AMX VST-DIST Dimensional Drawing

1.70
[43mm]
5.00
[127mm]
10.50
[267mm]
NOTICE: This drawing is the
property of AMX Corporation.
All information contained herein
that is not generally known
shall be confidential except
to the extent the information
has been previously established.
This drawing may not be copied,
reproduced, or used as the basis
for manufacture or sale without
written permission.
REV ECN
4908 PRODUCTION RELEASE
A
REL APPR REL DATE
UNLESS OTHERWISE SPECIFIED:
DAS 4/1/03
DRAWN
TOLERANCE ON DECIMAL DIMENSIONS: XX = .010
XXX = .005 ENGR SERV PL 4/11/03
TOLERANCE ON HOLE DIAMETERS:
PS 4/11/03
ENGINEER
UNDER .250 ú = +/- .005
.250 TO .500 = +.006 -.005
TG 4/11/03
PROD ENGR
OVER .500 = +.008 -.005
FRACTIONAL DIMENSIONS INCLUDING HOLES: +/- 1/64
MD 4/11/03
MATL SUP
ANGLES: +/- 1.0°
SURFACE FLATNESS .003 TIR PER LINEAR INCH.
AK 4/11/03
QUALITY
ALL DIMENSIONS IN INCHES.
THIRD ANGLE
DO NOT SCALE THIS DRAWING.
PROJECTION
REVISIONS
DESCRIPTION DATE APPROVED
4/11/03
REV APPR
TM
PICTORIAL,
VST-DIST, DISTRIBUTION PANEL,
VIEWSTAT S422
SIZE SCALE DWG. NO. REV.
95-0944-03
B FULL
A
1 OF 1
95-0944-03-A SHEET
