FORM MS−3478−05/09/2006
REPLACES FORM MS−6179−08/30/2005
FILE IN SECT. 2 OF SERVICE MANUAL
32K400
Illustrated Parts List
Model Series
32K400
GAS/KEROSENE
TYPE NUMBER(S)
0112.
PRINTED IN U.S.A.
COPYRIGHT by BRIGGS & STRATTON CORPORATION
All rights reserved. No part of this material may be reproduced or transmitted,
in any form or by any means, electronic or mechanical, including photocopying,
recording or by any information storage and retrieval system, without permission
in writing from Briggs & Stratton Corporation.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Briggs & Stratton 32K400 Series
Summary of Contents for Briggs & Stratton 32K400 Series
-
Page 1: Illustrated Parts List
FORM MS−3478−05/09/2006 REPLACES FORM MS−6179−08/30/2005 FILE IN SECT. 2 OF SERVICE MANUAL 32K400 Illustrated Parts List Model Series 32K400 GAS/KEROSENE TYPE NUMBER(S) 0112. PRINTED IN U.S.A. COPYRIGHT by BRIGGS & STRATTON CORPORATION All rights reserved. No part of this material may be reproduced or transmitted,... - Page 2 1334 REF. PART DESCRIPTION 395663 Cylinder Assembly 691712 Head−Cylinder 225137 Washer (Cylinder Head) 7 K∅692231 Gasket−Cylinder Head 495738 Breather Assembly 9 K∅27803s Gasket−Breather 690294 Screw (Breather Assembly) 691512 Tube−Breather 691614 Screw (Cylinder Head) (1 3/4” Long) −−−−−−− Note −−−−− 691640 Screw (Cylinder Head) (2 1/16”...
- Page 3 1141 228A REF. PART DESCRIPTION 3 K291675s Seal−Oil (Magneto Side) 690536 Crankshaft 691938 Bearing−Ball K691948 Seal−Oil (PTO Side) 222698s Key−Flywheel 390364 Piston Assembly (Standard) −−−−−−− Note −−−−− 390366 Piston Assembly (.020” Oversize) 390484 Ring Set (Standard) −−−−−−− Note −−−−− 390505 Ring Set (.020”...
- Page 4 REF. PART DESCRIPTION 690946 Plug−Oil Drain K691948 Seal−Oil (PTO Side) 281658 Cap−Oil Fill K691310 Gasket−Gear Reduction Cover K Engine Gasket Set−Reference 358 D Carburetor Overhaul Kit−Reference 121 3478−4 REF. PART DESCRIPTION 691352 Dipstick 524 K281370s Seal−Diptstick Tube 690622 Tube−Dipstick 294751 Base−Engine K691569 Gasket−Engine Base 690389 Clamp−Cable Assemblies include all parts shown in frames.
- Page 5 1227 REF. PART DESCRIPTION 691152 Manifold−Intake 27381 Gasket−Intake 692214 Gasket−Intake (Carburetor) 690953 Screw (Intake Manifold) 691681 Screw (Intake Manifold) 391065 Carburetor 391067 Body Assembly−Upper 691769 Bushing−Throttle Shaft 292681 Kit−Idle Mixture 691437 Screw (Throttle Valve) 691944 Shaft−Throttle 693942 Kit−Idle Speed 691616 Pin−Shaft K Engine Gasket Set−Reference 358 D Carburetor Overhaul Kit−Reference 121 3478−5...
- Page 6 REF. PART DESCRIPTION 690267 Collar−Bell Crank 691241 Stud (Air Cleaner) (9 1/2” Long) 690284 Nut (Air Cleaner) 690263 Crank−Bell 690810 Screw (Bell Crank) 691584 Nut−Governor Adjusting 393613 Rod−Governor Control 691596 Spring−Governor 691791 Link−Throttle K Engine Gasket Set−Reference 358 D Carburetor Overhaul Kit−Reference 121 3478−6 REF.
- Page 7 240A REF. PART DESCRIPTION 690280 Screw (Fuel Tank Strap) Tank−Fuel (No Longer Available) 392887 Cap−Fuel Tank (Large) (Kerosene Only) 181A 392886 Cap−Fuel Tank (Small) (Gas Only) 691068 Bracket−Fuel Tank 182A 690262 Bracket−Fuel Tank 691937 Strap−Fuel Tank 691764 Connector−Hose 186A 691609 Connector−Hose 791893 Line−Fuel 187A 791745 Line−Fuel...
- Page 8 864A REF. PART DESCRIPTION 395251 Flywheel (Magnetron) −−−−−−− Note −−−−− 391363 Flywheel 691171 Screen−Rotating 691655 Screw (Rotating Screen) 691178 Lock−Muffler Screw 691105 Nut (Muffler Adapter) 691808 Locknut−Muffler 399635 Muffler 691151 Fan−Booster K Engine Gasket Set−Reference 358 D Carburetor Overhaul Kit−Reference 121 3478−8 REF.
- Page 9 729A 452A 305A REF. PART DESCRIPTION 90072 Screw (Back Plate) (5/8”Long) 391229 Housing−Blower 690297 Screw (Blower Housing) (7/16” Long) 305A 690290 Screw (Blower Housing) (1/2” Long) 691612 Nut (Back Plate) 398811 Armature−Magneto 691061 Screw (Armature) 690650 Wire−Stop 691077 Washer (Insulator) 690305 Screw (Clip Wire) 691612 Nut...
- Page 10 1051 668A REF. PART DESCRIPTION 396306 Motor−Starter 692329 Bolt (Starter Motor) 497608 Brush Set 691693 Screw (Starter Strap) 690406 Strap−Starter 696541 Drive−Starter 692024 Clutch−Drive 490309 Armature−Starter K Engine Gasket Set−Reference 358 D Carburetor Overhaul Kit−Reference 121 3478−10 REF. PART DESCRIPTION 668A 396515 Spacer (Starter Motor)
- Page 11 1095 VALVE GASKET SET REF. PART DESCRIPTION 291675s Seal−Oil (Magneto Side) 692231 Gasket−Cylinder Head 27803s Gasket−Breather 691948 Seal−Oil (PTO Side) 27381s Gasket−Intake 692214 Gasket−Intake 292681 Kit−Idle Mixture 692215 Gasket−Carburetor Body 691775 Pin−Float Hinge 394989 Kit−Carburetor Overhaul 690627 Plug−Welch 394682 Kit−Needle/Seat 691966 Nozzle−Carburetor K Engine Gasket Set−Reference 358 D Carburetor Overhaul Kit−Reference 121...
