Briggs & Stratton 326400 Series Illustrated Parts List

Briggs & Stratton 326400 Series Illustrated Parts List

Briggs & stratton illustrated parts list
Hide thumbs

Advertisement

Quick Links

Download this manual

Illustrated Parts List

Model Series
326400
TYPE NUMBERS:
0010 through 0080,
0110 through 0399,
0611, 0620,
0630 through 0799,
0801, 0802, 0803, 0804, 0805,
1160, 2520, 2521, 2522, 2526, 2527,
2528, 2529, 2530, 2550, 2560, 2561,
2562, 2563, 2580, 2581, 2582, 2583, 2596.
All rights reserved. No part of this material may be reproduced or transmitted,
in any form or by any means, electronic or mechanical, including photocopying,
recording or by any information storage and retrieval system, without permission
in writing from Briggs & Stratton Corporation.
REPLACES FORM MS6179−08/23/2007
FILE IN SECT. 2 OF SERVICE MANUAL
COPYRIGHT by BRIGGS & STRATTON CORPORATION
FORM MS6179−03/18/2009
326400
PRINTED IN U.S.A.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 326400 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Briggs & Stratton 326400 Series

Summary of Contents for Briggs & Stratton 326400 Series

  • Page 1: Illustrated Parts List

    Illustrated Parts List Model Series 326400 TYPE NUMBERS: 0010 through 0080, 0110 through 0399, 0611, 0620, 0630 through 0799, 0801, 0802, 0803, 0804, 0805, 1160, 2520, 2521, 2522, 2526, 2527, 2528, 2529, 2530, 2550, 2560, 2561, 2562, 2563, 2580, 2581, 2582, 2583, 2596.
  • Page 2 724A REF. PART DESCRIPTION 395663 Cylinder Assembly 691712 Head−Cylinder 691261 Washer (Cylinder Head) 692231 Gasket−Cylinder Head 495738 Breather Assembly 27803s Gasket−Breather 690294 Screw (Breather Assembly) 691512 Tube−Breather 691614 Screw (Cylinder Head) (1 3/4” Long) −−−−−−− Note −−−−− 691640 Screw (Cylinder Head) (2 1/16”...
  • Page 3 REF. PART DESCRIPTION 792365 Piston Assembly (Standard) −−−−−−− Note −−−−− 792367 Piston Assembly (.020 Oversize) 792366 Ring Set (Standard) −−−−−−− Note −−−−− 792368 Ring Set (.020 Oversize) 691792 Lock−Piston Pin 299691 Pin−Piston 299632 Rod−Connecting 691726 Dipper− Connecting Rod 690396 Lock−Rod Screw 692345 Screw (Connecting Rod) 394436 Valve−Exhaust...
  • Page 4 REF. PART DESCRIPTION 691797 Crankshaft −−−−−−− Note −−−−− 690534 Crankshaft Used on Type No(s). 0237, 0133, 0190, 0252, 0315, 0788, 2582. 261222 Crankshaft Used on Type No(s). 0139, 0204, 0228, 0328, 0678. 690535 Crankshaft Used on Type No(s). 0050, 0116, 0130, 0143, 0147, 0149, 0150, 0151, 0156, 0167, 0170, 0172,...
  • Page 5 REF. PART DESCRIPTION 690946 Plug−Oil Drain 691680 Plug−Oil Drain 21 281658s Cap−Oil Fill 691104 Screw (Engine Base) 294751 Base−Engine Used on Type No(s). 0020, 0023, 0050, 0139, 0145, 0150, 0151, 0152, 0155, 0159, 0175, 0191, 0199, 0203, 0206, 0208, 0212, 0218, 0219, 0226, 0356, 0804, 2527, 2583.
  • Page 6 1141 228A REF. PART DESCRIPTION 691948 Seal−Oil (PTO Side) 20A 291675s Seal−Oil (PTO Side) 691681 Screw (Bearing Support) 228A 691058 Screw (Bearing Support) 391062 Support−Bearing 571A 291665 Support−Bearing Used on Type No(s). 0022, 0050, 0062, 0063, 0112, 0113, 0114, 0116, 0130, 0143, 0147, 0149, 0150, 0151, 0153, 0156, 0160, 0167,...
  • Page 7 749A 523A 1054 665A REF. PART DESCRIPTION 691948 Seal−Oil (Magneto Side) 690258 Washer−Sealing 690270 Gasket−Dipstick 690304 Screw (Timing Hole Plug) 691310 Gasket− Counterweight Cover (Magneto Side) 399A 692914 Gasket− Counterweight Cover (PTO Side) 691352 Dipstick 523A 690620 Dipstick 281370s Seal−Dipstick Tube Engine Gasket Set−Reference 358 Carburetor Overhaul Kit−Reference 121 6179−7...
