AMX VST-MVRT Dimensional Drawing

MINIVERTER
MINIVERTER BRACKET
UNLESS OTHERWISE SPECIFIED:
NOTICE: This drawing is the
property of AMX Corporation.
TOLERANCE ON DECIMAL DIMENSIONS: XX = .010
All information contained herein
XXX = .005
that is not generally known
TOLERANCE ON HOLE DIAMETERS:
shall be confidential except UNDER .250 ú = +/- .005
.250 TO .500 = +.006 -.005
to the extent the information
OVER .500 = +.008 -.005
has been previously established.
FRACTIONAL DIMENSIONS INCLUDING HOLES: +/- 1/64
This drawing may not be copied, ANGLES: +/- 1.0°
SURFACE FLATNESS .003 TIR PER LINEAR INCH.
reproduced, or used as the basis
ALL DIMENSIONS IN INCHES.
for manufacture or sale without
DO NOT SCALE THIS DRAWING.
written permission.
REVISIONS
REV ECN DESCRIPTION
A 4908 PRODUCTION RELEASE
REL APPR REL DATE REV APPR
DRAWN DAS 4/1/03
TM
ENGR SERV PL 4/11/03
PICTORIAL,
ENGINEER PS 4/11/03
VST-MVRT, MINIVERTER MODULE
TG 4/11/03
PROD ENGR FOR VIEWSTAT
MD 4/11/03
MATL SUP
QUALITY AK 4/11/03 SIZE SCALE DWG. NO.
95-0944-02
B
FULL
THIRD ANGLE
PROJECTION
95-0944-02-A
DATE APPROVED
4/11/03
REV.
A
1 OF 1
SHEET
