Click open to add a building to the project.
You can add a new building or open an already
existing building in the window that opens. Click
new to add a room to the building. The following
parameters are available per room:

Room type

Number of rooms

Amount of air inlets

Amount of air exhausts

The default type of grill
The picture on the right shows what it looks like
when several rooms are added.
Click save to save the project to the SD-card.
It is recommended to use the standard type of SD-card(Sandisk ultra II 2.0GB or an other class
4 SD-card) The time to store the project can increase significantly when a different type of SD-
card is used.

7.3 The DIFF with a SD-card

Put the SD-card into the DIFF and switch it on.
Go to the storage option.
Select project
=======================
 Project
Project 2
Select the building that you are going to measure
Building_1
=======================
 Living room
Toilet
Study room
Bath room
Bedroom
Select the grill
Version: 12.6 EN
In the next window you will see a list with the stored projects.
Select the project that you are going to measure
Select the room
Date: 22-09-2020
User Manual Diff
Menu
=======================
Measurement
Storage
Calibration
Off
Settings
Project
=======================
 Building_1
Building_2
Building_3
Living room
=======================
 Supply 1
Supply 2
Exhaust 1
Exhaust 2
AT-DIFF
Page: 18 of 28
