Summary of Contents for PCE Instruments PCE-CT 21BT
- Page 1 PCE-CT 2X BT Series Coating Thickness Gauge User manuals in various languages (français, italiano, español, português, nederlands, türk, polski, русский, 中文) can be found by using our product search on: www.pce-instruments.com Last change: 3 November 2020 v1.0 © PCE Instruments...
-
Page 2: Table Of Contents
11 Limit value alarm ................... 7 12 Convert unit ................... 7 13 Backlight ....................7 14 Software ....................7 14.1 PC transfer ........................8 15 App transfer ................... 9 16 Troubleshooting .................. 11 17 Warranty ....................12 18 Disposal ....................12 © PCE Instruments... -
Page 3: Safety Notes
We expressly point to our general guarantee terms which can be found in our general terms of business. If you have any questions please contact PCE Instruments. The contact details can be found at the end of this manual. © PCE Instruments... -
Page 4: Technical Specifications
Technical specifications Model PCE-CT 21BT PCE-CT 22BT PCE-CT 23BT Measurable substrates Fe, NFe Fe, NFe Probe external internal external Measurement range 0 ... 1500 µm Resolution 0.1 µm (within meas. range 0 ... 99.9 µm) 1 µm (within meas. range 100 ... 1500 µm) Accuracy ±(1 µm + 2 % of the coating thickness) -
Page 5: Display Description
Open the menu, apply changes to the settings. Calibration key, back Press this key to enter the calibration menu. Press this key to go back one step and exit the menu. Arrow keys Change parameters and select the desired function in the menu. © PCE Instruments... -
Page 6: Power Supply
The lower part of the display shows the currently selected function at the menu level. You can use the arrow keys to select between the functions and also change parameter values. Press the key to open the corresponding function. Press the back key to go back one level. © PCE Instruments... -
Page 7: Menu Structure
A calibration of magnetic (Fe) and non-magnetic substrates (nFe) is independent on each other. After each calibration, check the measured values again with the references. If the measured values are still not within the accuracies, repeat the calibration if necessary. © PCE Instruments... -
Page 8: Zero Point Calibration
To discard the setting, press the key. Important: When instructed to lift the probe, lift the probe quickly and place it 30 cm away from the reference before changing the reference film. © PCE Instruments... -
Page 9: Data Group
The data from the coating thickness gauge can also be exported. For this purpose, there is the possibility of Bluetooth transfer to an Android or iOS device. It is also possible to transfer the data to a PC via the micro USB interface. © PCE Instruments... -
Page 10: Pc Transfer
Under the tab "Data", the displays on the meter are now shown mirrored in the programme. This means that the data are live-transferred to the PC. The software is synchronised with the meter via the "Sync" button. © PCE Instruments... -
Page 11: App Transfer
You will then be taken directly to the measurement window where the current measured value is displayed. Via the "Master" function, the meater is synchronised with the mobile device. © PCE Instruments... - Page 12 Alarm vibration When the limit value is reached, the vibration alarm is activated. Paired gauge Click here for more information about this meter. About CoatingMaster Here you can find more information about the app. © PCE Instruments...
-
Page 13: Troubleshooting
The meter is used under The coating thickness gauge may only be difficult to read the wrong environmental located in areas with the specified conditions environmental conditions. Otherwise damage can occur. Other technical Please contact PCE Instruments’ technical problems support. © PCE Instruments... -
Page 14: Warranty
For countries outside the EU, batteries and devices should be disposed of in accordance with your local waste regulations. If you have any questions, please contact PCE Instruments. © PCE Instruments... - Page 15 PCE Instruments contact information Germany France Spain PCE Deutschland GmbH PCE Instruments France EURL PCE Ibérica S.L. Im Langel 4 23, rue de Strasbourg Calle Mayor, 53 D-59872 Meschede 67250 Soultz-Sous-Forets 02500 Tobarra (Albacete) Deutschland France España Tel.: +49 (0) 2903 976 99 0 Téléphone: +33 (0) 972 3537 17...