  • Page 8 1227 REF. PART DESCRIPTION 391065 Carburetor −−−−−−− Note −−−−− 391068 Carburetor Used on Type No(s). 0121, 0144, 0157, 0158, 0164, 0165, 0169, 0170, 0184, 0192, 0240, 0331. 391070 Carburetor Used on Type No(s). 0127, 0133, 0134, 0135, 0136, 0139, 0140, 0149, 0162, 0163, 0166, 0172, 0173, 0180, 0185, 0186, 0201, 0204,...
  • Page 9 1227 REF. PART DESCRIPTION 691152 Manifold−Intake −−−−−−− Note −−−−− 692525 Manifold− Intake Used on Type No(s). 0248, 0308, 0358, 0638, 0707, 0770. 27381 Gasket−Intake 692214 Gasket−Intake 691681 Screw (Intake Manifold) Carburetor (See Previous Page) 299687 Body− Upper Carburetor −−−−−−− Note −−−−− 391067 Body−...
  • Page 10 206A REF. PART DESCRIPTION 690267 Collar−Bell Crank 261027 Link−Air Vane Used on Type No(s). 0234, 0705. 690263 Crank−Bell 691681 Screw (Bell Crank) Used on Type No(s). 0136, 0139, 0204, 0228, 0234, 0248, 0328, 0678, 0705. 205A 690810 Screw (Bell Crank) 691079 Nut−Governor Adjusting 206A...
  • Page 11 163A REF. PART DESCRIPTION 67247 Gasket−Air Cleaner Used on Type No(s). 0308. 163A 270987 Gasket−Air Cleaner 691241 Stud−Air Cleaner (9 1/2” Long) Engine Gasket Set−Reference 358 Carburetor Overhaul Kit−Reference 121 6179−11 1158 REF. PART DESCRIPTION 691331 Nut (Air Cleaner) 171A 690284 Nut (Air Cleaner) 393957s Filter−...
  • Page 12 300C 613A 300A 300B REF. PART DESCRIPTION 691178 Lock−Muffler Screw 690409 Retainer−Muffler Guard 691105 Nut (Muffler Adapter) 691808 Locknut−Muffler/Elbow 393232s Muffler 300A 498984s Muffler 300B 392989 Muffler 300C 291519 Muffler 300D 399635 Muffler 93734 Pipe−Exhaust (8” Long) 301B 91416 Pipe−Exhaust (1 1/2”...
  • Page 13 240A REF. PART DESCRIPTION 690280 Screw (Fuel Tank Strap) 691068 Bracket−Fuel Tank −−−−−−− Note −−−−− 222669 Bracket− Fuel Tank Used on Type No(s). 0205, 0291, 0648. 182A 690262 Bracket−Fuel Tank 691937 Strap−Fuel Tank −−−−−−− Note −−−−− 291367 Strap− Fuel Tank (4 Quart) Used on Type No(s).
  • Page 14 REF. PART DESCRIPTION 291488 Tank−Fuel (6 Quart) −−−−−−− Note −−−−− 290816 Tank−Fuel (4 Quart) 292415 Tank−Fuel (8 Quart) Used on Type No(s). 0137, 0140, 0141, 0143, 0148, 0151, 0152, 0153, 0156, 0162, 0163, 0167, 0172, 0173, 0175, 0176, 0178, 0180, 0181, 0183, 0185, 0186, 0197, 0199, 0201, 0203, 0205,...
  • Page 15 REF. PART DESCRIPTION 395250 Flywheel (For Magnetron Ignition, Identified by Two Red Stripes) Used on Type No(s). 0611, 0620, 0632, 0633, 0635, 0637, 0640, 0641, 0642, 0644, 0645, 0646, 0647, 0648, 0650, 0651, 0652, 0655, 0656, 0657, 0659, 0662, 0664, 0670, 0674, 0677, 0681, 0683, 0686, 0689, 0690, 0691, 0694,...
  • Page 16 691151 Fan−Booster 321A 690377 Fan−Booster 321B 212000 Fan−Booster 691075 Washer (Booster Fan) 691059 Nut (Flywheel) Assemblies include all parts shown in frames. REF. PART DESCRIPTION 691076 Screw (Booster Fan) 690265 Retainer 211983 Adapter− Blower Housing Ring Valve Gasket Set−Reference 1095 03/18/2009...
  • Page 17 REF. PART DESCRIPTION 294698 Housing−Blower −−−−−−− Note −−−−− 297010 Housing− Blower Used on Type No(s). 0060, 0119, 0160, 0197, 0216, 0223, 0237. 297453 Housing− Blower Used on Type No(s). 0020, 0023, 0050, 0136, 0139, 0140, 0145, 0150, 0151, 0152, 0155, 0159,...
  • Page 18 452B 588A REF. PART DESCRIPTION 90072 Screw (Back Plate) 222445 Guide−Air 691612 Nut (Back Plate) 691666 Screw (Mounting Bracket) 690305 Screw (Cable Clamp) 690305 Screw (Wire Clip) 690371 Washer (Back Plate) 690290 Screw (Back Plate) Engine Gasket Set−Reference 358 Carburetor Overhaul Kit−Reference 121 6179−18 488A 729A...
