Click open to add a building to the project.
You can add a new building or open an already existing building in the window that opens. Click
new to add a room to the building. The
following parameters are available per
room:

Room type

Number of rooms

Amount of air inlets

Amount of air exhausts

The default type of grill
The picture on the right shows what it
looks like when several rooms are
added.
Click save to save the project to the SD-
card.
It is recommended to use the standard type of SD-card(Sandisk ultra II 2.0GB or an
other class 4 SD-card) The time to store the project can increase significantly when a
different type of SD-card is used.

7.3 The DIFF with an SD-card

Put the SD-card into the DIFF and switch it on.
Go to the storage option.
Select project
=======================
 Project
Project 2
Select the building that you are going measure
Building_1
=======================
 Living room
Toilet
Study room
Bath room
Bedroom
Select the grill
V11.2 - EN
DIFF automatic volume flow meter
In the next window you will see a list with the stored projects.
Select the project that you are going to measure
Select the room
Page 17
User manual
Menu
=======================
Measurement
Storage
Calibration
Off
Settings
Project
=======================
 Building_1
Building_2
Building_3
Living room
=======================
 Supply 1
Supply 2
Exhaust 1
Exhaust 2
TDC 16-7-2012
