  • Page 1 Bedienungsanleitung User Manual PCE-MFM 2400 Teslameter User manuals in various languages (français, italiano, español, português, nederlands, türk, polski, русский, 中文) can be found by using our product search on: www.pce-instruments.com Letzte Änderung / last change: 3 December 2019 v1.0 © PCE Instruments...
  • Page 2: Table Of Contents

    Display ..........................4 Funktionstasten ........................ 4 Vorbereitung ..................5 Stromversorgung ......................5 Inbetriebnahme ........................ 5 Betrieb ....................5 Nullpunktjustage ....................... 5 Messen ..........................5 Automatische Abschaltung ....................6 Anzeigefunktionen ......................6 Garantie ....................7 Entsorgung .................... 7 © PCE Instruments...
  • Page 3 Interfaces ........................10 Display ..........................11 Function keys ........................11 Getting started ..................12 Power supply ........................12 Preparation ........................12 Operation ..................... 12 Zero point adjustment ......................12 Measurement ........................12 Auto Power Off ........................13 Display functions ......................13 Warranty ....................14 Disposal ....................14 © PCE Instruments...
  • Page 4: Sicherheitsinformationen

    Für Druckfehler und inhaltliche Irrtümer in dieser Anleitung übernehmen wir keine Haftung. Wir weisen ausdrücklich auf unsere allgemeinen Gewährleistungsbedingungen hin, die Sie in unseren Allgemeinen Geschäftsbedingungen finden. Bei Fragen kontaktieren Sie bitte die PCE Deutschland GmbH. Die Kontaktdaten finden Sie am Ende dieser Anleitung. © PCE Instruments...
  • Page 5: Spezifikationen

    Spezifikationen Technische Spezifikationen Spezifikationen des Messgeräts PCE-MFM 2400 Spezifikation Erläuterung 0 … 200 mT Messbereich 200 … 2400 mT 0 … 2000 Gs 2000 … 24000 Gs Genauigkeit ±1 % v. Mw. Auflösung 0,01 mT 0,1 Gs Messrichtung transversal (Standardsensor)
  • Page 6: Systembeschreibung

    Systembeschreibung Gerät 1. Display 3. Batteriefach 2. Folientastatur 4. Sensorgriff mit Hall-Sensor Anschlüsse 1. Anschlussbuchse © PCE Instruments...
  • Page 7: Display

    Maximalmesswert auf dem Display beibehalten. Im Display HOLD wird „Hold“ angezeigt. Bei erneutem Drücken wird die Messung normal fortgesetzt und das Symbol verschwindet. Licht Hintergrundbeleuchtung ein- und ausschalten ZERO Nullpunktjustage Einheit Einheit zwischen mT und Gs umstellen (1 mT = 10 Gs) © PCE Instruments...
  • Page 8: Vorbereitung

    Sensorebene steht. Die Tabelle zeigt die Messabweichung nach dem Winkel zwischen dem Flussvektor und der Sensorebene. Winkel des Sensors zum Flussvektor Prozentuale Abweichung 10 ° 2,5 % 20 ° 30 ° 15,2 % 45 ° 30,3 % © PCE Instruments...
  • Page 9: Automatische Abschaltung

    Display angezeigt. In jedem Bereich wird über die Prozentleiste der aktuell ausgeschöpfte Messbereich als Prozentsatz angezeigt. Die Prozentleiste hat insgesamt 10 Kästen mit je 10 %iger Gewichtung. Wenn der Messwert größer als 2400 mT und die Leiste voll ist, zeigt das Gerät „Over Range“ an. © PCE Instruments...
  • Page 10: Garantie

    Zur Umsetzung der ElektroG (Rücknahme und Entsorgung von Elektro- und Elektronikaltgeräten) nehmen wir unsere Geräte zurück. Sie werden entweder bei uns wiederverwertet oder über ein Recyclingunternehmen nach gesetzlicher Vorgabe entsorgt. Alternativ können Sie Ihre Altgeräte auch an dafür vorgesehenen Sammelstellen abgeben. WEEE-Reg.-Nr.DE69278128 © PCE Instruments...
  • Page 11: Safety Notes

    We expressly point to our general guarantee terms which can be found in our general terms of business. If you have any questions please contact PCE Instruments. The contact details can be found at the end of this manual. © PCE Instruments...
  • Page 12: Specifications

    Specifications Technical specifications Specifications of the meter PCE-MFM 2400 Specification Description 0 … 200 mT Measurement range 200 … 2400 mT 0 … 2000 Gs 2000 … 24000 Gs Accuracy ±1 % of rdg. Resolution 0.01 mT 0.1 Gs Measuring direction...
  • Page 13: System Description

    System description Device 1. Display 3. Battery compartment 2. Membrane keypad 4. Sensor handle with Hall sensor Interfaces 1. Connection socket © PCE Instruments...
  • Page 14: Display

    “Hold“ will be displayed. When the key is HOLD pressed again, the measurement will be continued normally and the ”Hold“ icon disappears. Light Turn backlight on/off ZERO Zero point adjustment Unit Switch unit to mT or Gs (1 mT = 10 Gs) © PCE Instruments...
  • Page 15: Getting Started

    The following chart shows the measuring deviation in line with the angle between the flux vector and the sensor plane. Sensor’s angle to the flux vector Deviation in per cent 10 ° 2.5 % 20 ° 30 ° 15.2 % 45 ° 30.3 % © PCE Instruments...
  • Page 16: Auto Power Off

    The percentage bar has 10 boxes which stand for a portion of 10 % each. If the reading is higher than 2400 mT and the percentage bar is full, the meter will display ”Over Range“. © PCE Instruments...
  • Page 17: Warranty

    For countries outside the EU, batteries and devices should be disposed of in accordance with your local waste regulations. If you have any questions, please contact PCE Instruments. © PCE Instruments...
  • Page 18 PCE Instruments contact information Germany France Spain PCE Deutschland GmbH PCE Instruments France EURL PCE Ibérica S.L. Im Langel 4 23, rue de Strasbourg Calle Mayor, 53 D-59872 Meschede 67250 Soultz-Sous-Forets 02500 Tobarra (Albacete) Deutschland France España Tel.: +49 (0) 2903 976 99 0 Téléphone: +33 (0) 972 3537 17...
  • Page 19 © PCE Instruments...
  • Page 20 User manuals in various languages (français, italiano, español, português, nederlands, türk, polski, русский, 中文) can be found by using our product search on: www.pce-instruments.com Specifications are subject to change without notice. © PCE Instruments...
