- Page 1 model no. 054-7281-0 CORDED MULTI-CRAFTER KIT IMPORTANT: INSTRUCTION Please read this manual carefully before using this tool and MANUAL save it for reference.
- Page 2 model no. 054-7281-0 | contact us 1-800-689-9928...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Technical specifications General power tool safety warnings Symbols Key parts diagram Accessories Parts list Operating instructions Working hints for your tool Maintain tools with care Warranty NOTE: If any parts are missing or damaged, or if you have any questions, please call our toll-free helpline at 1-800-689-9928. -
Page 4: Technical Specifications
054-7281-0 | contact us 1-800-689-9928 model no. 054-7281-0 | contact us 1-800-689-9928 TECHNICAL SPECIFICATIONS Type Designation PMF300GU (PM-designation of machinery, representative of multi-tool Voltage: 120V, 60 Hz AC Amps: 2.5A Oscillations speed: 11,000–20,000 OPM (no load) Oscillations angle: 3.2°... -
Page 5: General Power Tool Safety Warnings
WORK AREA SAFETY Keep work area clean and well lit. Cluttered or dark areas invite accidents. • • Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes. Keep children and bystanders away while operating a power tool. - Page 6 model no. 054-7281-0 | contact us 1-800-689-9928 model no. 054-7281-0 | contact us 1-800-689-9928 • If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock. PERSONAL SAFETY •...
- Page 7 • Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles and grasping surfaces do not allow for safe handling and control of the tool in unexpected situations. SERVICE • Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained.
-
Page 8: Symbols
model no. 054-7281-0 | contact us 1-800-689-9928 model no. 054-7281-0 | contact us 1-800-689-9928 SYMBOLS To reduce the risk of injury, the user must read the instruction manual. Double insulation Warning Wear ear protection Wear eye protection Wear a dust mask Don’t use in the rain... -
Page 9: Key Parts Diagram
KEY PARTS DIAGRAM Description Description Tool-less blade change lever LED work light On/off switch Flush-cutting blade Variable speed dial Sandpaper Grip area Segmented saw blade Venting slots Detail sanding base Accessory interface Flexible scraping blade Flange Not all the accessories illustrated or described are included in standard delivery. -
Page 10: Accessories
model no. 054-7281-0 | contact us 1-800-689-9928 model no. 054-7281-0 | contact us 1-800-689-9928 ACCESSORIES Detail sanding base 3 1/8” segmented saw blade 1 3/8” flush-cutting blade Flexible scraping blade Sandpaper (80/120/180 grit) Nylon tote We recommend that you purchase your accessories from the same store that sold you the tool. Refer to the accessory packaging for further details. -
Page 11: Parts List
PARTS LIST No. Description Qty. No. Description Qty. Flange assembly Retaining ring O-rings Ball bearing race Revolve shaft Bearing Clutch lining Rotor Compression spring Bearing Orientation sleeve Magnet ring Washer Transistor Locked spring Left cover Linkage Wind baffle ring Spindle Screw Retaining ring Stator... - Page 12 model no. 054-7281-0 | contact us 1-800-689-9928 model no. 054-7281-0 | contact us 1-800-689-9928 model no. 054-7281-0 | contact us 1-800-689-9928...
-
Page 13: Operating Instructions
1. MOUNTING ACCESSORIES Caution: For all work or when changing accessories, always wear protective gloves. Avoid risk of injury from the sharp edges of the accessories. Accessories can become very hot while working, presenting danger of burns! Make sure the tool is unplugged prior to changing accessories. - Page 14 model no. 054-7281-0 | contact us 1-800-689-9928 model no. 054-7281-0 | contact us 1-800-689-9928 Fig. B2 2) Insert the flush-cutting blade onto the accessory interface (6), (if necessary, re-insert the flange) then press down on the flange with a finger to keep the blade temporarily secure. Flip the lever (1) back down to the seated position to secure the accessory.
- Page 15 Fig. E 2. OPERATING THE ON/OFF SWITCH (See Fig. F) ——Switching the power tool ON: Slide the switch forward. ——Switching the power tool OFF: Slide the switch backward. 3. USING THE VARIABLE SPEED DIAL (See Fig. G) Select the oscillation frequency (speed) while the motor is running.
- Page 16 model no. 054-7281-0 | contact us 1-800-689-9928 model no. 054-7281-0 | contact us 1-800-689-9928 model no. 054-7281-0 | contact us 1-800-689-9928 APPLICATION Warning: The saw teeth are very sharp. Do not touch during mounting and application. The workpiece must be clamped tightly before it is cut. Function Accessory Name...
-
Page 17: Working Hints For Your Tool
WORKING HINTS FOR YOUR TOOL If your power tool becomes too hot, especially when used at low speed, set the speed to maximum and run it with no load for 2–3 minutes to cool the motor. Avoid prolonged usage at very low speeds. Always keep the blade sharp. Always ensure the workpiece is firmly held or clamped to prevent movement. -
Page 18: Maintain Tools With Care
model no. 054-7281-0 | contact us 1-800-689-9928 model no. 054-7281-0 | contact us 1-800-689-9928 MAINTAIN TOOLS WITH CARE Remove the plug from the socket before carrying out any adjustment, servicing or maintenance. Your power tool requires no additional lubrication or maintenance. There are no user serviceable parts in your power tool. -
Page 19: Warranty
This Mastercraft product is guaranteed for a period of 3 years from the date of original retail purchase against defects in workmanship and materials, except for the following components: a) Component A: Batteries, chargers and carrying case, which are guaranteed for a period of 2 years from the date of original retail purchase against defects in workmanship and materials;...