  • Page 19 REF. PART DESCRIPTION 691355 Housing− Rewind Starter (Low Profile) 392630 Pulley−Starter (Low Profile) 295871 Pulley−Starter (Wide Legs Starter Housing, Includes 63” Rope) 490179 Spring−Rewind Starter 692188 Rope−Starter (63” Long) (Use With Plastic Pulley) −−−−−−− Note −−−−− 695002 Rope−Starter (99” Long) (Cut to Required Length) (Use With...
  • Page 20 REF. PART DESCRIPTION 66 393127s Clutch−Starter 399671 Clutch−Starter (Sealed) 690542 Housing−Clutch 394897 Housing−Clutch 691604 Ball−Clutch Engine Gasket Set−Reference 358 Carburetor Overhaul Kit−Reference 121 6179−20 REF. PART DESCRIPTION 690271 Washer (Starter Clutch) 690260 Washer (Starter Clutch) 690277 Washer (Starter Clutch) 691945 Ratchet−Clutch Assemblies include all parts shown in frames.
  • Page 21 REF. PART DESCRIPTION 68898 Belt−Vee (For Low Position Mounting) (35 3/4” Long) −−−−−−− Note −−−−− 68878 Belt−Vee (For High Position Mounting) (36 3/4” Long) 691681 Screw (Starting Switch) Regulator (Saddle Mount) (Delco Remy Number 1119577) (NO LONGER AVAILABLE) Engine Gasket Set−Reference 358 Carburetor Overhaul Kit−Reference 121 6179−21 1217...
  • Page 22 1217 1225 PARTS GHOSTED AVAILABLE IN KIT ONLY REF. PART DESCRIPTION 398808 Wire−Stop 93415 Screw (Starting Switch) Bracket−Mounting (NO LONGER AVAILABLE) 295158 Ammeter (Stewart Warner Number 357−W) 692303 Switch−Starting 578A 298582 Wire Assembly 696198 Nut (Starting Switch) (Terminal) 691075 Washer (Starting Switch) (Terminal) Engine Gasket Set−Reference 358...
  • Page 23 840A 1225 945A 578C REF. PART DESCRIPTION 27381 Gasket−Intake 692917 Gasket−Intake 215A 291871 Guide−Air 692179 Clamp−Casing 267A 93107 Screw (Casing Clamp) −−−−−−− Note −−−−− 691044 Screw (Casing Clamp) Used on Type No(s). 0644, 0672. 690323 Screw (Starter Motor) (4” Long) 310A 692329 Screw (Starter Motor)
  • Page 24 333B 351A 989B USED BEFORE CODE DATE: 81080100 REF. PART DESCRIPTION 24 222698s Key−Flywheel 333A 398811 Armature−Magneto (Breaker Ignition) (Used After Code Date 81073100). 333B 298968 Armature−Magneto (Breaker Ignition) (Used Before Code Date 81080100). 691061 Screw (Magneto Armature) 26018 Spring−Breaker Arm 298060 Condenser Cover−Breaker (NO LONGER...
  • Page 25 SEE REPAIR INSTRUCTION MANUAL FOR PROPER AMPERAGE OF ALTERNATOR DUAL CIRCUIT 1059 REF. PART DESCRIPTION 696459 Alternator (Dual Circuit) 474A 696457 Alternator (Tri−Circuit) 474C 696458 Alternator (10 Amp) (Key Switch) 474D 391595 Alternator (AC Only) 474E 696578 Alternator (DC Only) 475A 391507 Rectifier 230976 Bushing−Alternator...
  • Page 26 1051 REF. PART DESCRIPTION 396306 Motor−Starter 310B 691263 Screw (Starter Motor) (4 3/4” Long) 497608 Brush Set 696541 Drive−Starter 692024 Clutch−Drive Armature−Starter (Serviced By 396306 Starter Motor Only) Engine Gasket Set−Reference 358 Carburetor Overhaul Kit−Reference 121 6179−26 668B REF. PART DESCRIPTION 668B 396515 Spacer...
  • Page 27 309A 510A 510B 773A 896A REF. PART DESCRIPTION 309A Motor−Starter (For Replacement Starter Motor, See Reference 309, Previous Page) 310A 692329 Screw (Starter Motor) (5” Long) 311A 395538 Brush Set 691693 Screw (Starter Strap) Engine Gasket Set−Reference 358 Carburetor Overhaul Kit−Reference 121 6179−27 NOTE: For Replacement Starter Motor, See Reference 309, Previous Page...
  • Page 28 1095 VALVE GASKET SET 1227 REF. PART DESCRIPTION 691948 Seal−Oil (Magneto Side) 272166 Gasket−Cylinder Head 27803s Gasket−Breather 20A 291675s Seal−Oil (PTO Side) 27381 Gasket−Intake 692214 Gasket−Intake 692917 Gasket−Intake 292681 Kit−Idle Mixture 692215 Gasket−Carburetor Body 691775 Pin−Float Hinge 394989 Kit−Carburetor Overhaul (Used After Code Date 81090800).
