- Page 1 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE SHIFT Installation Guide Asia Pacific ECO No: BT0-001 M Page: 1 OF 45 Part No: 7029-9941 Rev: B...
-
Page 2: Table Of Contents
HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Table of contents Item Page • 1. Introduction……………..……………………………………………….3 • 2. Junction………………………………………………………………….4 • 3. Panel……………………………………………………………………..7 • 4. Supporting ………..……………………………………………………19 • 5. End trim/Top trim ………………………………………………..……23 • 6. Sliding bracket ……………………………………………………..26 • 7. Raceway cover ……………………………………………………….28 •... -
Page 3: Introduction
HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 1. Introduction The following installation guide assumes some knowledge of the installation of SHIFT, this guide will be updated as new elements are released within SHIFT range. ECO No: BT0-001 M Page: 3 OF 45... -
Page 4: Junction
HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 2. Junction Junction support various configurations such as 2-way 90-degree, 3-way 90 degree, 4-way 90 degree and 120-degree.Junction delivers together with panel connector, screws, light block foam and capping. And following is 3- way 90 degree junction instruction. - Page 5 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE bottom connector upper down Screw: 4*10 upper down ECO No: BT0-001 M Page: 5 OF 45 Part No: 7029-9941 Rev: B...
- Page 6 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Down direction Upper direction connector Bottom connector Note: direction of aligner, only one side aligner is down awards, and other sides aligner is upper awards as above shown. ECO No: BT0-001 M Page: 6 OF 45...
-
Page 7: Panel
HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 3. Panel In each vertical rail of panel, have 4 holes dividing two groups, and each group has 2 holes. Upper hole is for aligner down direction, lower hole is for aligner upper direction as below image shown. - Page 8 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Step 1: fix aligner with upper direction as following image shown. aligner Upper direction aligner Upper direction ECO No: BT0-001 M Page: 8 OF 45 Part No: 7029-9941 Rev: B...
- Page 9 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Step 2: Push block light EPE form into slot of panel vertical rail as following image shown. ECO No: BT0-001 M Page: 9 OF 45 Part No: 7029-9941 Rev: B...
- Page 10 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Step 3: let’s connect panel with junction PS: firstly connect panel with junction of down direction. Sliding down junction ECO No: BT0-001 M Page: 10 OF 45 Part No: 7029-9941 Rev: B...
- Page 11 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Step 4: push down junction, and set panel top connector on slot between junction and vertical of panel, and fix top connector. Top connector Notes: panel connector applying in junction, should mount this small screw, spec is M5*12.
- Page 12 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE After complete first panel connection panel with junction, please check other aligners direction on junction, it should be upper direction. Aligner upper direction Aligner upper direction ECO No: BT0-001 M Page: 12 OF 45...
- Page 13 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Step 4: fix aligner with down direction on another panel. ECO No: BT0-001 M Page: 13 OF 45 Part No: 7029-9941 Rev: B...
- Page 14 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE So connecting this panel with above junction as following image shown. ECO No: BT0-001 M Page: 14 OF 45 Part No: 7029-9941 Rev: B...
- Page 15 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE So now we connect 2 panels and 1 junction together as following image shown. ECO No: BT0-001 M Page: 15 OF 45 Part No: 7029-9941 Rev: B...
- Page 16 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Step 5: fix aligner with upper direction as below image shown: Detail Detail Aligner upper direction as following image shown Detail A Detail B ECO No: BT0-001 M Page: 16 OF 45 Part No: 7029-9941...
- Page 17 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Step 6: fix aligner with down direction as following image shown: ECO No: BT0-001 M Page: 17 OF 45 Part No: 7029-9941 Rev: B...
- Page 18 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Step 7: Connecting this panel with Step 5 workstation Panel connection completed, then adjust leveling For Monolithic Panel connection will all same as segment panel Note: after panel connection complete, should move workstation together, should NOT move separately panel;...
-
Page 19: Supporting
HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 4. Supporting Supporting including frame leg and sliding bracket. Frame leg has L shape and U shape and each type has left hand, right hand and share. Leg delivers together with bracket. A: L shape Share leg Step 1: use M6 screw to mount share end bracket with leg as below image shown. - Page 20 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE B: L shape end leg Step 1: mount two bracket with leg tube by M6 screws as following image shown. Step 2: insert leg bracket to panel intermediate rail, then knock leg tube to push vertical rail rib in slot of leg bracket.
- Page 21 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE C: U shape end leg Step 1: Mount L shape bracket to leg tube, it same as L shape end leg. Step 2: fix bottom small bracket to panel bottom rail by M5 screw.
- Page 22 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE D: Monolithic panel end U leg The monolithic panel end U leg installation all follow segment end U leg except no extra bending(on bracket to slot intermedia rail) as monolithic has no intermedia leg...
-
Page 23: End Trim/Top Trim
HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 5. End trim/Top trim End trim would deliver together with end cap, screws. Top trim would deliver together with panel by sticking 3M tape. step 1: insert end cap to top trim slot and screw fixed as below image shown. - Page 24 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Mount 25T end trim and top trim as following image shown. Step 1: knock end trim into slot of panel vertical rail. Step 2: fix end cap with top trim, then knock top trim into slot of panel horizontal rail.
