL NYLON/PLASTIC CUSTOMER SERVICE PHONE: 1-800-426-8562 E.C.O. No: 00000013511 3 OF 4 6100-0077 Rev: Page: Part No:...
- Page 17 RECYCLE BINS FOAM MATERIAL WOOD CUSTOMER SERVICE PHONE: 1-800-426-8562 E.C.O. No: 00000013511 4 OF 4 6100-0077 Rev: Page: Part No:...
