Operation instruction
SR 562
Hood
Revision: 02
OI06H-5118 SR 562
1
2020-05-07

Advertisement

loading
Need help?

Need help?

Do you have a question about the SR 562 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sundstrom SR 562

Summary of Contents for Sundstrom SR 562

  • Page 1 Operation instruction SR 562 Hood Revision: 02 OI06H-5118 SR 562 2020-05-07...

  • Page 2: General Information

    Instructions for use for SR 562 should be read before use. The SR 562 together with fan unit SR 500 / SR 500 EX / SR 700 and approved filters are included in the Sundström fan-assisted respiratory protective device system conforming to EN 12941/EN 12942:1998 class TH3.
  • Page 3 Unpacking SR 562 Packing list: • Hood with breathing hose • User instruction • Cleaning tissue OI06H-5118 SR 562 2020-05-07...

  • Page 4: Functional Check

    If the flow rate is below the minimum value, check that • The flow meter is vertical. • The float can move freely. • The air supply is not restricted by kinks or other restrictions in the hoses. OI06H-5118 SR 562 2020-05-07...
  • Page 5 2. Connect the hose 2.3 …and turn it clockwise 2.1 Check that the O-ring of the hose is in place. about 1/ 8 of a turn. 2.2 Connect the hose to the fan unit or compressed air attachment… OI06H-5118 SR 562 2020-05-07...
  • Page 6 The rubber band in the face seal can be adjusted to the required length. 3.2 Insert your chin into the hood. Keep your grip of the hood and draw it over your head. OI06H-5118 SR 562 2020-05-07...
  • Page 7 You can reach it without taking off the hood. Turn clockwise to tighten and counter clockwise to widen. 3.5 If necessary, adjust the head harness in height by lengthening or shortening the strap for the top of the head. OI06H-5118 SR 562 2020-05-07...
  • Page 8 4.2 Release the face seal 4.4 Fit the Velcro tape with rubber bands secured to the the rough side towards the forehead band next to the forehead band and the notch Velcro tapes. at the top. OI06H-5118 SR 562 2020-05-07...
  • Page 9 5.2 Release the face seal 5.4 Release the three press rubber bands secured to the studs at the top edge of the forehead band next to the visor Velcro tapes. Lift the head harness out of the hood. OI06H-5118 SR 562 2020-05-07...
  • Page 10 5.8 Fold the Velcro tapes head harness with one hand around the forehead band and insert the head harness and secure them as firmly as into the hood, first inserting possible. the rear part fitted with the hose. OI06H-5118 SR 562 2020-05-07...
  • Page 11 Secure it by pulling the rubber band into the narrow part of the slot. 5.91 Mount the hose in the adapter. OI06H-5118 SR 562 2020-05-07...
  • Page 12 One hose connection is fitted with an O-ring. This end should be connected to the fan/compressed air unit. 6.2 Twist the hose and pull it out of the adapter. OI06H-5118 SR 562 2020-05-07...
  • Page 13 Use polygrip pliers if the locknut is stiff to turn. Fit the new adapter to the head harness in the reverse order. 7.2 Twist the hose and pull it out of the adapter OI06H-5118 SR 562 2020-05-07...
  • Page 14 NOTE! Never use a solvent for cleaning! with a solution of water and dishwashing detergent or the like. Rinse the equipment and leave it to dry. 8.1 Sundström cleaning tissues SR 5226 are recommended for daily care OI06H-5118 SR 562 2020-05-07...

  • Page 15: Maintenance Schedule

    9. Maintenance schedule 9.1 Recommended minimum requirements on maintenance routines Before use After use so you will be certain that the equipment will always be in usable • • Visual inspection condition. • Performance check Cleaning • OI06H-5118 SR 562 2020-05-07...