- Page 25 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE ECO No: BT0-001 M Page: 25 OF 45 Part No: 7029-9941 Rev: B...
-
Page 26: Sliding Bracket
HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 6. Sliding bracket insert sliding bracket into panel intermediate rail to support worktop and screw fixed it. refer details for following typical workstation. Bench 6 workstation. Top view Note: • For 90 degree / 120 degree corner, apply 2 sliding brackets in corner (100mm away from vertex) as corner support. - Page 27 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE L shape 4 workstation Top view Note: • For 90 degree / 120 degree corner, apply 2 sliding brackets in corner (100mm away from vertex) as corner support. • For application with return panel, apply a sliding bracket as end bracket to connect the panel &...
-
Page 28: Raceway Cover
HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 7. Raceway cover Here have 2 different slots on raceway cover Step1: stick EVA foam on both side of raceway cover as below image shown. Step2: put two vacuum chuck on raceway cover and catch up it. -
Page 29: Add-On Screen
HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 8. Add-on acrylic screen Add-on acrylic screen delivers together with add-on top trim and gasket and some screws. Step 1: disassemble top trim from panel. mount add-on screen rail fixing screws on panel. Step 2: insert acrylic screen with gasket into add-on screen rail, and push down. -
Page 30: Hung Screen
HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 9. Hung screen 9.1 Segment hung screen Hung screen comes with top trim. Following shows hung screen connect with single desk. Step 1: insert LH/RH bracket into slot of middle rail, and knock bracket side to keep panel vertical rail into bracket slot. - Page 31 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Step 3: mount hung screen to single desk and screw fixed with worktop. Following shows hung screen connect with work cluster with shared hung screen bracket. Step 1: mount panel connector to one hung screen and connect each other like panel connecting.
- Page 32 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 9.2 Monolithic hung screen Step 2: Fix RH BKT as same way , if the width Step 1: Fix LH BKT to vertical rail, there are larger than 1200(include) then need install middle pre-nut on monolithic screen...
-
Page 33: Stabilizer Foot
HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 10. Stabilizer foot 10. 1 End stabilizer foot Stabilizer foot proivde additional support for panel free end. Including foot and 4pcs screws. Step 1: put panel into slot of bracket then screw tight fixed. - Page 34 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 10. 2 Intermediate stabilizer foot Step 2: Slide insert from middle of 2 panels Then fix the insert with M5 screws back side same operate Step 1: Slide stabilizer foot to middle of 2 panels...
-
Page 35: Osu
HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 11. OSU Step 1: Assembly OSU as normal Step 2: Install top BKT of OSU(by using 4 inserts same as BB2 done) Step 3: Fix top bracket with side bracket by Step 4: Hung the OSU to horizontal rail... -
Page 36: Shelf
HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 12. Shelf 12. 1 LPL Shelf Step 1: Fix end panel with shelf with self screw Step 2: Stick bumpers back of end panel Screw Spec: ST4.0x19 Bumper Spec: 12.7 x 3.5T Screw QTY : 4 pc... - Page 37 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 12. 2 Metal Shelf Step 2: Stick bumpers back of end panel Step 1: Fix end panel with shelf with nut Bumper Spec: 12.7 x 3.5T Nut Spec: M6 Bumper QTY : 4 pc...
-
Page 38: Transaction Top
HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 13. Transaction top Step 1: Slide counter top BKT from top along Step 2: Use set screw fix the BKT vertical rail until top hook fit to top rail, Screw Spec: M5 X 6... -
Page 39: Lateral Screen
HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 14. Lateral screen 14.1 Handed Step 1: loose pan head screw on vertical rail bottom and insert adapter plate into vertical rail slot as following pic 1 shown, and then tight screw again. To keep plate protrude bottom rail around 2mm. - Page 40 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Step 4: Move laterial screen from front to back Step 5: Fix handed front BKT on vertical rail make sure the set screw can into hole keep flush with worktop on vertical rail of laterial screen...
- Page 41 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 14.2 Shared Step 1: Fix 2 pcs shared back BKT to vertical rail Screw Spec: M4 X 6 Screw QTY : 2 pc Step 2: Slide laterial screen to the gap of vertical rails...
-
Page 42: Panel (Old Version To New Version)
HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE 15. Panel (new version to old version) Step 1: Manual drill a hole(Ø 3.5)as following image in old version panel. Detail size refers to below drawing shown. Manual drill this Ø3.5 hole ECO No: BT0-001 M... - Page 43 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Step 2: Fix two aligners in down direction to the manually drilled hole and the middle hole. Refer to the image below. Aligner down direction Aligner down direction ECO No: BT0-001 M Page: 43 OF 45...
-
Page 44: Bottom Connector
HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Step 3: Fix two aligners in upper direction and a bottom connector in new version panel as below image shown. Bottom connector Aligner Upper direction Aligner Upper direction ECO No: BT0-001 M Page: 44 OF 45... - Page 45 HAWORTH ASIA PACIFIC PRODUCT INSTALLATION GUIDE Step 4: Connect two versions of panels and fixe by top connector. Refer to the image below. old version New version panel panel Note: • Both the old version and new version share the same panel to panel connection and installation.
